lamborghini revuelto coupe (2024) sensor rotor parts diagram

927.01.00 - SENSOR ROTOR

Lamborghini Revuelto Coupe (2024) SENSOR ROTOR Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
      #
      Part number
      Description
      Key
      Price
      # 001
      MPN: 47B311675
      POSITION SENSOR
      from £159.19
      from £159.19
      POSITIONSSENSOR Genuine Lamborghini - New (to order)
      # 002
      MPN: 47B141297
      SPEED SENSOR
      from £233.76
      from £233.76
      SPEED SENSOR Genuine Lamborghini - New (to order)
      # 003
      -
      CONNECTOR
      NOT AVAILABLE SEPARATELY
      # 004
      MPN: 06H906433E
      IMPULSE SENDER
      3 PIN
      from £73.18
      from £73.18
      PULSE GENERATOR RSCD5 Genuine Lamborghini - New (to order)
      # 005
      MPN: N91096701
      OVAL HEXAGON SOCKET HEAD BOLT
      M6X16
      from £0.64
      from £0.64
      HEXALOBULAR SOCKET M6X16 Genuine Lamborghini - New In stock
      OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
      OVAL HEXAGON SOCKET HEAD BOLT Genuine Bentley Part - New (to order)
      # 006
      MPN: N10766201
      HEXAGON SOCKET FLAT HEAD BOLT
      M6X12
      from £0.59
      from £0.59
      HEXALOBULAR SOCKET PAN HEAD SCREW Genuine Lamborghini - New (to order)
      HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
      HEXAGON SOCKET FLAT HEAD BOLT Genuine Bentley Part - New (to order)
      # 007
      MPN: N10653801
      HEXAGON SOCKET HEAD BOLT
      M5X8.0
      from £0.54
      from £0.54
      HEXALOBULAR SOCKETM5X8 Genuine Lamborghini - New (to order)
      HEXAGONAL SOCKET HEAD Genuine Porsche Part - New (to order)
      HEXAGON SOCKET HEAD BOLT Genuine Bentley Part - New (to order)
      # 008
      -
      GEARBOX
      SEE ILLUSTRATION : 300.01
