lamborghini urus performante (2023) window regulator with motor parts diagram

839.01.00 - WINDOW REGULATOR WITH MOTOR

Lamborghini Urus Performante (2023) WINDOW REGULATOR WITH MOTOR Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 001
MPN: 4ML839461A
WINDOW REGULATOR WITHOUT MOTOR
FROM VIN KLA03073-LEFT (EUROPE, USA spec vehicles)
from £163.41
from £163.41
LIFTING MECHANISM Genuine Lamborghini - New (to order)
LIFTING MECHANISM Genuine Lamborghini - Used In stock
# 001
MPN: 4ML839462A
WINDOW REGULATOR WITHOUT MOTOR
FROM VIN KLA03073-RIGHT (EUROPE, USA spec vehicles)
from £163.41
from £163.41
LIFTING MECHANISM Genuine Lamborghini - New (to order)
LIFTING MECHANISM Genuine Lamborghini - Used In stock
# 002
MPN: WHT004905
HEXAGON SOCKET FLAT HEAD BOLT
(EUROPE, USA spec vehicles)
from £1.17
from £1.17
PAN HEAD BOLT Genuine Lamborghini - New (to order)
# 003
MPN: N10609201
HEXAGON COLLAR NUT
M8 (EUROPE, USA spec vehicles)
from £0.47
from £0.47
HEXAGON FLANGE NUT M8 Genuine Lamborghini - New In stock
shouldered hex. nut Genuine Porsche Part - New (to order)
# 004
MPN: 4K0959801
WINDOW REGULATOR MOTOR
RIGHT (EUROPE, USA spec vehicles)
from £53.70
from £53.70
MOTOR,WINDOW LIFT 13,75NM Genuine Lamborghini - New (to order)
MOTOR,WINDOW LIFT 13,75NM Genuine Lamborghini - Used In stock
# 004
MPN: 4K0959802
WINDOW REGULATOR MOTOR
LEFT (EUROPE, USA spec vehicles)
from £53.70
from £53.70
MOTOR,WINDOW LIFT 13,75NM Genuine Lamborghini - New In stock
MOTOR,WINDOW LIFT 13,75NM Genuine Lamborghini - Used In stock
# 005
MPN: 8Z0837691C
HEXAGON SOCKET HEAD PANEL BOLT
5X22 (EUROPE, USA spec vehicles)
from £0.92
from £0.92
SCREW KUNSTSTOFFSCHR.D=5 Genuine Lamborghini - New In stock
# 007
MPN: 191971908E
BUNGS
14MM (EUROPE, USA spec vehicles)
from £0.84
from £0.84
PLUG 14 Genuine Lamborghini - New (to order)
# 008
MPN: N90908701
BUNGS
12,5 (EUROPE, USA spec vehicles)
from £0.47
from £0.47
STOPPER A12.5X3X14.8 Genuine Lamborghini - New (to order)
PLUG Genuine Porsche Part - New (to order)
# 009
MPN: 4H0839111
COVER CAP
16,2 (EUROPE, USA spec vehicles)
from £0.47
from £0.47
GROMMET Genuine Lamborghini - New (to order)
# 010
MPN: 191971908
GROMMET
(EUROPE, USA spec vehicles)
from £3.07
from £3.07
PLUG 23.00 Genuine Lamborghini - New (to order)
GROMMET Genuine Porsche Part - New (to order)
# 012
MPN: 8P4837798
BUNGS
(EUROPE, USA spec vehicles)
from £1.00
from £1.00
PLUG Genuine Lamborghini - New (to order)
# 013
MPN: 8D0803583L
BUNGS
29,6 (EUROPE, USA spec vehicles)
from £2.68
from £2.68
PLUG 30.00 Genuine Lamborghini - New (to order)
# 014
MPN: 4ML839479
SEAL FOR DOOR WINDOW
WINDOWS IN HEAT- INSULATED GLASS-LEFT OUTER (EUROPE, USA spec vehicles)
from £45.33
from £45.33
WIN. WEATHERSTRIP Genuine Lamborghini - New (to order)
WIN. WEATHERSTRIP Genuine Lamborghini - Used In stock
# 014
MPN: 4ML839479A
SEAL FOR DOOR WINDOW
WINDOWS IN LAMINATED GLASS OR BLACK TINTED-LEFT OUTER (EUROPE, USA spec vehicles)
from £90.65
from £90.65
WIN. WEATHERSTRIP Genuine Lamborghini - New (to order)
# 014
MPN: 4ML839480
SEAL FOR DOOR WINDOW
WINDOWS IN HEAT- INSULATED GLASS-RIGHT OUTER (EUROPE, USA spec vehicles)
from £45.33
from £45.33
WIN. WEATHERSTRIP Genuine Lamborghini - New (to order)
WIN. WEATHERSTRIP Genuine Lamborghini - Used In stock
# 014
MPN: 4ML839480A
SEAL FOR DOOR WINDOW
WINDOWS IN LAMINATED GLASS OR BLACK TINTED-RIGHT OUTER (EUROPE, USA spec vehicles)
from £90.65
from £90.65
WIN. WEATHERSTRIP Genuine Lamborghini - New (to order)
# 015
MPN: 4ML839475A3Q7
SEAL FOR DOOR WINDOW
CHROMED - LEFT INNER-BURNISHED ALUMINIUM (EUROPE, USA spec vehicles)
from £133.88
from £133.88
WIN. WEATHERSTRIP Genuine Lamborghini - New (to order)
# 015
MPN: 4ML839475T94
SEAL FOR DOOR WINDOW
LEFT INNER-BLACK (EUROPE, USA spec vehicles)
from £60.83
from £60.83
Genuine Lamborghini (no longer available to order)
WIN. WEATHERSTRIP Genuine Lamborghini - Used In stock
# 015
MPN: 4ML839476A3Q7
SEAL FOR DOOR WINDOW
CHROMED - RIGHT INNER-BURNISHED ALUMINIUM (EUROPE, USA spec vehicles)
from £133.88
from £133.88
WIN. WEATHERSTRIP Genuine Lamborghini - New (to order)
# 015
MPN: 4ML839476T94
SEAL FOR DOOR WINDOW
RIGHT INNER-BLACK (EUROPE, USA spec vehicles)
from £40.55
from £40.55
WIN. WEATHERSTRIP Genuine Lamborghini - New (to order)
WIN. WEATHERSTRIP Genuine Lamborghini - Used In stock
# 016
MPN: 4H0837491
BUNGS
NO ROLL-UP SUNSHADE-6,5 (EUROPE, USA spec vehicles)
from £0.51
from £0.51
PLUG 6,50 Genuine Lamborghini - New (to order)
