105.01.00 - crankshaft with bearings
Lamborghini LP610-4 Coupe (2019) CRANKSHAFT WITH BEARINGS Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 07L105101BC
crankshaft
Supersession
Supersession
# 002
MPN: 07L198401F
1 SET: CONNECTING RODS
Supersession
Supersession
# 003
MPN: WHT004562
BOLT - CONNECTING ROD
M9X1X50
from £8.39
from £8.39
# 004
MPN: 07L105701KGLB
CONNECTING ROD BEARING SHELL
1,396-YELLOW
Supersession
Supersession
This part replaces part number 07L105701K
# 005
MPN: 079105561BEBLA
BEARING SHELL
Blue
from £41.28
from £41.28
# 005
MPN: 079105561BEGLB
BEARING SHELL
Yellow
from £41.28
from £41.28
# 005
MPN: 079105561BEGRN
BEARING SHELL
Green
from £41.28
from £41.28
# 005
MPN: 079105561BEROT
BEARING SHELL
red
from £63.46
from £63.46
# 005
MPN: 079105561BESWA
BEARING SHELL
Black
from £41.28
from £41.28
# 006
MPN: 079105591BEBLA
BEARING SHELL
Blue
from £21.15
from £21.15
# 006
MPN: 079105591BEGLB
BEARING SHELL
Yellow
from £21.15
from £21.15
# 006
MPN: 079105591BEGRN
BEARING SHELL
Green
from £21.15
from £21.15
# 006
MPN: 079105591BEROT
BEARING SHELL
red
from £21.15
from £21.15
# 006
MPN: 079105591BESWA
BEARING SHELL
Black
from £21.15
from £21.15
# 007
MPN: 078198421
1 SET OF THRUST WASHERS
from £27.63
from £27.63
# 008
-
BALL BEARING
# 009
-
SECURING RING
# 010
-
VIBRATION DAMPER
# 011
MPN: N91131202
SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD
M8X30
from £2.04
from £2.04
