lamborghini lp580-2 spyder (2018) doors parts diagram

837.01.00 - Doors

Lamborghini LP580-2 SPYDER (2018) DOORS Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Price
              # 001
              MPN: 4T7831051C
              DOOR
              LEFT
              from £3,674.73
              from £3,674.73
              # 001
              MPN: 4T7831052C
              DOOR
              RIGHT
              from £3,674.73
              from £3,674.73
              # 002
              MPN: 4T0837911C
              DOOR SEAL
              LEFT OUTER
              from £61.28
              from £61.28
              # 002
              MPN: 4T0837912C
              DOOR SEAL
              RIGHT OUTER
              from £96.30
              from £96.30
              # 003
              MPN: 4T7837477A
              WINDOW APERTURE SEAL
              LEFT
              from £87.74
              from £87.74
              # 003
              MPN: 4T7837478A
              WINDOW APERTURE SEAL
              RIGHT
              from £87.74
              from £87.74
              # 004
              MPN: 4T0837397C
              WINDOW REGULATOR WITHOUT MOTOR
              UNTIL VIN HLA06645 ORDER ALSO RIGHT PART-LEFT
              from £347.15
              from £347.15
              # 004
              MPN: 4T0837398C
              WINDOW REGULATOR WITHOUT MOTOR
              UNTIL VIN HLA06645 ORDER ALSO LEFT PART-RIGHT
              from £347.15
              from £347.15
              # 005
              MPN: 8K0959801B
              WINDOW REGULATOR MOTOR
              LEFT
              from £68.72
              from £68.72
              # 005
              MPN: 8K0959802B
              WINDOW REGULATOR MOTOR
              RIGHT
              from £76.80
              from £76.80
              # 006
              MPN: 4T0837917
              DOOR SEAL
              LEFT
              from £11.68
              from £11.68
              # 006
              MPN: 4T0837918
              DOOR SEAL
              RIGHT
              from £11.68
              from £11.68
              # 007
              MPN: 4T0837405
              WINDOW GUIDE
              LEFT
              from £25.35
              from £25.35
              # 007
              MPN: 4T0837406
              WINDOW GUIDE
              RIGHT
              from £25.35
              from £25.35
              # 008
              MPN: 4T0837933B
              SEAL
              LEFT A. RIGHT REAR
              from £27.55
              from £27.55
              # 009
              MPN: 4T0837349B
              SEAL
              LEFT A. RIGHT FRONT
              from £15.44
              from £15.44
              # 010
              MPN: 4T0831619
              WINDOW GUIDE
              WARNING UP TO VIN CLA00425 USE ALSO RIF. 2-LEFT
              from £25.35
              from £25.35
              # 010
              MPN: 4T0831620
              WINDOW GUIDE
              WARNING UP TO VIN CLA00425 USE ALSO RIF. 2-RIGHT
              from £25.35
              from £25.35
              # 011
              MPN: 8V0837267
              COVER
              LEFT A. RIGHT FRONT
              from £1.60
              from £1.60
              # 012
              MPN: 8S0837249
              DOOR CATCH
              LEFT A. RIGHT FRONT
              from £11.53
              from £11.53
              # 013
              MPN: WHT000778
              WASHER
              30X36X1
              from £0.51
              from £0.51
              # 014
              MPN: N10459201
              HEXAGON SOCKET HEAD BOLT
              M5X12
              from £0.51
              from £0.51
              # 015
              MPN: 4H0839111
              COVER CAP
              16,2
              from £0.53
              from £0.53
              # 016
              MPN: 1Z0971904A
              BUNGS
              from £0.53
              from £0.53
              # 017
              MPN: N90663602
              HEX. NUT WITH WASHER
              M5
              from £0.53
              from £0.53
              This part replaces part number N90663601
              # 018
              MPN: N91203201
              FLAT HEAD MULTI-POINT SOCKET BOLT
              M8X22
              from £1.47
              from £1.47
              # 019
              MPN: 4T7831431
              DOOR SEAL
              LEFT
              from £3.64
              from £3.64
              # 019
              MPN: 4T7831432
              DOOR SEAL
              RIGHT
              from £3.64
              from £3.64
              # 020
              MPN: 4T7831121
              REINFORCEMENT FOR DOOR HANDLE
              LEFT
              from £104.38
              from £104.38
              # 020
              MPN: 4T7831122
              REINFORCEMENT FOR DOOR HANDLE
              RIGHT
              from £105.58
              from £105.58
              # 021
              MPN: 8L3837199B
              CLIP
              from £0.62
              from £0.62
              # 022
              MPN: N91084201
              SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD (KOMBI)
              M8X25
              from £1.96
              from £1.96
              # 023
              MPN: WHT003237
              HEXAGON SOCKET FLAT HEAD BOLT
              M6X12
              from £0.87
              from £0.87
              # 024
              MPN: N01166623
              WASHER
              6,4X18X1,6
              from £0.94
              from £0.94
              This part replaces part number WHT000909
              # 025
              MPN: N10124308
              OVAL HEXAGON SOCKET HEAD BOLT
              M6X20
              from £1.16
              from £1.16
              This part replaces part number N10124303
              # 026
              MPN: WHT000127
              HEXAGON NUT
              M8
              from £10.59
              from £10.59
              # 027
              MPN: 8Z0837691C
              HEXAGON SOCKET HEAD PANEL BOLT
              5X22
              from £0.90
              from £0.90
              # 028
              MPN: 4G0831401A
              DOOR HINGE
              LEFT UPPER
              from £15.20
              from £15.20
              # 028
              MPN: 4G0831402A
              DOOR HINGE
              RIGHT UPPER
              from £15.20
              from £15.20
              # 029
              MPN: 4G0831401B
              DOOR HINGE
              LEFT LOWER
              from £28.06
              from £28.06
              # 029
              MPN: 4G0831402B
              DOOR HINGE
              RIGHT LOWER
              from £15.43
              from £15.43
              # 030
              MPN: 4T0831329B
              HINGE REINFORCEMENT
              LEFT UPPER
              from £49.03
              from £49.03
              # 030
              MPN: 4T0831330B
              HINGE REINFORCEMENT
              RIGHT UPPER
              from £49.03
              from £49.03
              # 031
              MPN: 4T0831333B
              HINGE REINFORCEMENT
              LEFT LOWER
              from £49.03
              from £49.03
              # 031
              MPN: 4T0831334B
              HINGE REINFORCEMENT
              RIGHT LOWER
              from £49.03
              from £49.03
              # 032
              MPN: 8H0831701
              HEX SOCKET HEAD COLLARED BOLT
              M10X34
              from £1.21
              from £1.21
              # 033
              MPN: 4T7837901B
              TRIM FOR DOOR WINDOW FRAME
              LEFT
              from £256.80
              from £256.80
              # 033
              MPN: 4T7837902B
              TRIM FOR DOOR WINDOW FRAME
              RIGHT
              from £466.91
              from £466.91
              # 034
              MPN: N91138701
              HEXAGON BOLT WITH INNER HEX ROUND HEAD (COMBI)
              M5X30
              from £0.59
              from £0.59
              # 035
              MPN: N10595002
              ROUND HD. SCREW
              M5X18
              from £0.95
              from £0.95
              # 036
              MPN: 4T7837173
              BUSH
              from £21.84
              from £21.84
              # 037
              MPN: 433857445C
              INSULATION STRIP
              55X1X25
              from £11.72
              from £11.72
              # 038
              MPN: 8E0837485C
              CLIP
              from £0.74
              from £0.74
              # 039
              MPN: 4T7868382
              SEAL
              from £10.99
              from £10.99
              # 040
              MPN: 8T0837947
              COVER CAP
              from £0.70
              from £0.70
