0011 - Exhaust System
Maserati Trofeo EXHAUST SYSTEM Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 197250
EXHAUST TUBE FROM RH MANIFOLD
from £4,496.79
from £4,496.79
# 002
MPN: 197251
EXHAUST TUBE FROM LH MANIFOLD
from £4,496.79
from £4,496.79
# 003
MPN: 184798
GASKET
Supplied also in the cylinder heads gasket revision kit (cod. 9800200001)
from £20.25
from £20.25
# 004
MPN: 190213
SCREW
from £2.69
from £2.69
# 005
MPN: 11193874
WASHER
from £0.53
from £0.53
# 006
MPN: 182837
FRONT LAMBDA FEELER
from £148.14
from £148.14
# 007
MPN: 175856
CONNECTORS FIXING BRACKET
from £1.27
from £1.27
This part replaces part number 155752
# 008
MPN: 67190100
NUT
from £1.18
from £1.18
# 009
MPN: 183795
RH EXHAUST MANIFOLD
from £1,355.88
from £1,355.88
# 010
MPN: 183796
LH EXHAUST MANIFOLD
from £1,355.88
from £1,355.88
# 011
MPN: 182868
GASKET
Supplied also in the cylinder heads gasket revision kit (cod. 9800200001)
from £3.12
from £3.12
# 012
MPN: 138392
NUT
from £0.61
from £0.61
# 013
MPN: 187827
BRACKET
from £12.45
from £12.45
# 014
MPN: 195273
NUT
from £1.18
from £1.18
This part replaces part number 10575215
# 015
MPN: 12625221
WASHER
Supersession
Supersession
# 016
MPN: 184333
PAD
from £21.30
from £21.30
# 017
MPN: 16043324
SCREW
from £0.53
from £0.53
# 018
MPN: 11193874
WASHER
from £0.54
from £0.54
# 019
MPN: 12625224
WASHER
from £0.54
from £0.54
This part replaces part number 12625221
# 020
MPN: 187826
CENTRAL SILENCER
Silenced version
from £929.31
from £929.31
# 020
MPN: 197252
CENTRAL SILENCER
STANDARD
from £1,923.40
from £1,923.40
# 021
MPN: 185307
CLAMP
from £16.02
from £16.02
This part replaces part number 173896
# 022
MPN: 187823
RH EXHAUST EXTENSION
from £392.80
from £392.80
# 023
MPN: 187824
LH EXHAUST EXTENSION
from £392.80
from £392.80
# 024
MPN: 185307
CLAMP
from £16.02
from £16.02
This part replaces part number 173896
# 025
MPN: 197253
RH REAR SILENCER
Valid for MY 2003Valid for MY 2004Valid till stock exhaustion
from £2,861.81
from £2,861.81
# 025
MPN: 219201
RH REAR SILENCER
Valid for MY 2005
# 026
MPN: 197254
LH REAR SILENCER
Valid for MY 2003Valid for MY 2004Valid till stock exhaustion
from £3,007.33
from £3,007.33
# 026
MPN: 219202
LH REAR SILENCER
Valid for MY 2005
# 027
MPN: 185307
CLAMP
from £16.02
from £16.02
This part replaces part number 173896
# 028
MPN: 194744
THERMOCOUPLE
from £254.99
from £254.99
# 029
MPN: 155751
CLIP
from £2.37
from £2.37
# 030
MPN: 14059111
NUT
from £0.53
from £0.53
# 031
MPN: 12644424
WASHER
from £0.54
from £0.54
This part replaces part number 13550214
# 032
MPN: 187836
SPACER
from £10.18
from £10.18
# 033
MPN: 193098
SPACER BAR THICKNESS
from £2.52
from £2.52
# 034
MPN: 16043124
SCREW
from £0.30
from £0.30
# 035
MPN: 12601374
WASHER
from £0.53
from £0.53
# 036
MPN: 187775
RH SUPPORT
from £12.84
from £12.84
# 037
MPN: 187774
LH SUPPORT
from £18.15
from £18.15
# 038
MPN: 16100814
NUT
from £0.71
from £0.71
# 039
MPN: 187861
ANTI-VIBRATION SUPPORT
from £29.11
from £29.11
# 040
MPN: 16043424
SCREW
from £0.51
from £0.51
# 041
MPN: 12601374
WASHER
from £0.53
from £0.53
# 042
MPN: 14496524
WASHER
from £0.53
from £0.53
# 043
MPN: 14496524
WASHER
from £0.53
from £0.53
# 044
MPN: 184814
REAR SUPPORT
from £20.56
from £20.56
# 045
MPN: 16043224
SCREW
from £0.51
from £0.51
# 046
MPN: 12601374
WASHER
from £0.53
from £0.53
# 047
MPN: 12638524
WASHER
from £0.53
from £0.53
# 048
MPN: 585005500
CLOSING FLANGE
from £101.34
from £101.34
# 049
MPN: 14305724
SCREW
from £0.53
from £0.53
# 050
MPN: 127494
WASHER
from £0.47
from £0.47
# 051
MPN: 312020382
CLAMP
from £0.75
from £0.75
