maserati ghibli (2021) wheelhouse and lids parts diagram

09.13.1 - WHEELHOUSE AND LIDS

Maserati Ghibli (2021) WHEELHOUSE AND LIDS Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                      #
                      Part number
                      Description
                      Key
                      Price
                      # 001
                      MPN: 670105932
                      LH FRONT WHEELHOUSE GUARD, FRONT SIDE
                      Valid from assembly:0 - 5118877.Suitable for:2.0 T4 2WD 330 HP MHEV, 3.0 BT SOFT V6 2WD 350 HP, 3.0 BT V6 2WD 430 HP, 3.0 BT V6 4WD 430 HP|ITALY, UNITED ARAB EMIRATES, USA
                      from £63.52
                      from £63.52
                      This part replaces part number 670039699
                      LH FRONT WHEELHOUSE GUARD Genuine Maserati Part - New In stock
                      # 001
                      MPN: 670105933
                      LH FRONT WHEELHOUSE GUARD, FRONT SIDE
                      Valid from assembly:0 - 5118877.Suitable for:AUTOMATIC|2.0 T4 2WD 330 HP MHEV, 3.0 BT SOFT V6 2WD 350 HP, 3.0 BT V6 2WD 430 HP, 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP|ITALY, UK
                      from £64.39
                      from £64.39
                      This part replaces part number 670039700
                      LH FRONT WHEELHOUSE GUARD (L Genuine Maserati Part - New (to order)
                      # 001
                      MPN: 670105934
                      RH FRONT WHEELHOUSE GUARD, FRONT SIDE
                      Valid from assembly:0 - 5118877.Suitable for:2.0 T4 2WD 330 HP MHEV, 3.0 BT SOFT V6 2WD 350 HP, 3.0 BT V6 2WD 430 HP, 3.0 BT V6 4WD 430 HP|ITALY, UNITED ARAB EMIRATES, USA
                      from £63.52
                      from £63.52
                      This part replaces part number 670039701
                      RH FRONT WHEELHOUSE GUARD (L Genuine Maserati Part - New In stock
                      # 001
                      MPN: 670105935
                      RH FRONT WHEELHOUSE GUARD, FRONT SIDE
                      Valid from assembly:0 - 5118877.Suitable for:AUTOMATIC|2.0 T4 2WD 330 HP MHEV, 3.0 BT SOFT V6 2WD 350 HP, 3.0 BT V6 2WD 430 HP, 3.0 TDS V6 2WD 250 HP, 3.0 TDS V6 2WD 275 HP|ITALY, UK
                      from £64.39
                      from £64.39
                      This part replaces part number 670039702
                      RH FRONT WHEELHOUSE GUARD, FRONT SIDE Genuine Maserati Part - New (to order)
                      # 003
                      MPN: 670153507
                      RH FRONT WHEELHOUSE GUARD, REAR SIDE
                      Valid from assembly:5101908.
                      from £46.51
                      from £46.51
                      RH FRONT WHEELHOUSE Genuine Maserati Part - New (to order)
                      # 003
                      MPN: 670153508
                      LH FRONT WHEELHOUSE GUARD, REAR SIDE
                      Valid from assembly:5101908.
                      from £46.51
                      from £46.51
                      LH FRONT WHEELHOUSE Genuine Maserati Part - New (to order)
                      # 004
                      MPN: 670038118
                      LH REAR WHEELHOUSE GUARD
                      from £49.36
                      from £49.36
                      This part replaces part number 670009774
                      LH REAR WHEELHOUSE GUARD Genuine Maserati Part - New (to order)
                      # 004
                      MPN: 670038155
                      RH REAR WHEELHOUSE GUARD
                      Valid from assembly:0 - 5113281.
                      from £27.15
                      from £27.15
                      This part replaces part number 670009775 - and 1 more. Click to view details
                      RH REAR WHEELHOUSE GUARD Genuine Maserati Part - New (to order)
                      RH REAR WHEELHOUSE GUARD Genuine Maserati Part - Used In stock
                      # 005
                      MPN: 675000327
                      BLOCK
                      from £0.73
                      from £0.73
                      FASTENING BLOCK Genuine Maserati Part - New In stock
                      # 006
                      MPN: 675000326
                      SCREW [10X16]
                      from £1.24
                      from £1.24
                      VITE(NORMALE)A TBIC CON FLAN / SCREW(NORMAL)TO TBIC WITH FLANGE Genuine Maserati Part - New In stock
                      # 007
                      MPN: 675000325
                      NUT
                      from £0.81
                      from £0.81
                      PLASTIC NUT Genuine Maserati Part - New In stock
                      # 008
                      MPN: 675000326
                      SCREW [10X16]
                      from £1.31
                      from £1.31
                      VITE(NORMALE)A TBIC CON FLAN / SCREW(NORMAL)TO TBIC WITH FLANGE Genuine Maserati Part - New In stock
                      # 009
                      MPN: 670009201
                      PIN
                      from £2.43
                      from £2.43
                      PIN Genuine Maserati Part - New In stock
                      # 010
                      MPN: 670005230
                      PLUG
                      Valid from assembly:0 - 5119326.
                      from £2.04
                      from £2.04
                      Plug 48X40 MM Genuine Maserati Part - New In stock
                      # 011
                      MPN: 670003320
                      FASTENER BUTTON
                      from £1.14
                      from £1.14
                      FASTENING BUTTON Genuine Maserati Part - New In stock
                      # 011
                      MPN: 670009112
                      FASTENER BUTTON
                      Valid from assembly:5101907.
                      from £2.43
                      from £2.43
                      Fastening Pin Genuine Maserati Part - New In stock
                      # 012
                      MPN: 670009112
                      FASTENER BUTTON
                      from £2.43
                      from £2.43
                      Fastening Pin Genuine Maserati Part - New In stock
                      # 013
                      MPN: 675000294
                      PIN
                      from £2.11
                      from £2.11
                      PIN Genuine Maserati Part - New In stock
                      # 014
                      MPN: 675000669
                      SCREW
                      Supersession
                      Supersession
                      This part replaces part number 675000773
                      Genuine Maserati Part (no longer available to order)
                      # 015
                      MPN: 675000818
                      SPECIAL SCREW
                      from £1.33
                      from £1.33
                      SCREW Genuine Maserati Part - New In stock
                      # 016
                      MPN: 670007383
                      FASTENER BUTTON
                      from £5.37
                      from £5.37
                      Fastening Pin Genuine Maserati Part - New (to order)
