lamborghini lp580-2 coupe (2016) for pick parts diagram

899.03.00 - FOR PICK

Lamborghini LP580-2 Coupe (2016) FOR PICK Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
          #
          Part number
          Description
          Price
          # 001
          MPN: 07L903137T
          POLY-V-BELT
          17,8X970MM
          from £52.40
          from £52.40
          # 002
          MPN: 7P0915105C
          BATTERY, FILLED AND CHARGED
          Supersession
          Supersession
          # 003
          MPN: 420698451B
          1 SET OF BRAKE PADS WITH WEAR DISPLAY FOR DISC BRAKES ECO
          356X32MM
          Supersession
          Supersession
          # 003
          MPN: 4S0698151B
          1 SET OF BRAKE PADS FOR DISK BRAKE
          365X34MM FRONT
          Supersession
          Supersession
          # 003
          MPN: 4S0698151F
          FRONT BRAKE PADS SET
          Supersession
          Supersession
          # 003
          MPN: 4S0698451J
          1 SET OF BRAKE PADS FOR DISK BRAKE
          356X32MM REAR
          Supersession
          Supersession
          # 004
          MPN: 06H905601C
          SPARK PLUG LONGLIFE
          from £21.15
          from £21.15
          This part replaces part number 06H905601A which we have in stock - and 2 more. Click to view details
          # 005
          MPN: 4T1955405
          AERO WIPER ARM
          DRIVER SIDE (EUROPE, USA spec vehicles)
          from £218.76
          from £218.76
          # 005
          MPN: 4T1955406A
          AERO WIPER ARM
          PASSENGER SIDE (EUROPE, USA spec vehicles)
          from £218.76
          from £218.76
          # 005
          MPN: 4T2955405
          AERO WIPER ARM
          PASSENGER SIDE (UK spec vehicles)
          from £120.32
          from £120.32
          # 005
          MPN: 4T2955406
          AERO WIPER ARM
          DRIVER SIDE (UK spec vehicles)
          from £218.76
          from £218.76
          # 006
          MPN: 4T0845099G
          WINDSCREEN
          from £2,727.95
          from £2,727.95
          # 007
          MPN: 4T8845501B
          REAR WINDOW
          from £266.79
          from £266.79
          # 008
          MPN: 4T8845201
          DOOR WINDOW
          LEFT
          from £545.59
          from £545.59
          # 008
          MPN: 4T8845202
          DOOR WINDOW
          RIGHT
          from £545.59
          from £545.59
          # 009
          MPN: 4T8845299D
          side window (fixed)
          LEFT REAR
          from £546.45
          from £546.45
          # 009
          MPN: 4T8845300D
          side window (fixed)
          RIGHT REAR
          from £300.55
          from £300.55
          # 010
          MPN: 4T0845115C
          side window (fixed)
          LEFT FRONT
          from £244.44
          from £244.44
          # 010
          MPN: 4T0845116C
          side window (fixed)
          RIGHT FRONT
          from £244.44
          from £244.44
          # 011
          MPN: 4T0412019AA
          Shock Absorbers
          AMR-FRONT
          from £2,010.59
          from £2,010.59
          # 011
          MPN: 4T0412019AB
          Shock Absorbers
          AMR + LIFTING SYSTEM-FRONT
          from £2,334.77
          from £2,334.77
          # 011
          MPN: 4T0412019AJ
          Shock Absorbers
          LIFTING SYSTEM-FRONT
          from £2,217.87
          from £2,217.87
          # 012
          MPN: 4T0512019K
          Shock Absorbers
          STANDARD-REAR
          from £668.26
          from £668.26
          # 012
          MPN: 4T0512019M
          Shock Absorbers
          MAGNETIC RIDE-REAR
          from £2,922.62
          from £2,922.62
          # 013
          MPN: 4T0857521G
          MIRROR GLASS (CONVEX)
          FOR USA, CANADA AND SOUTH KOREA-LEFT (EUROPE, USA spec vehicles)
          from £91.22
          from £91.22
          This part replaces part number 4T0857521
          # 013
          MPN: 4T0857521H
          MIRROR GLASS (CONVEX)
          NOT VALID FOR SOUTH KOREA-LEFT (EUROPE, UK spec vehicles)
          from £91.22
          from £91.22
          # 013
          MPN: 4T0857522C
          MIRROR GLASS (CONVEX)
          ELECTROCROMI C-RIGHT (EUROPE, UK spec vehicles)
          from £998.67
          from £998.67
          # 013
          MPN: 4T0857522G
          MIRROR GLASS (CONVEX)
          FOR USA, CANADA AND SOUTH KOREA-RIGHT (EUROPE, USA spec vehicles)
          from £91.22
          from £91.22
          # 013
          MPN: 4T0857522H
          MIRROR GLASS (CONVEX)
          RIGHT (EUROPE, UK spec vehicles)
          from £91.22
          from £91.22
          This part replaces part number 4T0857522B
          # 014
          MPN: 4T0857387C001
          EXTERIOR MIRROR
          SUPPLY VIN - LEFT-INTERMEDIATE PRIMER
          from £1,936.81
          from £1,936.81
          # 014
          MPN: 4T0857388C001
          EXTERIOR MIRROR
          SUPPLY VIN - RIGHT-INTERMEDIATE PRIMER
          from £1,936.81
          from £1,936.81
          # 014
          MPN: 4T0857507A
          EXTERIOR MIRROR
          SUPPLY VIN-LEFT
          from £1,603.92
          from £1,603.92
          # 014
          MPN: 4T0857508B
          EXTERIOR MIRROR
          SUPPLY VIN-RIGHT
          from £1,603.92
          from £1,603.92
