(valid for: AUTOMATIC | 3.8 BT V8 530 HP | USA)
Granted by MASERATI
Copyright MASERATI
maserati quattroporte (2018) valves parts diagram

01.25.1 - Valves

Maserati Quattroporte (2018) VALVES Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 001
MPN: 289270
FINGER FOLLOWER AND TAPPET ASSEMBLY
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
from £23.27
from £23.27
COMPLETE LUSH ADJUSTER WITH ROCKER ARM Genuine Maserati Part - New (to order)
Genuine Ferrari Part (no longer available to order)
# 002
MPN: 179763
COTTER FOR VALVE SPRING
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
from £0.29
from £0.29
COTTER FOR SPRING VALVE Genuine Maserati Part - New (to order)
COTTER FOR VALVE SPRING CUP. Genuine Ferrari Part - New In stock
COTTER FOR SPRING VALVE Genuine Maserati Part - Used In stock
Removed from 4200 engine 81090
COTTER FOR VALVE SPRING CUP. Genuine Ferrari Part - Used In stock
# 003
MPN: 287554
UPPER SPACER
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
from £1.55
from £1.55
UPPER SPACER Genuine Maserati Part - New (to order)
UPPER SPRING CAP Genuine Ferrari Part - New (to order)
UPPER SPRING CAP Genuine Ferrari Part - Used In stock
# 004
MPN: 331715
SPRING FOR VALVE RETURN
Valid from assembly: 4016300. Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
from £6.82
from £6.82
This part replaces part number 316505
SPRING FOR VALVE RETURN Genuine Maserati Part - New (to order)
SPRING Genuine Ferrari Part - New (to order)
SPRING Genuine Ferrari Part - Used In stock
# 006
MPN: 221473
OIL SEAL
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
from £1.03
from £1.03
This part replaces part number 148153
OIL SEAL FOR VALVES Genuine Maserati Part - New (to order)
OIL RING Genuine Ferrari Part - New In stock
# 007
MPN: 287552
EXHAUST LOWER SPACER
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
from £3.85
from £3.85
EXHAUST LOWER SPACER Genuine Maserati Part - New (to order)
# 008
-
EXHAUST VALVE GUIDE #AVAILABLE ONLY WITH HEAD ASSEMBLY#
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
# 009
MPN: 287608
EXHAUST VALVE
Valid from assembly: 0 - 4038854. Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
Supersession
Supersession
Genuine Maserati Part (no longer available to order)
Genuine Ferrari Part (no longer available to order)
# 010
MPN: 278885
EXHAUST VALVE SEAT
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
from £6.81
from £6.81
EXHAUST VALVE SEAT Genuine Maserati Part - New (to order)
# 011
MPN: 287551
INTAKE-SIDE LOWER SPACER
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
from £1.73
from £1.73
EXHAUST LOWER SPACER Genuine Maserati Part - New (to order)
LOWER EXHAUST VALVE SPRING C Genuine Ferrari Part - New (to order)
# 012
-
INTAKE VALVE GUIDE #AVAILABLE ONLY WITH HEAD ASSEMBLY#
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
# 013
MPN: 287607
INTAKE VALVE
Valid from assembly: 0 - 4038854. Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
from £6.74
from £6.74
RH CYLINDER HEAD INTAKE VALVE Genuine Maserati Part - New In stock
INTAKE VALVE Genuine Ferrari Part - New (to order)
INTAKE VALVE Genuine Ferrari Part - Used In stock
# 014
MPN: 278886
INDUCTION VALVE SEAT
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
from £8.19
from £8.19
INTAKE VALVE SEAT Genuine Maserati Part - New (to order)
# 015
MPN: 278885
EXHAUST VALVE SEAT
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
from £6.81
from £6.81
EXHAUST VALVE SEAT Genuine Maserati Part - New (to order)
# 016
MPN: 278886
INDUCTION VALVE SEAT
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
from £8.19
from £8.19
INTAKE VALVE SEAT Genuine Maserati Part - New (to order)
# 017
-
INTAKE VALVE GUIDE #AVAILABLE ONLY WITH HEAD ASSEMBLY#
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
# 018
-
EXHAUST VALVE GUIDE #AVAILABLE ONLY WITH HEAD ASSEMBLY#
Suitable for: AUTOMATIC | 3.8 BT V8 530 HP | USA
