lamborghini lp610-4 coupe (2018) seat parts diagram

881.01.00 - SEAT

Lamborghini LP610-4 COUPE (2018) SEAT Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
      #
      Part number
      Description
      Price
      # 001
      -
      SEAT, COMPLETE
      FOR STANDARD TRIM SEE ILLUSTRATION : 881.04
      # 002
      -
      SEAT
      SPORT MONO- SHELL - SEE ILLUSTRATION 881.07
      # 003
      -
      SEAT BACK TRIM
      SEE ILLUSTRATION : 881.02
      # 004
      MPN: N91229401
      HEXAGON BOLT
      M10X25
      from £10.21
      from £10.21
      # 005
      -
      SEAT
      SEE REF.13
      # 006
      MPN: 4T0959777
      SWITCH FOR BACKREST ADJUSTING
      LEFT
      from £71.77
      from £71.77
      # 006
      MPN: 4T0959778
      SWITCH FOR BACKREST ADJUSTING
      RIGHT
      from £61.83
      from £61.83
      # 006
      MPN: 8K0959747
      SWITCH FOR SEAT LONGITUDINAL- SEAT HEIGHT- SEAT RAKE AND BACKREST ADJUSTMENT
      LEFT
      from £77.30
      from £77.30
      # 006
      MPN: 8K0959748C
      SWITCH FOR SEAT LONGITUDINAL- SEAT HEIGHT- SEAT RAKE AND BACKREST ADJUSTMENT
      RIGHT
      from £77.30
      from £77.30
      # 007
      MPN: 8K09598154PK
      SETTING KNOB
      ELECTRIC - LEFT-SOUL (BLACK)
      from £23.05
      from £23.05
      # 007
      MPN: 8K09598164PK
      SETTING KNOB
      ELECTRIC - RIGHT-SOUL (BLACK)
      from £5.66
      from £5.66
      # 008
      MPN: 8K09598174PK
      SETTING KNOB
      LEFT-SOUL (BLACK)
      from £23.05
      from £23.05
      # 008
      MPN: 8K09598184PK
      SETTING KNOB
      RIGHT-SOUL (BLACK)
      from £5.66
      from £5.66
      # 009
      MPN: 4H0959777A
      SWITCH FOR LUMBAR SUPPORT ADJUSTMENT
      ONLY FOR FULL ELECTRIC VERSION
      from £47.30
      from £47.30
      # 010
      -
      SIDE AIRBAG UNIT
      NOT SOLD SEPARATELY - ORDER COMPLETE SEAT
      # 011
      MPN: 4T0898400
      HEXAGON BOLT
      from £0.99
      from £0.99
      # 012
      MPN: 4T0898400G
      FASTENING CLIP
      from £3.38
      from £3.38
      # 013
      MPN: 4T0898039B
      COVER FOR SEAT ADJUSTMENT
      LEFT
      from £222.22
      from £222.22
      # 013
      MPN: 4T0898040B
      COVER FOR SEAT ADJUSTMENT
      RIGHT
