maserati 4200 coupe (2004) spare assembly units parts diagram

000 - spare assembly units

Maserati 4200 Coupe (2004) Spare Assembly Units Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Price
# 000
MPN: 1001958
INSULATION KIT
-Not for F1--Not for GD-
from £783.86
from £783.86
# 000
MPN: 1001959
INSULATION KIT
-Not for F1--Valid for GD-
from £736.72
from £736.72
# 000
MPN: 1001960
INSULATION KIT
-Valid for F1--Not for GD-
from £825.13
from £825.13
# 000
MPN: 1001961
INSULATION KIT
-Valid for F1--Valid for GD-
from £881.58
from £881.58
# 000
MPN: 199545
COMPLETE GEAR BOX
-Valid for F1-
from £11,009.88
from £11,009.88
This part replaces part number 185062
# 000
MPN: 203017
COMPLETE GEAR BOX
-Not for F1-
from £10,638.31
from £10,638.31
This part replaces part number 198255 - and 1 more. Click to view details
# 000
MPN: 980020004
CRANKCASE GASKET REVISION KIT
from £112.37
from £112.37
This part replaces part number 980020002
