porsche 1956 (356/356a) carburetor - solex 32pbj - solex 40pjcb - and - fuel supply line parts diagram

107-005 - CARBURETOR - SOLEX 32PBJ - SOLEX 40PJCB - AND - FUEL SUPPLY LINE

Porsche 1956 (356/356A) CARBURETOR - SOLEX 32PBJ - SOLEX 40PJCB - AND - FUEL SUPPLY LINE Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                                    #
                                                                    Part number
                                                                    Description
                                                                    Key
                                                                    Price
                                                                    # 1
                                                                    MPN: 506 08101
                                                                    CARBURETOR - 32 PBJ
                                                                    (1300)
                                                                    CARBURETOR - 32 PBJ Genuine Porsche Part - New (to order)
                                                                    # 1
                                                                    MPN: 589 08102
                                                                    CARBURETOR - 32 PBJC
                                                                    (1300 S)
                                                                    CARBURETOR - 32 PBJC Genuine Porsche Part - New (to order)
                                                                    # 1
                                                                    MPN: 616 08101
                                                                    carburetor - 32 PBJC - M >> 67 000
                                                                    (1600)
                                                                    carburetor - 32 PBJC - M >> 67 000 Genuine Porsche Part - New (to order)
                                                                    # 2
                                                                    MPN: 616 08103
                                                                    carburetor - 40 PJCB - M >> 81 200
                                                                    (1600 S)
                                                                    carburetor - 40 PJCB - M >> 81 200 Genuine Porsche Part - New (to order)
                                                                    # 3
                                                                    MPN: 616 08108
                                                                    AIR CLEANER
                                                                    (1300 /S/1600)
                                                                    from £302.89
                                                                    from £302.89
                                                                    AIR CLEANER Genuine Porsche Part - New (to order)
                                                                    # -
                                                                    -
                                                                    AIR CLEANER
                                                                    (1600 S)
                                                                    # 4
                                                                    MPN: 369 08280
                                                                    GASKET
                                                                    (1300 /S/1600)
                                                                    from £5.67
                                                                    from £5.67
                                                                    gasket - mixture control unit Genuine Porsche Part - New (to order)
                                                                    # 5
                                                                    MPN: N 0115301
                                                                    Washer - B 8
                                                                    (1300 /S/1600)
                                                                    from £1.64
                                                                    from £1.64
                                                                    Washer - B 8 Genuine Porsche Part - New (to order)
                                                                    # 6
                                                                    MPN: 502 08310
                                                                    HEX. NUT
                                                                    (1300 /S/1600)
                                                                    from £1.49
                                                                    from £1.49
                                                                    hex. nut - Not for: - (S)(D) - M >> 075 3003 - M >> 083 6549 Genuine Porsche Part - New (to order)
                                                                    # 8
                                                                    MPN: 90002800501
                                                                    LOCK RING - A 10
                                                                    (1600 S)
                                                                    lock ring - D - MJ 1972>> Genuine Porsche Part - New (to order)
                                                                    # 9
                                                                    MPN: 547 01121
                                                                    HEX. NUT
                                                                    (1600 S)
                                                                    HEX. NUT - M10 Genuine Porsche Part - New (to order)
                                                                    # 10
                                                                    MPN: 369 08013
                                                                    LEVER
                                                                    RIGHT
                                                                    LEVER Genuine Porsche Part - New (to order)
                                                                    # 11
                                                                    MPN: 369 08103
                                                                    LEVER
                                                                    LEFT
                                                                    LEVER Genuine Porsche Part - New (to order)
                                                                    # 13
                                                                    MPN: N 0115247
                                                                    WASHER - 6,4 - DISCONTINUED PART
                                                                    Washer - R 6,6 - Discontinued part Genuine Porsche Part - New (to order)
                                                                    # 13
                                                                    MPN: N 01152427
                                                                    WASHER - 6,4
                                                                    from £0.47
                                                                    from £0.47
                                                                    Washer - R 6,6 Genuine Porsche Part - New (to order)
                                                                    WASHER 6.4X12.5X1.6 Genuine Lamborghini - New In stock
                                                                    # 14
                                                                    MPN: 90002100200
                                                                    cotter pin - 1,5 X 10
                                                                    cotter pin - Discontinued part Genuine Porsche Part - New (to order)
                                                                    # 15
                                                                    MPN: 369 08014
                                                                    ADJUSTING RING
                                                                    ADJUSTING RING Genuine Porsche Part - New (to order)
                                                                    # 16
                                                                    MPN: 90007601002
                                                                    NUT - M 6 - DISCONTINUED PART
                                                                    nut - M6 - Discontinued part Genuine Porsche Part - New (to order)
                                                                    # 16
                                                                    MPN: 9000760100B
                                                                    NUT - M 6
                                                                    from £0.73
                                                                    from £0.73
                                                                    NUT - M6 Genuine Porsche Part - New In stock
                                                                    # 18
                                                                    MPN: N 0102056
                                                                    SCREW, HEX. HD. - M 5 X 10 - DISCONTINUED PART
                                                                    screw, hex. hd. - M 5X10 DIN 933-8.8 VERZ. - Discontinued part Genuine Porsche Part - New (to order)
                                                                    # 18
                                                                    MPN: 90007510502
                                                                    SCREW - M 5 X 10
                                                                    from £0.73
                                                                    from £0.73
                                                                    SCREW - M 5X10 DIN 933-8.8 VERZ Genuine Porsche Part - New (to order)
                                                                    # 19
                                                                    MPN: 369 08128
                                                                    ECCENTRIC BOLT
                                                                    (1300 /S/1600)
                                                                    ECCENTRIC BOLT Genuine Porsche Part - New (to order)
                                                                    # 20
                                                                    MPN: 369 08110
                                                                    TENSION SPRING
                                                                    TENSION SPRING Genuine Porsche Part - New (to order)
                                                                    # 22
                                                                    MPN: 369 08131
                                                                    PUSH ROD
                                                                    (1300 /S/1600)
                                                                    push rod - for - 32 PJC Genuine Porsche Part - New (to order)
                                                                    # 22
                                                                    MPN: 369 08111
                                                                    PUSH ROD
                                                                    (1600 S)
                                                                    push rod - for - 40 PJCB Genuine Porsche Part - New (to order)
                                                                    # 23
                                                                    MPN: N 0155213
                                                                    BALL SOCKET - A 8
                                                                    from £16.82
                                                                    from £16.82
                                                                    ball socket - No longer use the part here Genuine Porsche Part - New (to order)
                                                                    # 24
                                                                    MPN: 90007600602
                                                                    hex. nut - M 5
                                                                    HEX. NUT - M5 Genuine Porsche Part - New (to order)
                                                                    # 25
                                                                    MPN: 527 08101
                                                                    ANGULAR JOINT
                                                                    (1300 /S/1600)
                                                                    ANGULAR JOINT Genuine Porsche Part - New (to order)
                                                                    # 26
                                                                    MPN: 369 08107
                                                                    ANGULAR JOINT
                                                                    (1600 S)
                                                                    ANGULAR JOINT Genuine Porsche Part - New (to order)
                                                                    # 27
                                                                    MPN: 90007500400
                                                                    SCREW, HEX. HD. - M 5 X 12
                                                                    SCREW, HEX. HD. - M 5 X 12 Genuine Porsche Part - New (to order)
                                                                    # 28
                                                                    MPN: 369 08134
                                                                    PUSH ROD
                                                                    PUSH ROD Genuine Porsche Part - New (to order)
                                                                    # 29
                                                                    MPN: N 0155213
                                                                    BALL SOCKET - A 8
                                                                    from £16.82
                                                                    from £16.82
                                                                    ball socket - No longer use the part here Genuine Porsche Part - New (to order)
                                                                    # 30
                                                                    MPN: 90007600602
                                                                    hex. nut - M 5
                                                                    HEX. NUT - M5 Genuine Porsche Part - New (to order)
                                                                    # 31
                                                                    MPN: 369 08017
                                                                    RELAY LEVER
                                                                    RELAY LEVER Genuine Porsche Part - New (to order)
                                                                    # 32
                                                                    MPN: 589 08032
                                                                    INTAKE MANIFOLD
                                                                    right ( 1300 /S/1600)
                                                                    INTAKE MANIFOLD Genuine Porsche Part - New (to order)
                                                                    # 32
                                                                    MPN: 589 08031
                                                                    INTAKE MANIFOLD
                                                                    left ( 1300 /S/1600)
                                                                    INTAKE MANIFOLD Genuine Porsche Part - New (to order)
                                                                    # 33
                                                                    MPN: 90006102602
                                                                    STUD - BM 8 X 22
                                                                    (1300 /S/1600)
                                                                    stud - M 8 X 22 Genuine Porsche Part - New (to order)
                                                                    # 34
                                                                    MPN: 528 08032
                                                                    INTAKE MANIFOLD
                                                                    right (1600 S)
                                                                    INTAKE MANIFOLD Genuine Porsche Part - New (to order)
                                                                    # 34
                                                                    MPN: 528 08031
                                                                    INTAKE MANIFOLD
                                                                    left (1600 S)
                                                                    INTAKE MANIFOLD Genuine Porsche Part - New (to order)
                                                                    # 35
                                                                    MPN: 90006104701
                                                                    stud - M 10 X 25
                                                                    (1600 S)
                                                                    stud - M 10 X 25 Genuine Porsche Part - New (to order)
                                                                    # 36
                                                                    MPN: 502 08110
                                                                    gasket - Discontinued part
                                                                    gasket - intake manifold - Discontinued part Genuine Porsche Part - New (to order)
                                                                    # 36
                                                                    MPN: 502 08111
                                                                    GASKET
                                                                    from £6.86
                                                                    from £6.86
                                                                    gasket - intake manifold Genuine Porsche Part - New (to order)
                                                                    # 37
                                                                    MPN: 539 08320
                                                                    RUBBER SLEEVE
                                                                    RUBBER SLEEVE Genuine Porsche Part - New (to order)
                                                                    # 38
                                                                    MPN: 589 08309
                                                                    CONNECTING PIPE
                                                                    CONNECTING PIPE Genuine Porsche Part - New (to order)
                                                                    # 39
                                                                    -
                                                                    DELETED
                                                                    # 40
                                                                    MPN: 90017100100
                                                                    CLAMP - 1 X 18
                                                                    CLAMP - 1 X 18 Genuine Porsche Part - New (to order)
                                                                    # 41
                                                                    MPN: N 0115247
                                                                    WASHER - 6,4 - DISCONTINUED PART
                                                                    Washer - R 6,6 - Discontinued part Genuine Porsche Part - New (to order)
                                                                    # 41
                                                                    MPN: N 01152427
                                                                    WASHER - 6,4
                                                                    from £0.47
                                                                    from £0.47
                                                                    Washer - R 6,6 Genuine Porsche Part - New (to order)
                                                                    WASHER 6.4X12.5X1.6 Genuine Lamborghini - New In stock
                                                                    # 42
                                                                    MPN: 90001412002
                                                                    SCREW, CHEESE HD. - M 6 X 12
                                                                    SCREW, CHEESE HD. - M 6 X 12 Genuine Porsche Part - New (to order)
                                                                    # 43
                                                                    MPN: 616 08021
                                                                    FUEL LINE
                                                                    FUEL LINE Genuine Porsche Part - New (to order)
                                                                    # 44
                                                                    MPN: 616 08022
                                                                    FUEL LINE
                                                                    FUEL LINE Genuine Porsche Part - New (to order)
                                                                    # 45
                                                                    MPN: 61610842300
                                                                    SEAL RING
                                                                    from £0.64
                                                                    from £0.64
                                                                    seal ring - for - banjo bolt Genuine Porsche Part - New (to order)
                                                                    # 46
                                                                    MPN: 61610843200
                                                                    BANJO BOLT
                                                                    BANJO BOLT Genuine Porsche Part - New (to order)
                                                                    # 47
                                                                    MPN: 616 08401
                                                                    fuel pump
                                                                    fuel pump Genuine Porsche Part - New (to order)
                                                                    # -
                                                                    -
                                                                    FUEL PUMP - SINGLE PARTS - SEE GROUP - 1/07/35
                                                                    # -
                                                                    -
                                                                    DIAPHRAGM - FUEL PUMP - COMPLETE
                                                                    # 48
                                                                    MPN: 61610844000
                                                                    GASKET - WITH: - GASKET
                                                                    from £31.90
                                                                    from £31.90
                                                                    gasket - with: - Gaskets - fuel pump Genuine Porsche Part - New (to order)
                                                                    # 49
                                                                    MPN: 616 080421
                                                                    INTERMEDIATE FLANGE
                                                                    INTERMEDIATE FLANGE Genuine Porsche Part - New (to order)
                                                                    # 50
                                                                    MPN: 539 08402
                                                                    GASKET
                                                                    from £5.62
                                                                    from £5.62
                                                                    gasket - M >> 73 236 - M >> 83 423 Genuine Porsche Part - New (to order)
                                                                    # 50
                                                                    MPN: 99970104350
                                                                    O-RING
                                                                    from £3.19
                                                                    from £3.19
                                                                    O-Ring - M 73 237 >> - M 83 424 >> Genuine Porsche Part - New (to order)
                                                                    # 51
                                                                    MPN: 539 08408
                                                                    CAM FOLLOWER
                                                                    CAM FOLLOWER Genuine Porsche Part - New (to order)
                                                                    # 53
                                                                    MPN: 90007403202
                                                                    SCREW, HEX. HD. - M 8 X 25
                                                                    SCREW, HEX. HD. - M 8 X 25 Genuine Porsche Part - New (to order)
