lamborghini revuelto coupe (2024) bumper front parts diagram

807.02.00 - BUMPER FRONT

Lamborghini Revuelto Coupe (2024) BUMPER FRONT Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 001
            MPN: 47B807429BGRU
            PRIMED
            BASE
            from £3,502.07
            from £3,502.07
            BUMPER, PRIMED Genuine Lamborghini - New (to order)
            # 001
            MPN: 47B807429CGRU
            PRIMED
            FRONT CAMERA + PLA
            from £3,567.48
            from £3,567.48
            BUMPER, PRIMED Genuine Lamborghini - New (to order)
            # 002
            MPN: 47B807677A
            BRACKET
            from £34.64
            from £34.64
            STAFFA Genuine Lamborghini - New (to order)
            # 003
            MPN: 47B807317
            REINFORCEMENT
            from £86.97
            from £86.97
            REINFORCEMENT Genuine Lamborghini - New (to order)
            # 004
            MPN: 47B807692
            BRACKET
            from £20.06
            from £20.06
            SUPPORTO TOP VIEW CAMERA Genuine Lamborghini - New (to order)
            # 005
            -
            CONN. FROM FRONT OVERH VIEW CAMERA TO FRONT BUMPER COUPLING POINT
            SEE ILLUSTRATION : 907.01
            # 006
            MPN: 47B919261B98
            SATIN BLACK
            LEFT, MATT
            from £147.85
            from £147.85
            SENSOR BRACKET Genuine Lamborghini - New (to order)
            # 006
            MPN: 47B919261Y9B
            BRILLIANT BLACK
            LEFT, SHINY
            from £147.85
            from £147.85
            SENSOR BRACKET Genuine Lamborghini - New (to order)
            # 006
            MPN: 47B919262B98
            SATIN BLACK
            RIGHT, MATT
            from £147.85
            from £147.85
            SENSOR BRACKET Genuine Lamborghini - New (to order)
            # 006
            MPN: 47B919262Y9B
            BRILLIANT BLACK
            RIGHT, MATT
            from £147.85
            from £147.85
            SENSOR BRACKET Genuine Lamborghini - New (to order)
            # 007
            -
            SENSOR
            SEE ILLUSTRATION : 919.01
            # 008
            -
            SENSOR
            SEE ILLUSTRATION : 919.01
            # 009
            -
            BRACKET
            NOT AVAILABLE SEPARATELY
            # 010
            MPN: N90698605
            HEXAGON SOCKET HEAD PANEL BOLT
            ST4,2X16
            from £0.47
            from £0.47
            HEXAGON SOCKET HEAD PANEL BOLT, M4.2 x 16 Genuine Lamborghini - New In stock
            HEXAGON SOCKET HEAD PANEL BOLT Genuine Porsche Part - New (to order)
            HEXAGON SOCKET HEAD PANEL BOLT Genuine Bentley Part - New (to order)
            # 011
            MPN: 8T0853107
            CLIP
            from £0.47
            from £0.47
            CLAMP Genuine Lamborghini - New (to order)
            CLAMP Genuine Porsche Part - New (to order)
            CLIP Genuine Bentley Part - New (to order)
            # 012
            MPN: N90475903
            SPEED NUT
            M5X13,6X11,5
            from £0.64
            from £0.64
            SNAP NUT CLAMP M5 X 13.6 X 11.5 Genuine Lamborghini - New In stock
            SPEED NUT Genuine Porsche Part - New (to order)
            SPEED NUT Genuine Bentley Part - New (to order)
            # 013
            MPN: 47B807897
            ADJUSTMENT PART
            from £4.98
            from £4.98
            ADJUSTMENT PART Genuine Lamborghini - New (to order)
            # 014
            MPN: N90688703
            SPEED NUT
            M6X24X16
            from £0.64
            from £0.64
            SNAP NUT CLAMP M6 x 23.8 x 16 Genuine Lamborghini - New In stock
            SPEED NUT Genuine Porsche Part - New (to order)
            SPEED NUT Genuine Bentley Part - New (to order)
            # 015
            MPN: N90986802
            HEXAGON SOCKET HEAD PANEL BOLT
            4,2X13
            from £0.47
            from £0.47
            FLANGE TAPPING Genuine Lamborghini - New (to order)
            HEXAGON SOCKET HEAD PANEL BOLT Genuine Porsche Part - New (to order)
            HEXAGON SOCKET HEAD PANEL BOLT Genuine Bentley Part - New (to order)
            # 016
            MPN: N10725401
            HEXAGON SOCKET HEAD COLLARED BOLT, THREAD FORMING
            M6X20
            from £0.72
            from £0.72
            HEXALOBULAR SOCKETM6GFX20 Genuine Lamborghini - New (to order)
            HEXAGON SOCKET HEAD COLLARED Genuine Porsche Part - New In stock
            HEXAGON SOCKET HEAD COLLARED BOLT, THREAD FORMING Genuine Bentley Part - New (to order)
            # 017
            MPN: 47B919291
            BRACKET FOR DISTANCE MEASURING SENSOR
            LEFT, NOT FOR VERTICAL FIN CARBON
            from £212.40
            from £212.40
            MOUNTING,SENSOR Genuine Lamborghini - New (to order)
            # 017
            MPN: 47B919291A
            BRACKET FOR DISTANCE MEASURING SENSOR
            LEFT, FOR VERTICAL FIN CARBON
            from £212.40
            from £212.40
            BRACKET FOR DISTANCE MEASURING Genuine Lamborghini - New (to order)
            # 017
            MPN: 47B919292
            BRACKET FOR DISTANCE MEASURING SENSOR
            RIGHT, NOT FOR VERTICAL FIN CARBON
            from £212.40
            from £212.40
            MOUNTING,SENSOR Genuine Lamborghini - New (to order)
            # 017
            MPN: 47B919292A
            BRACKET FOR DISTANCE MEASURING SENSOR
            RIGHT, FOR VERTICAL FIN CARBON
            from £212.40
            from £212.40
            BRACKET FOR DISTANCE MEASURING Genuine Lamborghini - New (to order)
