lamborghini sian (2021) suspension front parts diagram

407.01.00 - SUSPENSION FRONT

Lamborghini SIAN (2021) SUSPENSION FRONT Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
      #
      Part number
      Description
      Key
      Price
      # 001
      -
      WHEEL BEARING HOUSING
      # 002
      MPN: WHT005396
      THREADED PIN
      M10X1,25- M10X45
      from £18.03
      from £18.03
      TAP END STUD Genuine Lamborghini - New (to order)
      # 003
      MPN: N10272302
      HEXAGON COLLAR NUT SELF-LOCKING
      M10
      from £1.32
      from £1.32
      PREV.TORQUE TYPE M10 Genuine Lamborghini - New In stock
      SHOULDERED HEX. NUT, Genuine Porsche Part - New In stock
      # 004
      MPN: WHT004898
      HEXAGON COLLAR NUT SELF-LOCKING
      M14X1,5
      from £3.77
      from £3.77
      HEXAGON FLANGE NUT M14X1.5 Genuine Lamborghini - New (to order)
      SHOULDERED HEX. NUT, Genuine Porsche Part - New (to order)
      # 005
      MPN: N10736901
      HEXAGON BOLT
      M12X1,5X95
      from £47.30
      from £47.30
      HEXAGON FLANGE BOLT Genuine Lamborghini - New (to order)
      # 006
      MPN: N10106402
      HEXAGON COLLAR NUT SELF-LOCKING
      M12X1,5
      from £1.34
      from £1.34
      PREV.TORQUE TYPE M12X1.5 Genuine Lamborghini - New In stock
      SHOULDERED HEX. NUT, Genuine Porsche Part - New In stock
      # 007
      MPN: 470407505G
      WISHBONE
      LEFT UPPER
      from £370.93
      from £370.93
      CONTROL ARM,FRONT ANT.SUP.SX Genuine Lamborghini - New In stock
      CONTROL ARM,FRONT ANT.SUP.SX Genuine Lamborghini - Used In stock
      # 007
      MPN: 470407506G
      WISHBONE
      RIGHT UPPER
      from £370.93
      from £370.93
      CONTROL ARM,FRONT ANT. SUP.DX Genuine Lamborghini - New In stock
      CONTROL ARM,FRONT ANT. SUP.DX Genuine Lamborghini - Used In stock
      # 008
      MPN: N91055501
      OVAL HEXAGON SOCKET HEAD BOLT
      M5X12
      from £0.50
      from £0.50
      This part replaces part number N10459201 - and 1 more. Click to view details
      HEXALOBULAR SOCKETM5GFSX12 Genuine Lamborghini - New (to order)
      HEXALOBULAR SOCKETM5GFSX12 Genuine Lamborghini - New (other) In stock
      SCREW
      # 009
      MPN: N10714801
      OVAL HEXAGON SOCKET HEAD BOLT
      M6X18
      from £0.54
      from £0.54
      HEXALOBULAR SOCKETM6X18 Genuine Lamborghini - New In stock
      OVAL HEXAGON SOCKET HEAD BOLT Genuine Porsche Part - New (to order)
      # 010
      MPN: N10434301
      SOCKET HEAD BOLT
      M5X10
      from £0.57
      from £0.57
      PAN HEAD BOLT Genuine Lamborghini - New (to order)
      SCREW, CHEESE HD. Genuine Porsche Part - New (to order)
      # 011
      MPN: N01118312
      HEXAGON NUT, SELF-LOCKING
      M6
      from £1.32
      from £1.32
      This part replaces part number 008200606
      PREV.TORQUE TYPE M6 Genuine Lamborghini - New In stock
      HEX. NUT, SELF-LOCKING Genuine Porsche Part - New (to order)
      # 012
      MPN: N10640301
      HEX COLLARED BOLT
      M12X1,5X100
      from £4.45
      from £4.45
      HEXAGON FLANGE BM12X1.5X100X90 Genuine Lamborghini - New (to order)
      BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
      # 013
      MPN: 470407151H
      WISHBONE
      CONTACT YOUR AREA MANAGER-LEFT LOWER
      from £523.11
      from £523.11
      track control arm Genuine Lamborghini - New (to order)
      track control arm Genuine Lamborghini - Used In stock
      # 013
      MPN: 470407152H
      WISHBONE
      CONTACT YOUR AREA MANAGER-RIGHT LOWER
      from £523.11
      from £523.11
      track control arm Genuine Lamborghini - New (to order)
      track control arm Genuine Lamborghini - Used In stock
      # 014
      MPN: WHT005397
      THREADED PIN
      M10X1,25 - M10X39
      from £24.30
      from £24.30
      TAP END STUD Genuine Lamborghini - New (to order)
      # 015
      MPN: 470407203E
      BALANCING PLATE
      3 MM
      from £12.62
      from £12.62
      BACKING PLATE SPESS.CAMBER 3,0 Genuine Lamborghini - New In stock
      # 015
      MPN: 470407203F
      BALANCING PLATE
      1 MM
      from £17.12
      from £17.12
      SHIM SPESS.CAMBER 1 Genuine Lamborghini - New In stock
      # 015
      MPN: 470407203G
      BALANCING PLATE
      0,5 MM
      from £16.87
      from £16.87
      0.5 Shim Plate Genuine Lamborghini - New In stock
      # 016
      MPN: 47F413383
      INSULATION STRIP
      from £1,884.93
      from £1,884.93
      PUSH ROD Genuine Lamborghini - New (to order)
      # 017
      MPN: 470971003
      BRACKET
      LEFT
      from £29.63
      from £29.63
      CABLE HOLDER Genuine Lamborghini - New (to order)
      # 017
      MPN: 470971004
      BRACKET
      RIGHT
      from £29.63
      from £29.63
      CABLE HOLDER Genuine Lamborghini - New (to order)
      # 018
      MPN: 470611845
      BRACKET
      from £7.97
      from £7.97
      BRACKET,BRAKE HOSE Genuine Lamborghini - New (to order)
      BRACKET,BRAKE HOSE Genuine Lamborghini - Used In stock
      # 019
      MPN: 470611851B
      BRACKET
      LEFT
      from £6.57
      from £6.57
      BRACKET,BRAKE LINEPOTENZIOMETRI Genuine Lamborghini - New (to order)
      BRACKET,BRAKE LINEPOTENZIOMETRI Genuine Lamborghini - Used In stock
      # 019
      MPN: 470611852B
      BRACKET
      RIGHT
      from £11.51
      from £11.51
      BRACKET,BRAKE LINEPOTENZIOMETRI Genuine Lamborghini - New (to order)
      # 020
      MPN: 470941273A
      POSITION SENSOR
      LEFT AND RIGHT
      from £40.23
      from £40.23
      SENSOR,HEADLIGHT- ASS.POTENZIOMETRO Genuine Lamborghini - New (to order)
      SENSOR,HEADLIGHT- ASS.POTENZIOMETRO Genuine Lamborghini - Used In stock
      # 021
      MPN: 470941287E
      BRACKET
      LEFT FRONT
      from £5.52
      from £5.52
      RETAINING PART SENSORE LIFTING Genuine Lamborghini - New (to order)
      RETAINING PART SENSORE LIFTING Genuine Lamborghini - Used In stock
      # 021
      MPN: 470941288E
      BRACKET
      RIGHT FRONT
      from £120.79
      from £120.79
      RETAINING PART SENSORE LIFTING Genuine Lamborghini - New (to order)
      RETAINING PART SENSORE LIFTING Genuine Lamborghini - Used In stock
      # 022
      -
      GAS SHOCK ABSORBER, ELECTRONICALLY CONTROLLED
