022 - Tie Rods
Maserati Mistral 3.7 Tie Rods Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 101/7 - GS 47081
COMPLETE STEERING BOX FOR LEFT-HAND DRIVE
# 001
MPN: 101/7 - GS 47479
COMPLETE STEERING BOX FOR RIGHT HAND DRIVE
# 002
MPN: 1418748097
SCREW
# 003
MPN: DN/43588
NUT
# 004
MPN: 14131 480P1
COVER
# 005
MPN: 14133/48098
CRANKSET FOR TRANSFER LEVER BOX COVER
# 006
MPN: DNT/47064
NUT
# 007
MPN: RN 45680
RONCLELLA ELASTICA 8 X 15 PER DETTO
# 008
MPN: PN/45832
THREADED STUD
# 009
MPN: 14129/48092
TRANSMISSION LEVER HOLDER SHAFT
# 010
MPN: 14185/48094
WASHER
# 011
MPN: 1418348093
BUSH
# 012
MPN: 14127 48394
Transfer box
# 012
MPN: 14127/46429
COMPLETE TRANSFER BOX
# 013
MPN: GOM 41757
Rubber Ø 25 X 31 X 3 on the transfer case and guide
# 014
MPN: 14189/48099
SEAL
# 015
MPN: 107 GC 57940
LEVER
# 017
MPN: DN/47199
NUT
# 018
MPN: RAT. 45681
WASHER
This part replaces part number 45681
# 019
MPN: BNF 47090
BOLT
# 019
MPN: BNT 47020
BOLT
# 020
MPN: BNT 60724
BOLT
# 020
MPN: BNT/47484
BOLT
# 021
MPN: 101/10 - GC 5981 1
STEERING LIMITER
# 022
MPN: BNT/47484
BOLT
# 023
MPN: 13652 47083
JOINT FOR GUIDE COLUMN AND SHAFT ON THE BOX
# 024
MPN: 101/9 GS-59132
RING
# 025
MPN: 101/9 - GS 59133
WASHER
# 026
MPN: 101/9 - GS 61463
SCREW
# 027
MPN: 101/9GS59135
WASHER
# 028
MPN: 101/9-GS-59136
SPRING
# 029
MPN: 101/9 GS-59137
STEERING BOX LEVER HOLDER SHAFT
# 030
MPN: 101/9 GS-59138
NUT FOR WORM SCREW GUIDE BOX
# 031
MPN: SFN36593
Sfera per scatola guida
# 032
MPN: 101/9 GS-59139
BUSH
# 033
MPN: RSN/59128
WASHER
# 034
MPN: DN59129
NUT
# 035
MPN: BN 59130
BOLT
# 036
MPN: RSN 3 2 6 3 5
WASHER
# 037
MPN: 1362851000
ANGUS SEALING FLANGE JOINT SIDE STEERING BOX
# 038
MPN: ANT/57431
SEALING RING
# 039
MPN: 101/9 - GS 59140
COVER
# 040
MPN: 101 /9 GS 59141
GASKET OR SEAL
from £5.18
from £5.18
# 041
MPN: 101/9GS59142
STEERING BOX BODY FOR RIGHT DRIVE
# 041
MPN: 101/9GS59143
STEERING BOX BODY FOR LEFT-HAND DRIVE
# 042
MPN: 101/9 - GS 59144
OIL INTRODUCTION CAP INTO THE BOX
# 043
MPN: 101/9 GS 59145
SCREW
# 044
MPN: DN/59131
NUT
# 045
MPN: 101/9-GS-59146
COVER
# 046
MPN: 101/9-GS-59147
GASKET OR SEAL
# 047
MPN: 101/9GS59148
SLIM FLANGE FOR SIDE COVER
from £9.48
from £9.48
# 048
MPN: 101/9GS59149
COVER
# 049
MPN: 14006 48015
LEVER
# 050
MPN: 14002/48014
LEVER
# 051
MPN: 14130 46420
LEVER
# 052
MPN: 107 - GC 56199
TIE ROD
from £567.24
from £567.24
# 053
MPN: 101/9-GC-59150
CORPO DESTRO PER SNODO AUTOLUBRIFLCANTE TIRANTE CENTRALE COMPOSTA DEI PART. 61 - 62 - 63 - 64 - 65 - 66 - 67
from £144.82
from £144.82
# 054
MPN: 101/9 GC 59151
CLAMP ON THE CENTRAL TIE ROD
from £64.65
from £64.65
# 055
MPN: 107GC59152
ROD FOR CENTRAL TIE ROD
# 056
MPN: 101/9 - GS 59153
CORPO SINISTRO PER SNODO AUTOLUBRIFLCANTE TIRANTE CENTRALE COMPLETO DEI PART. 61 - 62 - 63 - 64 - 65 - 66 - 67
# 057
MPN: BNT47090
BOLT
# 058
MPN: RSN/33112
WASHER
from £1.72
from £1.72
# 060
MPN: 107 - GC 56200
TIE ROD
# 061
MPN: CN33539
PIN Ø 2 X 25 FOR TIE ROD JOINT FIXING NUT
# 062
MPN: DCNT50998
NUT
# 063
MPN: 101/9 GC 59154
PARAPOLVERE TESTINE SNODO TIRANTI
# 064
MPN: 101/9 GC 59155
BALL FOR TIE-ROD JOINT HEADS
# 065
MPN: 101/9 GC 59156
RING
# 066
MPN: 101/9GC59170
SPRING
# 067
MPN: 101/9 - GC 59171
Nut for steering tie rod head joint
