maserati ghibli 2.8 (non abs) gearbox-external controls parts diagram

009.2 - Gearbox-External Controls

Maserati Ghibli 2.8 (Non ABS) Gearbox-External Controls Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Price
# 001
MPN: 325253300
GEARSHIFT LEVER BOOT
Valid for 01
from £20.70
from £20.70
# 002
MPN: 167200625
SCREW
Valid for 01
from £2.47
from £2.47
# 003
MPN: 135100064
WASHER
Valid for 01
from £1.08
from £1.08
# 004
MPN: 395250102
KNOB
Valid for 01
from £70.26
from £70.26
# 005
MPN: 325253172
CONTROL LEVER
Valid for 01
Supersession
Supersession
# 006
MPN: 325253333
CUP
Valid for 01
# 007
MPN: 128350080
SELF LOCKING NUT
Valid for 01
Supersession
Supersession
# 008
MPN: 135100004
WASHER
Valid for 01
# 009
MPN: 325253180
SUPPORT
Valid for 01
from £13.13
from £13.13
# 010
MPN: 395250150
LEVER AND PINS
Valid for 01
Supersession
Supersession
# 011
MPN: 325253564
WASHER
Valid for 01
from £1.47
from £1.47
# 012
MPN: 325253572
CLIPS
Valid for 01
from £1.08
from £1.08
# 013
MPN: 325253176
ARTICULATION
Valid for 01
from £423.42
from £423.42
# 014
MPN: 315232407
GASKET
Valid for 01
from £1.93
from £1.93
# 015
MPN: 395250301
Frame
Valid for 01
from £10.12
from £10.12
# 016
MPN: 325253302
SPONGE RUBBER PROTECTION
Valid for 01
from £4.64
from £4.64
# 017
MPN: 100708045
SCREW
Valid for 01
# 018
MPN: 135600080
LOCK WASHER
Valid for 01
# 019
MPN: 325253178
PIN WITH CLIPS
Valid for 01
from £14.14
from £14.14
# 020
MPN: 395250574
BRACKET
Valid for 01
from £122.39
from £122.39
# 021
MPN: 325253568
BUSH
Valid for 01
from £9.66
from £9.66
# 022
MPN: 325253566
LEVER
Valid for 01
from £6.27
from £6.27
