lamborghini lp610-4 coupe (2018) individual parts for 3 parts diagram

145.01.00 - INDIVIDUAL PARTS FOR 3

Lamborghini LP610-4 COUPE (2018) INDIVIDUAL PARTS FOR 3 Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
          #
          Part number
          Description
          Price
          # 001
          MPN: 07L903137T
          POLY-V-BELT
          17,8X970MM
          from £52.40
          from £52.40
          # 002
          MPN: 07L105251AA
          VIBRATION DAMPER
          from £423.68
          from £423.68
          This part replaces part number 07L105251T
          # 003
          MPN: 07L903805AB
          BRACKET FOR ALTERNATOR
          from £68.25
          from £68.25
          # 004
          -
          ALTERNATOR
          SEE ILLUSTRATION : 903.01
          # 005
          MPN: 07L903133G
          TENSIONING ROLLER WITH SECURING PARTS
          from £104.86
          from £104.86
          # 006
          MPN: 07L903389B
          IDLER PULLEY
          from £107.65
          from £107.65
          # 007
          MPN: N91151001
          SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD
          M10X50
          from £2.90
          from £2.90
          # 008
          MPN: N91057501
          SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD
          M10X65X45
          from £1.00
          from £1.00
          # 009
          MPN: N10610001
          HEX COLLARED BOLT
          M8X90
          from £2.47
          from £2.47
          # 010
          MPN: N91131202
          SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD
          M8X30
          from £1.87
          from £1.87
          # 011
          MPN: N90440003
          HEXAGON HEAD BOLT (COMBI)
          M8X35
          from £1.58
          from £1.58
