lamborghini jalpa 3.5 (1984) front suspension parts diagram

036 - Front Suspension

Lamborghini Jalpa 3.5 (1984) Front Suspension Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Price
    # 001
    MPN: 008200804
    NUT
    DADO N/70/108M
    from £0.69
    from £0.69
    # 002
    MPN: 008400801
    WASHER
    Rond. 8,4 UNI 1734 8G
    Supersession
    Supersession
    # 003
    MPN: 005207465
    NUT RETAIN
    Fermo dado ammortizz./U
    from £6.81
    from £6.81
    # 004
    MPN: 008201405
    NUT
    Dado 14x1,5 CH22 8G
    from £3.70
    from £3.70
    # 005
    MPN: 005207464
    GUARD
    Protez. grasso snodo sup./U
    from £5.27
    from £5.27
    # 006
    MPN: 005119407
    SHABS SUPP
    Supp. telaio x ammortizzatore
    from £360.50
    from £360.50
    # 007
    MPN: 005108658
    PLUG
    Tampone FC ammortizz. ant.
    from £115.00
    from £115.00
    # 008
    MPN: 008830119
    CLAMP RING
    Fasc. soffietto ammort./U
    from £11.37
    from £11.37
    # 009
    MPN: 005108120
    BOOT
    Soffietto stelo ammortizz.
    from £70.39
    from £70.39
    # 010
    MPN: 008830107
    CLAMP RING
    Clamp D.68/U
    from £12.90
    from £12.90
    # 011
    MPN: 008200806
    NUT
    DADO M8 UNI 5588-65/8G
    Supersession
    Supersession
    # 012
    MPN: 008410806
    LOCK WASHER
    Rond. EL. A8,4 UNI 1751
    Supersession
    Supersession
    # 013
    MPN: 005107110
    SUPPOR
    Sostegno supp. att. barra/U
    from £29.14
    from £29.14
    # 014
    MPN: 008921501
    SUPPOR
    Supp. barra tors. D.15/U
    from £8.17
    from £8.17
    # 015
    MPN: 005108224
    ROLL BAR GU
    Protez. barra tors./U
    from £64.60
    from £64.60
    # 016
    MPN: 005107450
    BAR
    Barra tors. ant. D. 15/U
    from £148.66
    from £148.66
    # 017
    MPN: 008400801
    WASHER
    Rond. 8,4 UNI 1734 8G
    Supersession
    Supersession
    # 018
    MPN: 008200804
    NUT
    DADO N/70/108M
    from £0.69
    from £0.69
    # 019
    MPN: 008800801
    BUSH
    Bush 0.8x14x25
    from £26.24
    from £26.24
    # 020
    MPN: 008921603
    BUSH RUBBER
    Saga bush 9999
    # 021
    MPN: 008100842
    BOLT
    Bull. M8x45 UNI 5737/8G
    from £0.99
    from £0.99
    # 022
    MPN: 005113379
    JOINT
    Art. x barra tors. ant. 5/S
    from £10.20
    from £10.20
    # 022
    MPN: 005113380
    JOINT
    Art. x barra tors. ant. D/S
    from £10.20
    from £10.20
    # 023
    MPN: 008101031
    BOLT
    Bull. M10x25 UNI 5739/8G
    Supersession
    Supersession
    # 024
    MPN: 005206915
    SUPPOR
    Supp. Sup. molle post./U
    from £8.57
    from £8.57
    # 025
    MPN: 005207451
    SPRING RING
    Anello supp. molla ammort.
    from £35.61
    from £35.61
    # 026
    MPN: 005108657
    SPRING
    Molla sosp. ant. D.12/U
    from £191.53
    from £191.53
    # 026
    MPN: 005113358
    SPRING
    (Valid for the first 60 cars only) Molla Sosp. ant./S
    from £177.43
    from £177.43
    # 027
    MPN: 008100821
    BOLT
    Bull. M8x25 UNI 5739 10K
    Supersession
    Supersession
    # 028
    MPN: 008200804
    NUT
    DADO N/70/108M
    from £0.71
    from £0.71
    # 029
    MPN: 005207821
    ROD
    Tir. sosp. 027024503251 2/U
    from £769.42
    from £769.42
    # 030
    MPN: 008201008
    NUT
    DADO B/70/210M
    from £0.55
    from £0.55
    # 031
    MPN: 008200804
    NUT
    DADO N/70/108M
    from £0.69
    from £0.69
    # 032
    MPN: 008400801
    WASHER
    Rond. 8,4 UNI 1734 8G
    Supersession
    Supersession
    # 033
    MPN: 008101609
    BOLT
    Bull. 16x1,5x80 CH24 10K
    from £105.81
    from £105.81
    # 034
    MPN: 008921602
    SILENT BLOC
    Estendbloc Riv-89801573 U
    from £72.02
    from £72.02
    # 035
    MPN: 005106982
    FRONT ARM
    Braccio inf. ant. des./sin./U
    from £227.19
    from £227.19
    # 036
    MPN: 008401611
    WASHER
    Rond. 17x29x3 5S UNI 16592
    from £8.84
    from £8.84
    # 037
    MPN: 008201603
    NUT
    Dado 8/70/21 6x1, 5M
    from £2.25
    from £2.25
    # 038
    MPN: 005119530
    RH FRONT SHOCK ABSORBER
    from £3,990.33
    from £3,990.33
    # 038
    MPN: 005119531
    LH FRONT SHOCK ABSORBER
    from £3,990.33
    from £3,990.33
    # 039
    MPN: 008201008
    NUT
    DADO B/70/210M
    from £0.55
    from £0.55
    # 040
    MPN: 008401006
    WASHER
    Rond. A10.5 UNI 1734
    from £0.53
    from £0.53
    # 041
    MPN: 008101032
    BOLT
    Bull. 10x1,5x55 CH17 10K
    from £4.73
    from £4.73
    # 042
    MPN: 008100809
    BOLT
    Bull. M8x22 UNI 5739/8G
    from £0.52
    from £0.52
    # 043
    MPN: 005106906
    BALL, JOINT
    Snodo 0270145013512 sosp.
    from £201.90
    from £201.90
