lamborghini performante coupe (2020) ignition system parts diagram

905.01.00 - IGNITION SYSTEM

Lamborghini PERFORMANTE COUPE (2020) IGNITION SYSTEM Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 001
            MPN: 4S8971713A
            HARNESS FOR ENGINE COMPARTMENT
            from £2,258.38
            from £2,258.38
            HARNESS,ENGINE 5,2L V10 FSI DL800 Genuine Lamborghini - New (to order)
            # 002
            MPN: N10464802
            OVAL HEXAGON SOCKET HEAD BOLT
            4X12
            from £0.47
            from £0.47
            PAN HEAD SCREW W. TP4X12-S2-L Genuine Lamborghini - New In stock
            OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
            # 003
            MPN: WHT001999
            CABLE TIE WITH TERMINAL SOCKET
            4,6X200 3,0-6,0MM OUTER
            from £1.47
            from £1.47
            CABLE TIE BASE 200.00X4.00-45.00 Genuine Lamborghini - New (to order)
            # 004
            MPN: 5M0971838
            CABLE TIE WITH TERMINAL SOCKET
            4,6X200MM
            from £1.73
            from £1.73
            CABLE TIE BASE L-4.6X193 Genuine Lamborghini - New In stock
            # 005
            MPN: N91123701
            CLAMP
            1-40X15
            from £2.94
            from £2.94
            RETAINING CLAMP D1-40X15 Genuine Lamborghini - New (to order)
            CLAMP Genuine Porsche Part - New (to order)
            # 006
            MPN: N90833202
            HEXAGON BOLT
            M6X22
            from £0.54
            from £0.54
            DUO HEXAGON FLANGEM6X22 Genuine Lamborghini - New (to order)
            DUO HEXAGON FLANGEM6X22 Genuine Lamborghini - New (other) In stock
            BOLT
            # 007
            MPN: N10646101
            CABLE TIES
            from £0.65
            from £0.65
            CABLE TIE BASE A5/4.6X143 Genuine Lamborghini - New In stock
            TIE WRAP Genuine Porsche Part - New (to order)
            # 008
            MPN: 079905115B
            IGNITION COIL
            from £45.25
            from £45.25
            This part replaces part number 079905115
            IGNITION COIL Genuine Lamborghini - New (to order)
            # 009
            MPN: 07L905142
            PROTECTIVE CAP
            UPPER
            from £2.94
            from £2.94
            PROTECTIVE CAP Genuine Lamborghini - New (to order)
            # 010
            MPN: 07L905116B
            PROTECTIVE CAP
            LOWER
            from £9.56
            from £9.56
            PROTECTIVE CAP Genuine Lamborghini - New (to order)
            # 011
            MPN: 06H905601C
            SPARK PLUG 'LONGLIFE'
            from £13.66
            from £13.66
            This part replaces part number 06H905601A which we have in stock - and 2 more. Click to view details
            SPARK PLUG Genuine Lamborghini - New In stock
            SPARK PLUG Original Equipment - New In stock
            # 012
            MPN: 06E905377J
            KNOCK SENSOR WITH WIRING HARNESS
            GREEN - CYLINDER 4,5-GREEN 465MM 3 PIN
            from £52.53
            from £52.53
            SENSORE D DETONAZ. Genuine Lamborghini - New (to order)
            # 012
            MPN: 06E905377K
            KNOCK SENSOR WITH WIRING HARNESS
            GREY - CYLINDER 9, 10_-GREY 480MM
            from £50.19
            from £50.19
            SENSORE D DETONAZ. Genuine Lamborghini - New (to order)
            # 012
            MPN: 07L905377E
            KNOCK SENSOR WITH WIRING HARNESS
            ORANGE - CYLINDER 1- 3 _-565MM ORANGE
            from £30.24
            from £30.24
            KNOCK SENSOR WITH Genuine Lamborghini - New (to order)
            # 012
            MPN: 07L905377F
            KNOCK SENSOR WITH WIRING HARNESS
            BROWN - CYLINDER 6-8-590MM BROWN
            from £30.24
            from £30.24
            This part replaces part number 07L905377D
            SENSORE D DETONAZ.L1=590MM Genuine Lamborghini - New (to order)
            # 013
            MPN: N01024425
            HEXAGON BOLT
            M8X30-M8X30
            from £1.97
            from £1.97
            HEXAGON HEAD BOLT Genuine Lamborghini - New (to order)
            SCREW, HEX. HD. - M 8 X 30 Genuine Porsche Part - New (to order)
            # 014
            MPN: 4S0937539B
            BRACKET
            LEFT
            from £18.99
            from £18.99
            BRACKET E-BOX LI Genuine Lamborghini - New (to order)
            BRACKET E-BOX LI Genuine Lamborghini - Used In stock
            # 014
            MPN: 4S0937540B
            BRACKET
            RIGHT
            from £18.99
            from £18.99
            BRACKET E-BOX RE Genuine Lamborghini - New (to order)
            BRACKET E-BOX RE Genuine Lamborghini - Used In stock
            # 015
            MPN: 4S0937113A
            HOUSING FOR CONTROL UNITS
            LEFT
            from £20.61
            from £20.61
            ELECTRONICS BOX Genuine Lamborghini - New In stock
            # 015
            MPN: 4S0937114A
            HOUSING FOR CONTROL UNITS
            RIGHT
            from £20.61
            from £20.61
            ELECTRONICS BOX Genuine Lamborghini - New In stock
            # 016
            MPN: 4S0937503
            RELAY PLATE
            RIGHT
            from £14.08
            from £14.08
            RELAY PLATE Genuine Lamborghini - New (to order)
            # 016
            MPN: 4S0937507
            RELAY PLATE
            LEFT
            from £10.30
            from £10.30
            RELAY PLATE Genuine Lamborghini - New (to order)
            # 017
            MPN: 4S0937554A
            COVER
            RIGHT
            from £10.64
            from £10.64
            COVER E-BOX RE Genuine Lamborghini - New (to order)
            # 017
            MPN: 4S0937555A
            COVER
            LEFT
            from £10.64
            from £10.64
            COVER E-BOX LI Genuine Lamborghini - New (to order)
            # 018
            MPN: N90739704
            PANEL SCREW
            TP5X22-5X22
            from £0.57
            from £0.57
            SCREW TP5X22-Q Genuine Lamborghini - New In stock
            tapping screw Genuine Porsche Part - New (to order)
            # 019
            MPN: N10653201
            HEX COLLARED BOLT
            M6X16-M6X16
            from £1.13
            from £1.13
            HEXAGON FLANGE M6X16 Genuine Lamborghini - New In stock
            BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
            # 020
            MPN: N10196103
            OVAL SOCKET HEAD BOLT WITH HEX DRIVE
            M6X16-M6X18
            from £0.78
            from £0.78
            HEXALOBULAR SOCKET M6X18 Genuine Lamborghini - New In stock
            oval socket head bolt Genuine Porsche Part - New In stock
            # 021
            MPN: 04C907601K
            IMPULSE SENDER
            from £46.08
            from £46.08
            This part replaces part number 04C907601
            PULSE GENERATOR Genuine Lamborghini - New (to order)
