maserati 4200 coupe (2003) spare assembly units parts diagram

000 - spare assembly units

Maserati 4200 Coupe (2003) Spare Assembly Units Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Price
# 000
MPN: 1001732
INSULATION KIT
-Not for F1--Valid for USA and CDN-
from £837.57
from £837.57
# 000
MPN: 1001896
INSULATION KIT
-Not for F1--Not for USA, CDN and GD-
from £795.62
from £795.62
# 000
MPN: 1001903
INSULATION KIT
-Not for F1--Valid for AUS-
from £843.49
from £843.49
# 000
MPN: 1001920
INSULATION KIT
-Not for F1--Valid for GB-
from £964.33
from £964.33
# 000
MPN: 1001941
INSULATION KIT
-Valid for F1--Valid for USA and CDN-
from £877.80
from £877.80
# 000
MPN: 1001943
INSULATION KIT
-Valid for F1--Not for USA, CDN and GD-
from £821.59
from £821.59
# 000
MPN: 1001944
INSULATION KIT
-Valid for F1--Valid for GB-
from £999.50
from £999.50
# 000
MPN: 1001945
INSULATION KIT
-Valid for F1--Valid for AUS-
from £877.80
from £877.80
# 000
MPN: 185062
COMPLETE GEAR BOX
-Valid for F1-
Supersession
Supersession
# 000
MPN: 198255
COMPLETE GEAR BOX
-Not for F1-
Supersession
Supersession
This part replaces part number 185204 which we have in stock
# 000
MPN: 980020002
CRANKCASE GASKET REVISION KIT
Supersession
Supersession
