103-000 - CYLINDER HEAD - CYLINDER WITH PISTONS - M >> 10 199 - M >> 21 780 - M >> 50 099 - M >> 21 999 - M >> 33 899 - M >> 40 999
Porsche 1956 (356/356A) CYLINDER HEAD - CYLINDER WITH PISTONS - M >> 10 199 - M >> 21 780 - M >> 50 099 - M >> 21 999 - M >> 33 899 - M >> 40 999 Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 369 042031
CYLINDER HEAD - WITH VALVES - READY FOR INSTALLATION - 73,5 MM - MOUNT - 3 - PIN
(369)
# -
-
CYLINDER HEAD - WITH VALVES - READY FOR INSTALLATION - 73,5 MM - MOUNT - 4 - PIN
(369)
# -
-
CYLINDER HEAD - WITH VALVES - READY FOR INSTALLATION - 80 MM
(506/546/527 528)
# -
-
CYLINDER HEAD - WITH VALVES - READY FOR INSTALLATION
(528)
# -
-
CYLINDER HEAD - WITH VALVES - READY FOR INSTALLATION - WITH: - INTAKE - EXHAUST - 10 MM
(506/546)
# -
-
CYLINDER HEAD - WITH VALVES - READY FOR INSTALLATION - WITH: - INTAKE - EXHAUST - 10 MM
(527/528)
# 2
MPN: 369 042022
CYLINDER HEAD - WITHOUT VALVES - 73,5 MM - MOUNT - 3 - PIN
(369)
# -
-
CYLINDER HEAD - WITHOUT VALVES - 73,5MM - MOUNT - 4 - PIN
(369)
# -
-
CYLINDER HEAD - WITHOUT: - INLET/OUTLET VALVE - 80 MM
(506/546/527 528)
# -
-
CYLINDER HEAD - 80 MM
(528)
# -
-
CYLINDER HEAD - 10 MM
(506/546)
# -
-
CYLINDER HEAD - 10 MM
(527/528)
# 3
MPN: 369 04240
BRACKET
# 4
MPN: 59710430500
cylinder head cover
from £233.64
from £233.64
# 5
MPN: 61610495100
GASKET
Supersession
Supersession
# 5
MPN: 61610495101
gasket - Repair set for maintenance - see illustration:
--198-000
from £39.86
from £39.86
This part replaces part number 61610495100
# 6
MPN: 369 05232
CAP - 8 MM
# -
-
CAP - 10 MM
# -
-
CAP
Flat (528)
# 7
MPN: 369 052041
COTTER, SPLIT
from £11.12
from £11.12
# 8
MPN: 369 052031
SPRING SEAT
# -
-
SPRING SEAT - WITH: - REINFORCEMENT - 1.40 I
# 9
MPN: 369 052291
VALVE SPRING
INNER
# -
-
VALVE SPRING - WITH: - REINFORCEMENT - 0.75 I
INNER
# 10
MPN: 369 052281
VALVE SPRING
OUTER
# -
-
VALVE SPRING - WITH: - REINFORCEMENT - 1.25 I
OUTER
# 11
MPN: 369 04218
SHIM
from £3.52
from £3.52
# -
-
GUIDE WASHER - VALVE SPRING
# 12
MPN: 369 052016
INTAKE VALVE - $ 8 MMX 117,5 MM
# -
-
INTAKE VALVE - $ 8 MM X 119,5
# -
-
INTAKE VALVE - $ 10 MM X 130,6MM
# 13
MPN: 369 052024
EXHAUST VALVE - $ 8 MM X 128,6 MM
# -
-
EXHAUST VALVE - $ 8 MM X 130,6 MM
# -
-
EXHAUST VALVE - $ 10 MM X 130,6 MM
# -
-
EXHAUST VALVE
(528)
# -
-
STICKER - VALVE CLEARANCE - ALUMINIUM - 15 : 20
# -
-
STICKER - VALVE CLEARANCE - - 10 : 10
--steel
# -
-
sticker 'valve clearance' - 0,10 + 0,15
# -
-
VALVE GUIDE - EXHAUST - 8 X 11 - 1ST OVERSIZE - OLD VERSION
# -
-
VALVE GUIDE - INTAKE - 8 X 11 - 1ST OVERSIZE
# -
-
VALVE GUIDE - EXHAUST - 8 X 14 - 1ST OVERSIZE - FOR - 502. 04.022 - 369. 04.202.2
# -
-
VALVE GUIDE - EXHAUST - AND - INTAKE - 10 X 14 - 1ST OVERSIZE - FOR - 528. 04.022
# 14
MPN: 369 03205
PISTON - COMPLETE - $ 73,5 MM
# 15
MPN: 369 03204
PISTON - $ 73,5 MM
# 16
-
OIL SCRAPER RING - A 73,5 X 5AC
# 17
-
PISTON RINGS - A 73,5 X 3AC
# 18
-
PISTON RINGS - B 73,5 X 3AC
UPPER
# 19
MPN: 369 03215
PISTON PIN - 20 X 63
# 20
MPN: 369 04217
CYLINDER - $ 73,5
# 21
MPN: 506 03010
PISTON - COMPLETE - $ 80
# 22
MPN: 506 031023
PISTON - $ 80
# 23
MPN: 506 03107
PISTON RING - A 80 X 5AC
# 24
MPN: 506 03106
PISTON RING - B 80 X 3AC
# 25
MPN: 506 03105
PISTON RING - B 80 X 3AC
UPPER
# 26
MPN: 506 03108
PISTON PIN - 20 X 63
# 27
MPN: 527 04102
CYLINDER - $ 80 MM - ALUMINIUM
# 28
MPN: 502 03011
PISTON - COMPLETE - $ 80 MM
# 29
MPN: 502 03101
PISTON - $ 80 MM
# 30
-
OIL SCRAPER RING - A 80 X 5AC
# 31
-
PISTON RINGS - B 80 X 3AC
# 32
-
PISTON RINGS - B 80 X 3AC
UPPER
# 33
MPN: 616 03208
PISTON PIN - 22 X 69
# 34
-
CIRCLIP - 22
