Suitable for cars with: Skyhook System. Not for cars with: Special Edition.
maserati granturismo (2009) rear shock absorber devices parts diagram

06.21.2 - rear shock absorber devices

Maserati GranTurismo (2009) REAR SHOCK ABSORBER DEVICES Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                              #
                              Part number
                              Description
                              Price
                              # 001
                              MPN: 246271
                              REAR SHOCK ABSORBER #(SOLUTION WITH FIXED SPACER, FOR CARS WITH OLD SOLUTION WITH ADJUSTMENT SPACER REPLACE BOTH)#
                              Valid from assembly: 0 - 66947. Suitable for cars with: Skyhook System. (valid for: CAMBIOCORSA | 4700 cc)
                              from £978.29
                              from £978.29
                              # 001
                              MPN: 254814
                              REAR SHOCK ABSORBER #(SOLUTION WITH FIXED SPACER, FOR CARS WITH OLD SOLUTION WITH ADJUSTMENT SPACER REPLACE BOTH)#
                              Valid from assembly: 0 - 66947. Suitable for cars with: Skyhook System. (valid for: AUTOMATIC)
                              from £973.56
                              from £973.56
                              # 002
                              MPN: 900027816
                              REAR COUPLE SPRINGS KIT
                              Valid from assembly: 0 - 54105. (valid for: AUTOMATIC)
                              from £170.10
                              from £170.10
                              This part replaces part number 216365 which we have in stock - and 1 more. Click to view details
                              # 002
                              MPN: 900027821
                              REAR COUPLE SPRINGS KIT
                              Valid from assembly: 0 - 54105. (valid for: CAMBIOCORSA | 4700 cc)
                              from £136.44
                              from £136.44
                              This part replaces part number 237964
                              # 003
                              MPN: 163918
                              BALL JOINT
                              from £77.62
                              from £77.62
                              This part replaces part number 387000375
                              # 004
                              MPN: 13550624
                              WASHER
                              from £1.39
                              from £1.39
                              # 005
                              MPN: 179555
                              COMPENSATING RING
                              from £3.27
                              from £3.27
                              # 006
                              MPN: 193058
                              SPECIAL SCREW
                              from £31.07
                              from £31.07
                              # 007
                              MPN: 235219
                              INNER FOR SPRING
                              from £10.89
                              from £10.89
                              # 008
                              MPN: 238358
                              UPPER SPACER
                              from £16.15
                              from £16.15
                              # 009
                              MPN: 231388
                              WASHER
                              from £55.95
                              from £55.95
                              This part replaces part number 225875
                              # 010
                              MPN: 228842
                              HYPERBLOCK
                              from £35.87
                              from £35.87
                              # 011
                              MPN: 233125
                              SHOCK ABSORBER PAD
                              Valid from assembly: 0 - 91906. Suitable for cars with: Skyhook System. (valid for: CAMBIOCORSA | 4700 cc)
                              from £9.55
                              from £9.55
                              # 012
                              MPN: 10520125
                              WASHER
                              Suitable for cars with: Skyhook System.
                              from £1.85
                              from £1.85
                              # 013
                              MPN: 203795
                              NUT
                              Suitable for cars with: Skyhook System.
                              from £1.57
                              from £1.57
                              This part replaces part number 183417 - and 1 more. Click to view details
                              # 014
                              MPN: 14306634
                              SCREW
                              from £0.47
                              from £0.47
                              # 015
                              MPN: 11194074
                              WASHER
                              from £0.47
                              from £0.47
                              # 016
                              MPN: 14496524
                              WASHER [D. 8.40-17 X1.6]
                              from £0.51
                              from £0.51
                              # 017
                              MPN: 279627
                              UPPER WASHER
                              Valid from assembly: 0 - 61842.
                              from £11.52
                              from £11.52
                              This part replaces part number 190332
                              # 018
                              MPN: 183595
                              BUSHING
                              from £32.38
                              from £32.38
                              # 019
                              MPN: 183594
                              CIRCLIP
                              from £21.56
                              from £21.56
                              # 023
                              MPN: 239278
                              SPACER #INDIA - KOREA - ORDER ONLY FOR THE VEHICLES IN THE LIST OF THE PDF DOCUMENT ATTACHED#
                              (valid for: 4700 cc)
                              from £22.41
                              from £22.41
                              # 023
                              MPN: 239278
                              SPACER #INDIA - KOREA - ORDER ONLY FOR THE VEHICLES IN THE LIST OF THE PDF DOCUMENT ATTACHED#
                              Valid from assembly: 0 - 91906. (valid for: 4700 cc)
                              from £22.41
                              from £22.41
                              # 024
                              MPN: 14306934
                              SCREW #INDIA - KOREA - ORDER ONLY FOR THE VEHICLES IN THE LIST OF THE PDF DOCUMENT ATTACHED#
                              from £0.89
                              from £0.89
