107-020 - SINGLE PARTS - FOR - CARBURETOR - SOLEX 32 PBIC
Porsche 1956 (356/356A) SINGLE PARTS - FOR - CARBURETOR - SOLEX 32 PBIC Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# -
MPN: 616 08901
SET OF GASKETS FOR CARBURETOR
(1300 S 1600)
from £82.20
from £82.20
# 1
MPN: 61610070201
CARBURETOR - HOUSING
(1300 S)
# 1
MPN: 61610070200
CARBURETOR - HOUSING
(1600)
# 2
MPN: 61610070301
CARBURETOR - HOUSING
(1300 S)
# 2
MPN: 61610070300
CARBURETOR - HOUSING
(1600)
# 3
MPN: 61610091200
SHAFT
from £90.52
from £90.52
# 4
MPN: 61610090900
flap
from £6.47
from £6.47
# 5
MPN: 61610098500
SCREW, CSK. HD.
# 6
MPN: 61610098600
SUPPORT
# 7
MPN: 61610098800
ADJUSTING SCREW
from £0.64
from £0.64
# 8
MPN: 61610098900
HEX. NUT
# 9
MPN: 61610099000
ADJUSTING SCREW - IDLING
# 10
MPN: 61610099100
PRESSURE SPRING
from £4.33
from £4.33
# 11
MPN: 91110094500
LOCK WASHER
# 12
MPN: 61610098700
LEVER
# 13
MPN: 61610091300
HEX. NUT
from £3.75
from £3.75
# 14
MPN: 61610075500
ADJUSTING SCREW
from £14.25
from £14.25
# 15
MPN: 61610081400
PRESSURE SPRING
from £2.88
from £2.88
# 16
MPN: 61610099400
THREADED PLUG
# 17
MPN: 61610090600
FLOAT - 5,7 GR
from £48.49
from £48.49
# 18
MPN: 61610091100
PIVOT PIN
from £2.34
from £2.34
# 19
MPN: 61610089801
FUNNEL - (K) 24
(1300 S)
from £15.48
from £15.48
# 19
MPN: 61610089800
FUNNEL - (K) 26
(1600)
# 20
MPN: 61610099900
SCREW - FUNNEL
# 21
MPN: 61610070400
TUBE - 33
from £12.05
from £12.05
# 22
MPN: 61610090000
JET - (A) 200
# 23
MPN: 61610091400
NOZZLE HOLDER
from £6.07
from £6.07
# 24
MPN: 61610089903
JET - (GG) 0105
# 24
MPN: 61610089904
JET - (GG) 0112,5
# 25
MPN: 61610091500
SEAL RING
from £2.79
from £2.79
# 26
MPN: 61610090100
JET - (G) 50
# 27
MPN: 61610090203
JET - (U) 1,5
from £7.17
from £7.17
# 28
MPN: 61610070100
THREADED PLUG
# 29
MPN: 90110897600
SEAL RING
from £1.09
from £1.09
# 30
MPN: 61610070800
JET - (GP) 60
# 31
MPN: 61610093700
SEAL RING
from £2.46
from £2.46
# 32
MPN: 61610094300
VALVE
# 33
MPN: 61610094400
STRAINER
from £3.20
from £3.20
# 34
MPN: 61610093700
SEAL RING
from £2.46
from £2.46
# 35
MPN: 61610070900
tube - complete - 0,8 CAL.
# 36
MPN: 61610094800
GASKET
# 37
MPN: 61610071000
SCREW, CSK. HD.
# 38
MPN: 61610071100
pump - complete - 72
# 39
MPN: 61610071200
Lower part
# 40
MPN: 61610095200
SPRING
# 41
MPN: 61610071300
DIAPHRAGM
# 42
MPN: 61610072700
COVER - COMPLETE
# 43
MPN: 61610095401
COVER
from £31.88
from £31.88
# 44
MPN: 61610074500
LEVER
# 45
MPN: 61610095600
PIVOT PIN
from £7.04
from £7.04
# 46
MPN: 61610071600
SCREW, CSK. HD.
# 47
MPN: 61610095700
GASKET
from £6.94
from £6.94
# 48
MPN: 61610071700
SCREW, CSK. HD.
# 49
MPN: 61610071800
CONNECTING ROD - COMPLETE
from £16.90
from £16.90
# 50
MPN: 61610071900
CONNECTING ROD
# 51
MPN: 61610096300
COTTER PIN
# 52
MPN: 61610096200
WASHER
# 53
MPN: 61610072000
SPRING
# 54
MPN: 61610072200
BUSHING
# 55
MPN: 61610072100
NUT
# 56
MPN: 61610072300
HEX. NUT
# -
-
COVER PLATE
# -
-
GASKET - COVER PLATE
# -
-
SCREW, CSK. HD.
# 57
MPN: 61610074600
COVER - CARBURETOR
# 58
MPN: 61610073600
DISC VALVE - 1,5 MM
# 59
MPN: 61610842300
SEAL RING
from £0.64
from £0.64
# 60
MPN: 61610091000
GASKET
# 61
MPN: 61610093400
ADJUSTING SCREW
from £2.07
from £2.07
# 62
MPN: 61610097300
CONNECTING ROD
# 63
MPN: 61610842300
SEAL RING
from £0.64
from £0.64
# 64
MPN: 61610843200
BANJO BOLT
