( 1300 1300 S 1500 1500 S 1600 1600 S)
porsche 1956 (356/356a) camshaft - m 22 001 >> - m 50 101 >> - m 33 901 >> - m 41 001 >> - m 60 001 >> - m 80 001 >> parts diagram

103-020 - CAMSHAFT - M 22 001 >> - M 50 101 >> - M 33 901 >> - M 41 001 >> - M 60 001 >> - M 80 001 >>

Porsche 1956 (356/356A) CAMSHAFT - M 22 001 >> - M 50 101 >> - M 33 901 >> - M 41 001 >> - M 60 001 >> - M 80 001 >> Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                      #
                                      Part number
                                      Description
                                      Key
                                      Price
                                      # 1
                                      -
                                      CAMSHAFT - ALTERNATIVE PARTS:
                                      (1300/1600)
                                      # -
                                      -
                                      CAMSHAFT - COMPLETE - WITH: - GEAR - SIZE 0
                                      (1300/1600)
                                      # -
                                      -
                                      CAMSHAFT - COMPLETE - WITH: - GEAR - -1
                                      (1300/1600)
                                      # -
                                      -
                                      CAMSHAFT - COMPLETE - WITH: - GEAR - -2
                                      (1300/1600)
                                      # -
                                      -
                                      CAMSHAFT - COMPLETE - WITH: - GEAR - +1
                                      (1300/1600)
                                      # -
                                      -
                                      CAMSHAFT - COMPLETE - WITH: - GEAR - +2
                                      (1300/1600)
                                      # -
                                      -
                                      CAMSHAFT - WITHOUT: - GEAR
                                      (1300/1600)
                                      # 1
                                      -
                                      CAMSHAFT - - ALTERNATIVE PARTS:
                                      (1300 S 1600 S)
                                      # -
                                      -
                                      CAMSHAFT - COMPLETE - WITH: - GEAR - 0
                                      (1300 S 1600 S)
                                      # -
                                      -
                                      CAMSHAFT - COMPLETE - WITH: - GEAR - -1
                                      (1300 S 1600 S)
                                      # -
                                      -
                                      CAMSHAFT - COMPLETE - WITH: - GEAR - -2
                                      (1300 S 1600 S)
                                      # -
                                      -
                                      CAMSHAFT - COMPLETE - WITH: - GEAR - +1
                                      (1300 S 1600 6)
                                      # -
                                      -
                                      CAMSHAFT - COMPLETE - WITH: - GEAR - +2
                                      (1300 S 1600 S)
                                      # 2
                                      -
                                      GEAR - ALTERNATIVE PARTS:
                                      # -
                                      -
                                      gear - aluminium
                                      # -
                                      -
                                      CAMSHAFT SPROCKET - 0 - ALUMINIUM - DISCONTINUED PART
                                      # -
                                      -
                                      CAMSHAFT SPROCKET - 0 - ALUMINIUM
                                      # -
                                      -
                                      GEAR
                                      # -
                                      -
                                      CAMSHAFT SPROCKET - -1 - ALUMINIUM - DISCONTINUED PART
                                      # -
                                      -
                                      CAMSHAFT SPROCKET - -1 - ALUMINIUM
                                      # -
                                      -
                                      GEAR
                                      # -
                                      -
                                      CAMSHAFT SPROCKET - -2 - ALUMINIUM
                                      # -
                                      -
                                      GEAR
                                      # -
                                      -
                                      CAMSHAFT SPROCKET - +1 - ALUMINIUM - DISCONTINUED PART
                                      # -
                                      -
                                      CAMSHAFT SPROCKET - +1 - ALUMINIUM
                                      # -
                                      -
                                      gear - Discontinued part
                                      # -
                                      -
                                      CAMSHAFT SPROCKET
                                      # -
                                      -
                                      GEAR - +2 - ALUMINIUM - DISCONTINUED PART
                                      # -
                                      -
                                      CAMSHAFT SPROCKET - +2 - ALUMINIUM
                                      # 4
                                      MPN: 90007502400
                                      SCREW, HEX. HD. - M 8 X 13 - DISCONTINUED PART
                                      SCREW, HEX. HD. - M 8 X 13 - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                      # 4
                                      MPN: 90007545300
                                      SCREW, HEX. HD. - M 8 X 16
                                      from £0.47
                                      from £0.47
                                      SCREW, HEX. HD. - M 8 X 16 Genuine Porsche Part - New (to order)
                                      # 5
                                      MPN: N 0131991
                                      dowel pin - 6 X 12
                                      from £0.74
                                      from £0.74
                                      dowel pin - 6 X 12 Genuine Porsche Part - New (to order)
                                      PARALLEL PIN 6M6X14 Genuine Lamborghini - New In stock
                                      # 6
                                      MPN: 61610520100
                                      CAM FOLLOWER
                                      (1300/1600)
                                      from £105.12
                                      from £105.12
                                      CAM FOLLOWER Genuine Porsche Part - New (to order)
                                      # 6
                                      MPN: 539 05210
                                      CAM FOLLOWER
                                      (1300 S 1600 S)
                                      from £84.05
                                      from £84.05
                                      CAM FOLLOWER - (RCC) Genuine Porsche Part - New (to order)
                                      # 7
                                      MPN: 61610502802
                                      cam follower - for cylinder - Grey cast iron
                                      (1600/1600 S)
                                      from £80.27
                                      from £80.27
                                      cam follower - for cylinder - Grey cast iron Genuine Porsche Part - New (to order)
                                      # 7
                                      MPN: 61610502600
                                      selector shaft - for cylinder - aluminium
                                      from £77.52
                                      from £77.52
                                      selector shaft - for cylinder - aluminium Genuine Porsche Part - New (to order)
                                      # 8
                                      MPN: 61610523101
                                      PROTECTIVE PIPE - STAINLESS STEEL - ALSO USE:
                                      --539 05 207
                                      from £50.65
                                      from £50.65
                                      protective pipe - Valve pushrod - stainless steel - M 21 180 >> - M 30 530 >> - also use: Genuine Porsche Part - New (to order)
                                      # 9
                                      MPN: 539 05207
                                      GASKET
                                      from £3.25
                                      from £3.25
                                      gasket - for - cam follower - protective pipe Genuine Porsche Part - New (to order)
                                      # 10
                                      MPN: 539 05223
                                      BRIDGE ADAPTER
                                      BRIDGE ADAPTER Genuine Porsche Part - New (to order)
                                      # 11
                                      MPN: 539 05225
                                      ROCKER SHAFT - LONG
                                      ROCKER SHAFT - LONG Genuine Porsche Part - New (to order)
                                      # 12
                                      MPN: 539 05226
                                      ROCKER SHAFT - SHORT
                                      ROCKER SHAFT - SHORT Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: 539 05218
                                      ROCKER ARM - LONG
                                      ROCKER ARM - LONG Genuine Porsche Part - New (to order)
                                      # 15
                                      MPN: 539 05219
                                      ROCKER ARM - SHORT
                                      ROCKER ARM - SHORT Genuine Porsche Part - New (to order)
                                      # 16
                                      MPN: 539 05205
                                      SPRING
                                      from £2.00
                                      from £2.00
                                      spring - for - Rocker arm - M 21 180 >> - M 30 530 >> Genuine Porsche Part - New (to order)
                                      # 17
                                      MPN: 539 05235
                                      thrust washer - 0,50 MM
                                      thrust washer - 0,50 MM Genuine Porsche Part - New (to order)
                                      # 17
                                      MPN: 539 05236
                                      thrust washer - 0,40 MM
                                      thrust washer - 0,40 MM Genuine Porsche Part - New (to order)
                                      # 17
                                      MPN: 539 05237
                                      thrust washer - 0,60 MM
                                      from £3.25
                                      from £3.25
                                      thrust washer - 0,60 MM Genuine Porsche Part - New (to order)
                                      # 18
                                      MPN: N 0124161
                                      LOCK RING - 16 X 1
                                      from £0.51
                                      from £0.51
                                      LOCK RING - 16 X 1 Genuine Porsche Part - New (to order)
                                      RETAINING RING Genuine Lamborghini - New In stock
                                      # 19
                                      MPN: 90007801100
                                      HEX. NUT - M 8 X 1
                                      from £1.82
                                      from £1.82
                                      HEX. NUT - M 8 X 1 Genuine Porsche Part - New (to order)
                                      # 20
                                      MPN: 369 05243
                                      ADJUSTING SCREW
                                      from £12.69
                                      from £12.69
                                      ADJUSTING SCREW - M 21 180 >>- M 30 530 >> Genuine Porsche Part - New (to order)
                                      # 21
                                      MPN: 90007406100
                                      SCREW, HEX. HD. - M 10 X 48
                                      SCREW, HEX. HD. - M 10 X 48 Genuine Porsche Part - New (to order)
