lamborghini urus performante (2023) exhaust gas turbocharger parts diagram

145.05.00 - EXHAUST GAS TURBOCHARGER

Lamborghini Urus Performante (2023) EXHAUST GAS TURBOCHARGER Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 001
            -
            1 SET OF VACUUM PIPES
            # 002
            -
            VACUUM HOSE
            # 002
            MPN: 0P2131612G
            VACUUM HOSE
            SIDE, RIGHT
            from £11.94
            from £11.94
            HOSE Genuine Lamborghini - New (to order)
            HOSE Genuine Lamborghini - Used In stock
            # 003
            -
            VACUUM HOSE
            # 003
            MPN: 0P2131611J
            VACUUM HOSE
            SIDE, LEFT
            from £12.86
            from £12.86
            HOSE Genuine Lamborghini - New (to order)
            HOSE Genuine Lamborghini - Used In stock
            # 004
            -
            VACUUM UNIT FOR EXHAUST GAS TURBOCHARGER
            # 004
            -
            VACUUM UNIT FOR EXHAUST GAS TURBOCHARGER
            # 004
            MPN: 0P2145461
            VACUUM UNIT FOR EXHAUST GAS TURBOCHARGER
            LEFT
            from £82.93
            from £82.93
            VACUUM UNIT Genuine Lamborghini - New (to order)
            # 004
            MPN: 0P2145462
            VACUUM UNIT FOR EXHAUST GAS TURBOCHARGER
            RIGHT
            from £83.18
            from £83.18
            VACUUM UNIT Genuine Lamborghini - New (to order)
            # 005
            -
            VACUUM PIPE
            # 005
            MPN: 0P2131051
            VACUUM PIPE
            from £9.34
            from £9.34
            VACUUM HOSE Genuine Lamborghini - New (to order)
            VACUUM HOSE Genuine Lamborghini - Used In stock
            # 005
            MPN: 0P2131051A
            VACUUM PIPE
            VACUUM PIPE Genuine Lamborghini - New (to order)
            # 006
            -
            EXHAUST GAS TURBOCHARGER
            # 006
            MPN: 0P2145654C
            EXHAUST GAS TURBOCHARGER
            RIGHT
            from £946.35
            from £946.35
            Turbocharger Genuine Lamborghini - New (to order)
            Turbocharger Genuine Lamborghini - Used In stock
            # 006
            MPN: 0P2145654F
            EXHAUST GAS TURBOCHARGER
            RIGHT
            from £1,699.03
            from £1,699.03
            EXHAUST GAS TURBOCHARGER Genuine Lamborghini - New (to order)
            # 007
            -
            EXHAUST GAS TURBOCHARGER
            # 007
            MPN: 0P2145653C
            EXHAUST GAS TURBOCHARGER
            LEFT
            from £946.35
            from £946.35
            Turbocharger Genuine Lamborghini - New (to order)
            Turbocharger Genuine Lamborghini - Used In stock
            # 007
            MPN: 0P2145653F
            EXHAUST GAS TURBOCHARGER
            LEFT
            from £1,720.64
            from £1,720.64
            EXHAUST GAS TURBOCHARGER Genuine Lamborghini - New (to order)
            # 008
            -
            VACUUM PUMP
            # 009
            -
            oil pressure line
            # 009
            MPN: 0P2145140A
            oil pressure line
            FEED
            from £55.40
            from £55.40
            OIL FEED LINE Genuine Lamborghini - New (to order)
            OIL FEED LINE Genuine Lamborghini - Used In stock
            # 010
            -
            CLAMP
            # 010
            MPN: 0P2253725B
            CLAMP
            from £32.61
            from £32.61
            CLAMP Genuine Lamborghini - New (to order)
            # 011
            MPN: N10413405
            HEXAGON SOCKET FLAT HEAD BOLT
            M6X25
            from £0.97
            from £0.97
            HEXALOB.SOCKET PAN HEAD SCREW Genuine Lamborghini - New In stock
            Hexagon socket flat (N 10413405) Genuine Porsche Part - New In stock
            # 012
            MPN: WHT006537
            O-RING
            from £2.95
            from £2.95
            O-RING Genuine Lamborghini - New (to order)
            # 013
            MPN: WHT008755
            O-RING
            13X3
            from £1.98
            from £1.98
            O-RING Genuine Lamborghini - New (to order)
            # 014
            MPN: N91126601
            OVAL HEXAGON SOCKET HEAD BOLT
            M6X16
            from £0.55
            from £0.55
            HEXALOBULAR SOCKETM6X16 Genuine Lamborghini - New In stock
            Oval hexagon socket head bolt (N 91126601) Genuine Porsche Part - New (to order)
            # 015
            -
            CUT-OFF VALVE
            # 015
            MPN: 0P2145710
            CUT-OFF VALVE
            from £86.47
            from £86.47
            SHUT-OFF VALVE Genuine Lamborghini - New (to order)
            # 016
            -
            HEAT SHIELD
            # 016
            -
            HEAT SHIELD
            # 016
            MPN: 0P2145325
            HEAT SHIELD
            LEFT
            from £30.48
            from £30.48
            SHIELD Genuine Lamborghini - New (to order)
            # 016
            MPN: 0P2145326
            HEAT SHIELD
            RIGHT
            from £30.48
            from £30.48
            SHIELD Genuine Lamborghini - New (to order)
            # 017
            MPN: N10546403
            HEXAGON SOCKET HEAD BOLT
            M6X16
            from £1.28
            from £1.28
            HEXALOBULAR SOCKETM6X16 Genuine Lamborghini - New (to order)
            hexagonal socket head - screw - M 6 X 18 (N 10546403) Genuine Porsche Part - New In stock
            # 018
            -
            oil return line
            # 018
            -
            oil return line
            # 018
            MPN: 0P2145771
            oil return line
            SIDE, LEFT
            from £38.85
            from £38.85
            OIL PIPE - RETURN LINE Genuine Lamborghini - New (to order)
            OIL PIPE - RETURN LINE Genuine Lamborghini - Used In stock
            # 018
            MPN: 0P2145772
            oil return line
            SIDE, RIGHT
            from £38.85
            from £38.85
            OIL PIPE - RETURN LINE Genuine Lamborghini - New (to order)
            OIL PIPE - RETURN LINE Genuine Lamborghini - Used In stock
            # 019
            MPN: N0124371
            RETAINING WASHER
            7
            from £0.53
            from £0.53
            LOCK WASHER Genuine Lamborghini - New In stock
            lock washer (N 0124371) Genuine Porsche Part - New (to order)
            # 020
            MPN: 1H0919371
            O-RING
            17X3
            from £3.68
            from £3.68
            SEALING RING Genuine Lamborghini - New (to order)
            # 021
            MPN: N10335206
            HEXAGON SOCKET FLAT HEAD BOLT
            M6X12
            from £0.80
            from £0.80
            HEXALOBULAR SOCKETM6X12 Genuine Lamborghini - New In stock
            Hexagon socket flat (N 10335206) Genuine Porsche Part - New (to order)
            # 022
            MPN: WHT008755
            O-RING
            13X3
            from £1.98
            from £1.98
            O-RING Genuine Lamborghini - New (to order)
            # 023
            MPN: 1H0919371
            O-RING
            from £3.68
            from £3.68
            SEALING RING Genuine Lamborghini - New (to order)
            # 024
            MPN: N01508210
            HEXAGON COLLAR NUT
            M6
            from £0.47
            from £0.47
            HEXAGON FLANGE NUT M6 Genuine Lamborghini - New In stock
            Genuine Porsche Part (no longer available to order)
