lamborghini urus s (2023) anti-roll bar parts diagram

407.02.00 - ANTI-ROLL BAR

Lamborghini Urus S (2023) ANTI-ROLL BAR Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 001
MPN: 4M0411023AS
ANTI-ROLL BAR
(UK, USA spec vehicles)
from £2,563.67
from £2,563.67
STABILIZER BAR COST-DOWN-PAKET Genuine Lamborghini - New (to order)
# 003
MPN: 4M0407555B
HOLDER FOR WIRING HARNESS
(UK, USA spec vehicles)
from £13.63
from £13.63
BRACKET Genuine Lamborghini - New (to order)
# 004
MPN: 4M0407731B
BRACKET
(UK, USA spec vehicles)
from £3.40
from £3.40
BRACKET KOPPELSTELLE Genuine Lamborghini - New (to order)
BRACKET KOPPELSTELLE Genuine Lamborghini - Used In stock
# 005
MPN: N10738101
HEX SOCKET HEAD BOLT (COMBI)
M5X16 (UK, USA spec vehicles)
from £0.73
from £0.73
HEXALOBULAR SOCKET M5X16 S11-L Genuine Lamborghini - New In stock
# 006
MPN: N91189303
HEXAGON NUT
M6 (UK, USA spec vehicles)
from £1.15
from £1.15
HEXAGON FLANGE NUTM6 Genuine Lamborghini - New (to order)
hex. nut (N 91189303) Genuine Porsche Part - New (to order)
# 007
MPN: WHT004890A
WELD SCREW WITH CAP NUT
M10X20 (UK, USA spec vehicles)
from £14.62
from £14.62
WELD STUD M10 Genuine Lamborghini - New (to order)
# 008
MPN: N90533005
HEXAGON HEAD BOLT (COMBI)
M6X20 (UK, USA spec vehicles)
from £1.31
from £1.31
This part replaces part number N90533002
HEXAGON HEAD BOLT M6X20-S1 Genuine Lamborghini - New In stock
bolt, hex. hd. (combi.) (N 90533005) Genuine Porsche Part - New (to order)
# 009
MPN: N90335006
CLAMPING WASHER
(UK, USA spec vehicles)
from £0.54
from £0.54
CLAMPING WASHER S-5X30 Genuine Lamborghini - New (to order)
# 010
MPN: N10335206
HEXAGON SOCKET FLAT HEAD BOLT
M6X12 (UK, USA spec vehicles)
from £0.80
from £0.80
HEXALOBULAR SOCKETM6X12 Genuine Lamborghini - New In stock
Hexagon socket flat (N 10335206) Genuine Porsche Part - New (to order)
# 011
MPN: 4M0411336C
CLAMP
FRONT (UK, USA spec vehicles)
from £14.88
from £14.88
CLIP Genuine Lamborghini - New In stock
CLIP Genuine Lamborghini - Used In stock
# 012
MPN: N10261311
HEXAGON NUT
M10 (UK, USA spec vehicles)
from £1.17
from £1.17
This part replaces part number N10261306
HEXAGON FLANGE NUT M10 Genuine Lamborghini - New In stock
hex. nut (N 10261311) Genuine Porsche Part - New In stock
# 013
MPN: N10699901
HEXAGON BOLT
M10X45 (UK, USA spec vehicles)
from £2.16
from £2.16
HEXAGON FLANGE M10X45 Genuine Lamborghini - New (to order)
screw, hex. hd. (N 10699901) Genuine Porsche Part - New (to order)
