lamborghini urus performante (2023) shock absorber parts diagram

511.03.00 - SHOCK ABSORBER

Lamborghini Urus Performante (2023) SHOCK ABSORBER Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Key
              Price
              # 001
              MPN: 4ML513021A
              GAS SHOCK ABSORBER, ELECTRONICALLY CONTROLLED
              rear
              from £923.93
              from £923.93
              REAR SHOCK Genuine Lamborghini - New (to order)
              # 002
              MPN: N10106403
              HEXAGON COLLAR NUT SELF-LOCKING
              M12X1,5
              from £1.65
              from £1.65
              PREV.TORQUE TYPE M12X1.5 Genuine Lamborghini - New In stock
              SHOULDERED HEX. NUT, Genuine Porsche Part - New (to order)
              # 003
              -
              GUIDE
              SEE ILLUSTRATION : 505.02,9
              # 004
              MPN: N10402904
              HEXAGON COLLAR NUT
              M12X1,5
              from £2.14
              from £2.14
              PREV.TORQUE TYPE M12X1.5 Genuine Lamborghini - New (to order)
              Genuine Porsche Part (no longer available to order)
              # 005
              MPN: 4ML512131
              BUMP STOP BUFFER (SELF-ADHESIVE)
              from £36.95
              from £36.95
              BUMP STOP Genuine Lamborghini - New (to order)
              # 006
              MPN: 4M0512137C
              PROTECTIVE SLEEVE
              rear
              from £2.43
              from £2.43
              PROTECTIVE COVER Genuine Lamborghini - New (to order)
              # 007
              MPN: 4ML513353
              SHOCK ABSORBER BEARING
              from £210.45
              from £210.45
              DAMPER BEARING, UPPER Genuine Lamborghini - New (to order)
              # 008
              -
              GAS SHOCK ABSORBER, ELECTRONICALLY CONTROLLED
              # 008
              MPN: 4ML513023A
              GAS SHOCK ABSORBER, ELECTRONICALLY CONTROLLED
              GAS SHOCK ABSORBER, ELECTRONICALLY CONTROLLED Genuine Lamborghini - New (to order)
              # 009
              MPN: 4M0512135M
              PROTECTIVE CAP
              from £3.02
              from £3.02
              PROTECTIVE CAP Genuine Lamborghini - New (to order)
              # 010
              MPN: 4M0512195
              GROMMET
              from £1.65
              from £1.65
              GROMMET Genuine Lamborghini - New (to order)
              # 011
              MPN: 1J0906102
              GROMMET
              8,2X40
              from £1.37
              from £1.37
              GROMMET Genuine Lamborghini - New (to order)
              GROMMET Genuine Porsche Part - New (to order)
              # 012
              MPN: 1J0973802
              FLAT CONNECTOR HOUSING WITH CONTACT LOCKING MECHANISM
              2 PIN BLACK
              from £4.44
              from £4.44
              TAB CONNECTOR Genuine Lamborghini - New (to order)
              FLAT CONNECTOR HOUSING WITH Genuine Porsche Part - New (to order)
              # 013
              MPN: N91222501
              HEXAGON HEAD BOLT (COMBI)
              M10X40
              from £2.76
              from £2.76
              HEXAGON FLANGE M10X40-S22 Genuine Lamborghini - New (to order)
              # 014
              MPN: N91236401
              HEXAGON HEAD BOLT (COMBI)
              M12X1,5X100
              from £4.52
              from £4.52
              HEXAGON FLANGE AM12X1.5X100XS22 Genuine Lamborghini - New (to order)
              BOLT, HEX. HD. (COMBI.) Genuine Porsche Part - New (to order)
              # 015
              MPN: 8W0512149A
              SPRING SUPPORT
              UPPER
              from £11.32
              from £11.32
              SPRING SEAT, UPPER Genuine Lamborghini - New (to order)
              # 016
              MPN: 4ML511115
              SPRING
              from £71.21
              from £71.21
              HELICAL SPRING Genuine Lamborghini - New (to order)
              # 017
              MPN: 4M0512297B
              SPRING SUPPORT
              LOWER
              from £11.32
              from £11.32
              SPRING SEAT +1BA Genuine Lamborghini - New (to order)
