01.71.6 - cooling system: nourice and lines
Maserati Levante Zenga (2020) COOLING SYSTEM: NOURICE AND LINES Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 670031955
PIPE BETWEEN ENGINE AND SECONDARY RADIATOR
from £41.16
from £41.16
# 002
MPN: 670104917
PIPE BETWEEN SECONDARY RADIATOR AND PUMP
Valid from assembly: 6053787.
from £36.95
from £36.95
# 003
MPN: 670005347
ELECTRIC WATER PUMP
from £195.09
from £195.09
# 004
MPN: 670008886
CLAMP
from £4.76
from £4.76
# 005
MPN: 670003816
BRACKET
Valid from assembly: 0 - 6079466.
Supersession
Supersession
# 005
MPN: 670037040
BRACKET
from £19.18
from £19.18
This part replaces part number 670003816
# 006
MPN: 675000658
COLLAR
from £5.73
from £5.73
This part replaces part number 675000349
# 008
MPN: 11417670
SCREW COLLAR
from £6.47
from £6.47
This part replaces part number 675000094 - and 2 more. Click to view details
# 009
MPN: 670104778
BRACKET
Valid from assembly: 6027449.
from £15.65
from £15.65
This part replaces part number 670035057
# 010
MPN: 670101979
WATER DELIVERY PIPE FROM PUMP TO ENGINE
Valid from assembly: 6035538.
from £25.66
from £25.66
# 011
MPN: 675000088
SCREW [M6X22]
from £2.11
from £2.11
# 012
MPN: 670031954
WATER DELIVERY PIPE FROM PUMP TO EXCHANGER
Valid from assembly: 0 - 6079466.
from £6.92
from £6.92
# 013
MPN: 670037865
WATER PUMP CABLE
Valid from assembly: 6035538.
from £66.50
from £66.50
# 014
MPN: 11417670
SCREW COLLAR
from £6.47
from £6.47
This part replaces part number 675000094 - and 2 more. Click to view details
# 015
MPN: 675000658
COLLAR
from £5.73
from £5.73
This part replaces part number 675000349
# 016
MPN: 675000372
COLLAR [D.20,5]
from £1.09
from £1.09
This part replaces part number 675000388
# 017
MPN: 675000319
COLLAR [D.22,5]
from £9.75
from £9.75
# 018
MPN: 675000372
COLLAR [D.20,5]
from £1.09
from £1.09
This part replaces part number 675000388
# 019
MPN: 675000319
COLLAR [D.22,5]
from £9.75
from £9.75
# 020
MPN: 675000087
SCREW [M6X16]
from £2.16
from £2.16
# 021
MPN: 675000658
COLLAR
from £5.73
from £5.73
This part replaces part number 675000349
# 022
MPN: 675000364
SCREW [M6X14]
from £0.77
from £0.77
# 024
MPN: 675000180
SCREW [M6X14]
from £0.99
from £0.99
# 025
MPN: 675000319
COLLAR [D.22,5]
from £9.75
from £9.75
# 026
MPN: 675000319
COLLAR [D.22,5]
from £9.75
from £9.75
# 027
MPN: 675000088
SCREW [M6X22]
from £2.11
from £2.11
