maserati ghibli 2.8 gt (variante) handbrake control parts diagram

040 - Handbrake Control

Maserati Ghibli 2.8 GT (Variante) Handbrake Control Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                        #
                                        Part number
                                        Description
                                        Price
                                        # 001
                                        MPN: 328056110
                                        KNOB FOR LEVER ASSY
                                        from £71.18
                                        from £71.18
                                        # 004
                                        MPN: 58841309
                                        SPRING CLIP
                                        from £2.00
                                        from £2.00
                                        This part replaces part number 670000498 - and 2 more. Click to view details
                                        # 005
                                        MPN: 318020327
                                        PIN
                                        from £4.56
                                        from £4.56
                                        # 006
                                        MPN: 318020324
                                        CHECK NUT
                                        from £1.08
                                        from £1.08
                                        # 007
                                        MPN: 124900060
                                        NUT
                                        from £0.78
                                        from £0.78
                                        # 008
                                        MPN: 318020325
                                        SPRING
                                        from £1.41
                                        from £1.41
                                        # 009
                                        MPN: 378000118
                                        CABLE ASSY
                                        Supersession
                                        Supersession
                                        This part replaces part number 398050118
                                        # 010
                                        MPN: 318020355
                                        DUST COVER
                                        from £6.41
                                        from £6.41
                                        # 011
                                        MPN: 318020120
                                        ROD
                                        from £7.55
                                        from £7.55
                                        # 012
                                        MPN: 30331157
                                        SWITCH
                                        from £0.62
                                        from £0.62
                                        # 013
                                        MPN: 318053109
                                        HAND BRAKE LEVER
                                        Supersession
                                        Supersession
                                        # 014
                                        MPN: 163981307
                                        CLAMP
                                        from £1.55
                                        from £1.55
                                        # 016
                                        MPN: 378000322
                                        SPRING CLIP
                                        from £1.93
                                        from £1.93
                                        # 017
                                        MPN: 378000321
                                        SPRING CLIP
                                        from £1.93
                                        from £1.93
                                        # 018
                                        MPN: 128300060
                                        NUT
                                        Supersession
                                        Supersession
                                        # 019
                                        MPN: 135900064
                                        WASHER
                                        from £0.47
                                        from £0.47
