615.02.00 - CERAMIC BRAKE DISC REAR
Lamborghini LP580-2 SPYDER (2016) CERAMIC BRAKE DISC REAR Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 4S0615601A
CERAMIC BRAKE DISC (VENTED)
LEFT REAR
from £4,530.73
from £4,530.73
# 001
MPN: 4S0615602A
CERAMIC BRAKE DISC (VENTED)
RIGHT REAR
from £2,491.90
from £2,491.90
This part replaces part number 420615602F which we have in stock - and 2 more. Click to view details
# 002
MPN: N10648301
HEX SOCKET COUNTERSUNK BOLT
M6X16
from £0.56
from £0.56
# 003
MPN: 4T0615405AQ
FLOATING CALIPER BRAKE
LEFT REAR 'VERDE MANTIS'
from £905.93
from £905.93
# 003
MPN: 4T0615405CB
FLOATING CALIPER BRAKE
LEFT REAR BLACK
from £729.75
from £729.75
# 003
MPN: 4T0615405CC
FLOATING CALIPER BRAKE
REPLACE FOR AXLE-LEFT REAR YELLOW
from £1,530.42
from £1,530.42
# 003
MPN: 4T0615405CF
FLOATING CALIPER BRAKE
ALSO ORDER THE RIGHT-LEFT REAR RED
from £1,608.25
from £1,608.25
# 003
MPN: 4T0615405CH
FLOATING CALIPER BRAKE
AD-PERSONAM-LEFT REAR 'VERDE SCANDAL'
from £3,328.88
from £3,328.88
# 003
MPN: 4T0615405CJ
FLOATING CALIPER BRAKE
AD-PERSONAM-LEFT REAR BLUE
from £3,138.66
from £3,138.66
# 003
MPN: 4T0615405S
FLOATING CALIPER BRAKE
LEFT REAR SILVER
from £1,435.31
from £1,435.31
# 003
MPN: 4T0615405T
FLOATING CALIPER BRAKE
LEFT REAR ORANGE
from £1,023.53
from £1,023.53
# 003
MPN: 4T0615406AN
FLOATING CALIPER BRAKE
RIGHT REAR ORANGE
from £1,595.27
from £1,595.27
# 003
MPN: 4T0615406AQ
FLOATING CALIPER BRAKE
RIGHT REAR 'VERDE MANTIS'
from £905.93
from £905.93
# 003
MPN: 4T0615406CB
FLOATING CALIPER BRAKE
RIGHT REAR BLACK
from £1,174.62
from £1,174.62
# 003
MPN: 4T0615406CC
FLOATING CALIPER BRAKE
REPLACE FOR AXLE-RIGHT REAR YELLOW
from £841.73
from £841.73
# 003
MPN: 4T0615406CF
FLOATING CALIPER BRAKE
RIGHT REAR RED
from £1,608.25
from £1,608.25
# 003
MPN: 4T0615406CH
FLOATING CALIPER BRAKE
AD-PERSONAM-RIGHT REAR 'VERDE SCANDAL'
from £3,328.88
from £3,328.88
# 003
MPN: 4T0615406CJ
FLOATING CALIPER BRAKE
AD-PERSONAM-RIGHT REAR BLUE
from £3,138.66
from £3,138.66
# 003
MPN: 4T0615406R
FLOATING CALIPER BRAKE
RIGHT REAR YELLOW
from £1,019.45
from £1,019.45
# 003
MPN: 4T0615406S
FLOATING CALIPER BRAKE
RIGHT REAR SILVER
from £1,435.31
from £1,435.31
# 004
MPN: 420615437B
CONTACTS
rear
from £25.21
from £25.21
# 005
MPN: 4S0611847H
RETAINER FOR BRAKE HOSE
LEFT REAR
from £14.41
from £14.41
# 005
MPN: 4S0611848H
RETAINER FOR BRAKE HOSE
RIGHT REAR
from £7.93
from £7.93
# 006
MPN: 420611775A
BRAKE HOSE
rear
from £20.00
from £20.00
# 007
MPN: 4S0971845D
HOLDER FOR WIRING HARNESS
LEFT REAR
from £5.97
from £5.97
# 007
MPN: 4S0971846A
HOLDER FOR WIRING HARNESS
RIGHT REAR
from £10.19
from £10.19
# 008
MPN: 8K0611715
RETAINING SPRING
from £0.68
from £0.68
# 009
MPN: 4S0698451J
1 SET OF BRAKE PADS FOR DISK BRAKE
356X32MM
Supersession
Supersession
# 010
MPN: N10406504
OVAL HEXAGON SOCKET HEAD BOLT
M6X12
from £1.13
from £1.13
# 011
MPN: N91042302
OVAL HEXAGON SOCKET HEAD BOLT
M6X16
from £0.63
from £0.63
# 012
MPN: 4S0611847D
RETAINER FOR BRAKE HOSE
LEFT REAR
from £6.98
from £6.98
# 012
MPN: 4S0611848D
RETAINER FOR BRAKE HOSE
RIGHT REAR
from £6.98
from £6.98
# 013
MPN: 4E0927803F
SPEED SENSOR
LEFT
from £46.41
from £46.41
This part replaces part number 4E0927803D which we have in stock - and 7 more. Click to view details
# 013
MPN: 4E0927804F
SPEED SENSOR
RIGHT
from £46.41
from £46.41
This part replaces part number 4E0927804D which we have in stock - and 6 more. Click to view details
# 014
MPN: N91141801
SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD
M12X1,5X105X90
from £12.89
from £12.89
# 015
MPN: N10406504
OVAL HEXAGON SOCKET HEAD BOLT
M6X12
from £1.07
from £1.07
# 016
MPN: 4S0615611A
COVER PLATE FOR BRAKE DISC
LEFT
from £13.13
from £13.13
# 016
MPN: 4S0615612A
COVER PLATE FOR BRAKE DISC
RIGHT
from £13.13
from £13.13
# 017
MPN: N01474011
SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD
M6X16
from £1.26
from £1.26
# 018
-
FLOATING CALIPER
# 019
-
SUSPENSION
# 020
MPN: 211611483
DUST CAP
from £3.47
from £3.47
# 021
MPN: 8A0615273
BREATHER VALVE
from £11.68
from £11.68
# 022
MPN: 420698269C
1 SET ATTACHMENT PARTS
from £49.46
from £49.46
