Valid from assembly: 0 - 91906. Not for cars with: Special Edition.
maserati granturismo (2011) driver controls for automatic gearbox parts diagram

03.02.1 - driver controls for automatic gearbox

Maserati GranTurismo (2011) DRIVER CONTROLS FOR AUTOMATIC GEARBOX Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Price
# 000
MPN: 980139931
MOONWOOD KIT
(valid for: AUTOMATIC | AUSTRALIA,JAPAN (RH DRIVE),SOUTH AFRICA,UK)
from £2,353.19
from £2,353.19
# 000
MPN: 980139932
MOONWOOD KIT
(valid for: AUTOMATIC | CANADA,CHINA,EUROPE,JAPAN,MIDDLE-EAST,TAIWAN,USA)
from £2,353.19
from £2,353.19
# 001
MPN: 217517
AUTOMATIC GEARBOX ASSEMBLY
(valid for: AUTOMATIC)
from £422.36
from £422.36
# 002
MPN: 14059214
NUT [M6]
(valid for: AUTOMATIC)
from £0.54
from £0.54
This part replaces part number 12578121
# 003
MPN: 14305821
SCREW [M6X40 ]
(valid for: AUTOMATIC)
from £0.53
from £0.53
# 004
MPN: 14059121
NUT
(valid for: AUTOMATIC)
from £0.54
from £0.54
# 005
MPN: 222488
BRACKET
(valid for: AUTOMATIC)
from £14.25
from £14.25
# 006
MPN: 16286024
SCREW [M 6X 16]
(valid for: AUTOMATIC)
from £0.53
from £0.53
# 007
MPN: 981431700
AUTOMATIC GEARBOX CONTROL KNOB
Colour: BLACK.(valid for: AUTOMATIC)
from £254.46
from £254.46
This part replaces part number 9814317.. - and 1 more. Click to view details
# 007
MPN: 981431702
AUTOMATIC GEARBOX CONTROL KNOB
Colour: IVORY.(valid for: AUTOMATIC)
from £462.65
from £462.65
This part replaces part number 9814317..
# 007
MPN: 981431707
AUTOMATIC GEARBOX CONTROL KNOB
Colour: BORDEAUX.(valid for: AUTOMATIC)
from £431.26
from £431.26
This part replaces part number 9814317..
# 007
MPN: 981431708
AUTOMATIC GEARBOX CONTROL KNOB
Colour: TAN.(valid for: AUTOMATIC)
from £411.51
from £411.51
This part replaces part number 9814317..
# 007
MPN: 981431724
AUTOMATIC GEARBOX CONTROL KNOB
Colour: CORALLO RED.(valid for: AUTOMATIC)
from £462.65
from £462.65
This part replaces part number 9814317..
# 007
MPN: 981431728
AUTOMATIC GEARBOX CONTROL KNOB
Colour: CORNIOLA BROWN.(valid for: AUTOMATIC)
from £462.65
from £462.65
This part replaces part number 9814317..
# 007
MPN: 981431729
AUTOMATIC GEARBOX CONTROL KNOB
Colour: NUOVO SABBIA.(valid for: AUTOMATIC)
from £462.65
from £462.65
This part replaces part number 9814317..
# 007
MPN: 981431732
AUTOMATIC GEARBOX CONTROL KNOB
Colour: PEARL BEIGE.(valid for: AUTOMATIC)
from £254.46
from £254.46
This part replaces part number 9814317.. - and 1 more. Click to view details
# 007
MPN: 981431733
AUTOMATIC GEARBOX CONTROL KNOB
Colour: PROFONDITA BLUE.(valid for: AUTOMATIC)
from £431.26
from £431.26
This part replaces part number 9814317..
# 007
MPN: 981431748
AUTOMATIC GEARBOX CONTROL KNOB
Colour: CHRONO GREY.(valid for: AUTOMATIC)
from £289.20
from £289.20
This part replaces part number 9814317..
# 007
MPN: 981431749
AUTOMATIC GEARBOX CONTROL KNOB
Colour: PRIZED WHITE.(valid for: AUTOMATIC)
from £289.20
from £289.20
This part replaces part number 9814317..
# 008
MPN: 80050200
INSERT FOR KNOB #HIGH GLOSS MOULDING#
Colour: BLACK PIANO.(valid for: AUTOMATIC)
from £247.06
from £247.06
This part replaces part number 800502..
# 008
MPN: 80050201
INSERT FOR KNOB #HIGH GLOSS MOULDING#
Colour: ICE WHITE.(valid for: AUTOMATIC)
from £229.74
from £229.74
This part replaces part number 800502..
# 008
MPN: 80050202
INSERT FOR KNOB #HIGH GLOSS MOULDING#
Colour: DECORO YELLOW.(valid for: AUTOMATIC)
from £192.14
from £192.14
This part replaces part number 800502..
# 008
MPN: 80050203
INSERT FOR KNOB #HIGH GLOSS MOULDING#
Colour: SIGILLO RED.(valid for: AUTOMATIC)
from £247.06
from £247.06
This part replaces part number 800502..
# 008
MPN: 80050204
INSERT FOR KNOB #HIGH GLOSS MOULDING#
Colour: LAQUE BLUE.(valid for: AUTOMATIC)
from £192.14
from £192.14
This part replaces part number 800502..
# 008
MPN: 80050247
INSERT FOR KNOB #PAINT PLASTICS#
Colour: ALU GREY.(valid for: AUTOMATIC)
from £224.74
from £224.74
This part replaces part number 800502..
# 008
MPN: 80050249
INSERT FOR KNOB #PAINT PLASTICS#
Colour: DARK CHROME.(valid for: AUTOMATIC)
from £266.04
from £266.04
This part replaces part number 800502..
# 008
MPN: 80050275
INSERT FOR KNOB #INTERIOR TRIMMING - FOR MOONWOOD MOULDING P/N REFER TO BULLETIN PPD 05/2014#
Colour: PADOUK.(valid for: AUTOMATIC)
from £229.74
from £229.74
This part replaces part number 800502..
# 008
MPN: 80050278
INSERT FOR KNOB #INTERIOR TRIMMING - FOR MOONWOOD MOULDING P/N REFER TO BULLETIN PPD 05/2014#
Colour: MOONWOOD.(valid for: AUTOMATIC)
from £191.38
from £191.38
This part replaces part number 800502..
# 008
MPN: 80050282
INSERT FOR KNOB #INTERIOR TRIMMING - FOR MOONWOOD MOULDING P/N REFER TO BULLETIN PPD 05/2014#
Colour: ROSEWOOD.(valid for: AUTOMATIC)
from £229.74
from £229.74
This part replaces part number 800502..
# 008
MPN: 80050290
INSERT FOR KNOB #INTERIOR TRIMMING - FOR MOONWOOD MOULDING P/N REFER TO BULLETIN PPD 05/2014#
Colour: WALNUT BRIANWOOD MY06.(valid for: AUTOMATIC)
from £135.88
from £135.88
This part replaces part number 800502.. - and 1 more. Click to view details
# 008
MPN: 80050297
INSERT FOR KNOB #INTERIOR TRIMMING - FOR MOONWOOD MOULDING P/N REFER TO BULLETIN PPD 05/2014#
Colour: WENGE.(valid for: AUTOMATIC)
from £247.06
from £247.06
This part replaces part number 800502..
# 008
MPN: 82413660
INSERT FOR KNOB #INTERIOR TRIMMING (CARBON)#
Valid from assembly: 49658. Colour: ALUTEX.(valid for: AUTOMATIC)
from £281.17
from £281.17
This part replaces part number 824136..
# 008
MPN: 82413677
INSERT FOR KNOB #INTERIOR TRIMMING (CARBON)#
Valid from assembly: 49658. Colour: CARBON MC LINE.(valid for: AUTOMATIC)
from £206.89
from £206.89
This part replaces part number 824136.. - and 3 more. Click to view details
# 008
MPN: 82413679
INSERT FOR KNOB #INTERIOR TRIMMING (CARBON)#
Valid from assembly: 49658. Colour: TITANTEX.(valid for: AUTOMATIC)
from £291.12
from £291.12
This part replaces part number 824136..
# 009
MPN: 261433
LEVERS SET
Valid from assembly: 0 - 66947. (valid for: AUTOMATIC)
from £462.24
from £462.24
This part replaces part number 235836 - and 1 more. Click to view details
# 009
MPN: 261433
LEVERS SET
Valid from assembly: 0 - 87853. (valid for: AUTOMATIC)
from £462.24
from £462.24
This part replaces part number 235836 - and 1 more. Click to view details
# 009
MPN: 261434
LEVERS SET #SHIFT PADDLES WITH TROFEO SHAPE#
(valid for: AUTOMATIC | 4700 cc)
from £262.50
from £262.50
This part replaces part number 237665 - and 2 more. Click to view details
# 009
MPN: 261435
LEVERS SET #CARBON#
Valid from assembly: 49658. Suitable for cars with: MC Sport Line Version. (valid for: AUTOMATIC)
from £1,704.62
from £1,704.62
This part replaces part number 257925
# 010
MPN: 13025787
SCREW
(valid for: AUTOMATIC)
from £0.53
from £0.53
# 011
MPN: 12601174
WASHER [D.5.3-11X0.5]
(valid for: AUTOMATIC)
from £0.54
from £0.54
This part replaces part number 675000100
# 012
MPN: 12601274
WASHER [D. 6,40-12X 0,5]
(valid for: AUTOMATIC)
from £0.53
from £0.53
This part replaces part number 12601270
# 013
MPN: 175856
CONNECTOR FIXING BRACKET
(valid for: AUTOMATIC)
from £1.17
from £1.17
This part replaces part number 155752
