lamborghini revuelto coupe (2024) high voltage wire for elec- tric a/c compressor lhd parts diagram

970.01.00 - HIGH VOLTAGE WIRE FOR ELEC- TRIC A/C COMPRESSOR LHD

Lamborghini Revuelto Coupe (2024) HIGH VOLTAGE WIRE FOR ELEC- TRIC A/C COMPRESSOR LHD Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 001
MPN: 47A971109
HIGH VOLTAGE WIRE FOR ELEC- TRIC A/C COMPRESSOR
VALID FOR VEHICLE WITHOUT PTC (EUROPE, USA spec vehicles)
from £455.93
from £455.93
HIGH VOLTAGE WIRE FOR ELEC- TRIC A/C COMPRESSOR Genuine Lamborghini - New (to order)
# 002
MPN: 47A971109B
HIGH VOLTAGE WIRE FOR ELEC- TRIC A/C COMPRESSOR
VALID FOR VEHICLE WITH PTC (EUROPE, USA spec vehicles)
from £808.39
from £808.39
HIGH VOLTAGE WIRE FOR ELEC- TRIC A/C COMPRESSOR Genuine Lamborghini - New (to order)
# 003
MPN: 47B915924C
HIGH-VOLTAGE WIRING SET FOR CHARGING SOCKET
TYPE 1 (EUROPE, USA spec vehicles)
from £2,570.62
from £2,570.62
HIGH-VOLTAGE WIRING SET FOR CHARGING SOCKET Genuine Lamborghini - New (to order)
# 003
MPN: 47B915924D
HIGH-VOLTAGE WIRING SET FOR CHARGING SOCKET
TYPE 2 (EUROPE, USA spec vehicles)
from £1,873.49
from £1,873.49
HIGH-VOLTAGE WIRING SET FOR CHARGING SOCKET Genuine Lamborghini - New (to order)
# 004
MPN: 47A907907
BRACKET
(EUROPE, USA spec vehicles)
from £139.41
from £139.41
BRACKET Genuine Lamborghini - New (to order)
# 008
MPN: 47B971061
HIGH-VOLTAGE WIRING SET FOR HIGH-VOLTAGE BATTERY
(EUROPE, USA spec vehicles)
from £670.66
from £670.66
HIGH-VOLTAGE WIRING SET FOR HIGH-VOLTAGE BATTERY Genuine Lamborghini - New (to order)
# 010
MPN: 47A907102B
BRACKET
(EUROPE, USA spec vehicles)
from £80.51
from £80.51
BRACKET Genuine Lamborghini - New (to order)
# 011
MPN: 47A907102J
BRACKET
(EUROPE, USA spec vehicles)
from £20.53
from £20.53
BRACKET Genuine Lamborghini - New (to order)
# 012
MPN: N90937701
CABLE TIES
4.6X193 OUTER (EUROPE, USA spec vehicles)
from £1.12
from £1.12
CLIP Genuine Lamborghini - New In stock
TIE WRAP Genuine Porsche Part - New (to order)
# 013
MPN: N10017304
HEXAGON COLLAR NUT
M5 (EUROPE, USA spec vehicles)
from £1.08
from £1.08
HEXAGON FLANGE NUT M5 Genuine Lamborghini - New In stock
shouldered hex. nut Genuine Porsche Part - New (to order)
# 014
MPN: 3Q0971897
CABLE TIE WITH HOSE RETAINER
(EUROPE, USA spec vehicles)
from £2.68
from £2.68
CABLE TIE WITH HOSE RETAINER Genuine Lamborghini - New (to order)
# 015
MPN: 3D0971838K
CABLE TIES WITH BRACKET
(EUROPE, USA spec vehicles)
from £0.81
from £0.81
CABLE TIE Genuine Lamborghini - New In stock
# 016
MPN: 3D0971838A
CABLE TIE WITH HOLDER FOR WELD PIN:
5X200MM 5MM (EUROPE, USA spec vehicles)
from £1.92
from £1.92
CABLE TIE BASE 193.00X4.60X5.00 Genuine Lamborghini - New (to order)
# 017
MPN: N10677601
CABLE TIE WITH HOSE RETAINER
(EUROPE, USA spec vehicles)
from £1.69
from £1.69
CABLE TIE WITH HOSE RETAINER Genuine Lamborghini - New (to order)
BRACKET Genuine Porsche Part - New (to order)
# 018
MPN: 3D0971838N
CABLE TIES WITH BRACKET
(EUROPE, USA spec vehicles)
from £0.71
from £0.71
CABLE TIE BASE 6.50X193.00 Genuine Lamborghini - New In stock
# 019
MPN: N10879701
TORX LENS FLANGE SCREW
(EUROPE, USA spec vehicles)
from £0.54
from £0.54
TORX LENS FLANGE SCREW Genuine Lamborghini - New (to order)
# 020
MPN: N90944604
OVAL HEXAGON SOCKET HEAD BOLT
M5X12 (EUROPE, USA spec vehicles)
from £0.95
from £0.95
HEXALOBULAR SOCKETM5X12 Genuine Lamborghini - New In stock
OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
# 021
MPN: 3D0971838F
CABLE TIE WITH HOLDER FOR WELD PIN:
5 (EUROPE, USA spec vehicles)
from £1.87
from £1.87
CABLE TIE BASE Genuine Lamborghini - New In stock
