lamborghini lp610-4 coupe (2016) for parking brake parts diagram

609.01.00 - FOR PARKING BRAKE

Lamborghini LP610-4 COUPE (2016) FOR PARKING BRAKE Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Price
    # 001
    MPN: 4S0615403E
    BRAKE CALIPER HOUSING WITH SERVOMOTOR
    LEFT REAR
    Supersession
    Supersession
    # 001
    MPN: 4S0615404E
    BRAKE CALIPER HOUSING WITH SERVOMOTOR
    RIGHT REAR
    from £640.70
    from £640.70
    # 002
    MPN: N91105601
    HEX COLLARED BOLT
    M10X85
    from £2.68
    from £2.68
    # 003
    MPN: 4T0698451A
    1 SET OF BRAKE PADS FOR DISK BRAKE ECO
    Supersession
    Supersession
    # 004
    -
    WHEEL BEARING HOUSING
    # 005
    MPN: 4S0698269
    1 SET ATTACHMENT PARTS
    TRW REAR
    from £24.30
    from £24.30
