lamborghini urus performante (2023) active charcoal filter with diagnosis pump for fuel delivery system parts diagram

201.03.00 - ACTIVE CHARCOAL FILTER WITH DIAGNOSIS PUMP FOR FUEL DELIVERY SYSTEM

Lamborghini Urus Performante (2023) ACTIVE CHARCOAL FILTER WITH DIAGNOSIS PUMP FOR FUEL DELIVERY SYSTEM Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 001
-
breather line
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
# 001
MPN: 4M4201997G
breather line
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
from £325.90
from £325.90
VENT HOSE Genuine Lamborghini - New (to order)
# 001
MPN: 4M4201997Q
breather line
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
from £353.30
from £353.30
breather line Genuine Lamborghini - New (to order)
# 002
MPN: N10354503
HEXAGON SOCKET OVAL HEAD BOLT (COMBI)
ONLY FOR SOUTH KOREA, USA,CDN-5X10 (EUROPE, USA spec vehicles)
from £0.47
from £0.47
PAN HEAD SCREW W Genuine Lamborghini - New (to order)
HEXAGON SOCKET OVAL HEAD BOLT Genuine Porsche Part - New (to order)
# 003
MPN: 4M0201369B
BRACKET
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
from £11.90
from £11.90
BRACKET Genuine Lamborghini - New (to order)
BRACKET Genuine Lamborghini - Used In stock
# 004
MPN: N90071102
HEXAGON HEAD BOLT (COMBI)
ONLY FOR SOUTH KOREA, USA,CDN-M6X18 (EUROPE, USA spec vehicles)
from £1.06
from £1.06
BOLT, HEX. HD. (COMBI.) Genuine Lamborghini - New (to order)
BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
# 005
MPN: 7L0906243A
DIAGNOSIS PUMP FOR FUEL SYSTEM
ONLY FOR CHINA (EUROPE, USA spec vehicles)
from £267.77
from £267.77
LEAK DIAGNOSTIC DMTL Genuine Lamborghini - New (to order)
# 005
MPN: 7L0906243F
DIAGNOSIS PUMP FOR FUEL SYSTEM
(EUROPE, USA spec vehicles)
from £127.89
from £127.89
LEAK DIAGNOSTIC DMTL Genuine Lamborghini - New (to order)
LEAK DIAGNOSTIC DMTL Genuine Lamborghini - Used In stock
# 006
MPN: 4B0422379A
SPRING BAND CLAMP
ONLY FOR SOUTH KOREA, USA,CDN-25X12 (EUROPE, USA spec vehicles)
from £1.51
from £1.51
SPRING CLAMP Genuine Lamborghini - New In stock
# 007
MPN: 4M4906272
VENT HOSE
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
from £138.16
from £138.16
VENT HOSE Genuine Lamborghini - New (to order)
VENT HOSE Genuine Lamborghini - Used In stock
# 008
MPN: N90686901
SPRING BAND CLAMP
ONLY FOR SOUTH KOREA, USA,CDN-23X12 (EUROPE, USA spec vehicles)
from £0.59
from £0.59
SPRING CLAMP B23X12 Genuine Lamborghini - New In stock
SPRING CLIP Genuine Porsche Part - New (to order)
# 009
MPN: 8R0906621H
AIR FILTER
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
from £10.73
from £10.73
AIR CLEANER Genuine Lamborghini - New In stock
AIR CLEANER Genuine Lamborghini - Used In stock
# 010
MPN: 4M4201999C
VENT HOSE
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
from £276.31
from £276.31
VENT HOSE Genuine Lamborghini - New (to order)
# 011
MPN: N91205601
HEXAGON BOLT
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
from £0.87
from £0.87
DUO HEXAGON FLANGEM8X22 Genuine Lamborghini - New (to order)
SCREW, HEX. HD Genuine Porsche Part - New (to order)
# 012
MPN: WHT007137
HOSE BRACKET
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
from £1.00
from £1.00
LINE BRACKET 5X21 Genuine Lamborghini - New (to order)
# 013
MPN: 4M4201799A
VAPOUR CONTAINER FOR ACTIVATED CHARCOAL CANISTER
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
from £254.94
from £254.94
ACTIVATED CARBON NAR Genuine Lamborghini - New (to order)
# 015
MPN: 4M0201995T
breather line
ONLY FOR SOUTH KOREA, USA,CDN-RIGHT REAR (EUROPE, USA spec vehicles)
from £26.19
from £26.19
BREATHER PIPE Genuine Lamborghini - New (to order)
BREATHER PIPE Genuine Lamborghini - Used In stock
# 016
MPN: 4M0201801A
ACTIVATED CHARCOAL CONTAINER
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
from £102.21
from £102.21
Activated carbon filter Genuine Lamborghini - New (to order)
Activated carbon filter Genuine Lamborghini - Used In stock
# 018
MPN: 4Z7721697A
BRACKET
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
from £4.35
from £4.35
LINE BRACKET 1 FACH Genuine Lamborghini - New (to order)
# 019
MPN: 4M4201782A
HEAT SHIELD
ONLY FOR SOUTH KOREA, USA,CDN (EUROPE, USA spec vehicles)
from £342.20
from £342.20
SHIELD Genuine Lamborghini - New (to order)
SHIELD Genuine Lamborghini - Used In stock
# 020
MPN: N90817003
HEXAGON SOCKET HEAD PANEL BOLT
ONLY FOR SOUTH KOREA, USA,CDN-6X17 (EUROPE, USA spec vehicles)
from £0.50
from £0.50
SCREW TP6X17-Q Genuine Lamborghini - New In stock
HEXAGON SOCKET HEAD PANEL BOLT Genuine Porsche Part - New In stock
# 021
MPN: N10335206
HEXAGON SOCKET FLAT HEAD BOLT
ONLY FOR SOUTH KOREA, USA,CDN-M6X12 (EUROPE, USA spec vehicles)
from £0.78
from £0.78
HEXALOBULAR SOCKETM6X12 Genuine Lamborghini - New In stock
HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
