107-042 - CARBURETOR - SOLEX 40 P II-4/WEBER - AND - FUEL SUPPLY LINE
Porsche 1956 (356/356A) CARBURETOR - SOLEX 40 P II-4/WEBER - AND - FUEL SUPPLY LINE Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 69210810300
CARBURETOR - SOLEX 40 P II-4
(6921)
# -
-
CARBURETOR - SOLEX 40 P II-4
(6922)
# -
-
CARBURETOR - WEBER
(692/3)
# 3
MPN: 502 08305
GASKET - CARBURETOR - SOLEX
(692/1/2)
# 3
MPN: 69210890100
GASKET - CARBURETOR - WEBER
(692/3)
# 4
MPN: 69210801500
LEVER - CARBURETOR - SOLEX
left (692/1/2)
# 4
MPN: 69210801700
lever - carburetor - WEBER
left (692/3)
# 5
MPN: 69210801600
LEVER - CARBURETOR - SOLEX
right (692/1/2)
# 5
MPN: 69210801800
lever - carburetor - WEBER
right (692/3)
# -
-
LEVER - FOR - FUEL PUMP - CARBURETOR - WEBER
(692/3)
# -
-
BOW - CARBURETOR - SOLEX
(692/1/2)
# -
-
BOW - CARBURETOR - WEBER
(692/3)
# -
-
BOW - CARBURETOR - SOLEX
(692/1/2)
# -
-
BOW - CARBURETOR - WEBER
(692/3)
# -
-
RELAY LEVER
(692/1/2)
# -
-
RELAY LEVER
(692/3)
# 7
MPN: 90016900700
BALL SOCKET
# 8
MPN: 90007600500
hex. nut - M 5
# 12
MPN: 69210864000
PUSH ROD
# 13
MPN: 90016900900
SECURING CLIP
# -
-
PRESSURE SPRING
# -
-
BALL PIN
# -
-
NUT, SLOTTED - M 6
# -
-
cotter pin - 1,5 X 15
# -
-
TENSION SPRING
# 18
MPN: 547 08230
FUEL LINE
(692/1/2)
# -
-
fuel line - fuel filter - carburetor
(692/1/2)
# -
-
fuel line - fuel filter - carburetor - with: - - EBERSPAECHER - - heater
(6922)
# -
-
FUEL HOSE - FUEL FILTER - HEATER
(6922)
# 19
MPN: 356 49648
CLAMP
# 20
MPN: 547 08239
FUEL LINE
# 21
MPN: 90110821900
CAP
from £12.70
from £12.70
# 22
MPN: 547 08255
LINE - CARBURETOR - SOLEX
left (692/1/2)
# -
-
LINE - CARBURETOR - WEBER
left (692/3)
# 23
MPN: 547 08256
LINE - CARBURETOR - SOLEX
right (692/1/2)
# -
-
LINE - CARBURETOR - WEBER
right (692/3)
# 24
MPN: 547 08318
INTAKE MANIFOLD - CARBURETOR - SOLEX
left (692/1/2)
# 25
MPN: 547 08319
INTAKE MANIFOLD - CARBURETOR - SOLEX
right (692/1/2)
# -
-
INTAKE MANIFOLD - CARBURETOR - WEBER
(692/3)
# 26
MPN: 547 08320
STUD
(692/1/2)
# 26
MPN: 90006102202
STUD - 8 X 12
(692/3)
# 27
MPN: N 0122301
spring washer - A 10
(692/1/2)
from £0.69
from £0.69
# 27
MPN: 90002800401
spring washer - A 10
(692/3)
# 28
MPN: 547 01121
hex. nut - M 10
(692/1/2)
# 28
MPN: 502 08310
hex. nut - M 10
(692/3)
from £1.49
from £1.49
# 29
MPN: 547 08313
GASKET
# 32
MPN: 547 08323
GUIDE SLEEVE
# 33
MPN: 547 08324
SEAL RING
from £3.97
from £3.97
# 34
MPN: 547 08325
WASHER
# 35
MPN: 000 95507
nut, slotted
# 36
MPN: 90002100900
COTTER PIN - 2 X 18
# 37
MPN: 61610820301
air cleaner - for - carburetor - SOLEX
(692/1/2)
from £292.23
from £292.23
# -
-
AIR CLEANER - FOR - CARBURETOR - WEBER
(692/3)
# 38
MPN: 90007402600
SCREW, HEX. HD. - M 6 X 95
(692/1/2)
# -
-
SCREW, HEX. HD. - M 5 X 100 - CARBURETOR - WEBER
(692/3)
# -
-
stud - M 5 X 15
(692/3)
# -
-
LOCK RING - B 5
(692/3)
# -
-
hex. nut - M 5
(692/3)
# 39
MPN: 90002800800
SPRING WASHER - B 6
(692/1/2)
# 39
MPN: 90002800700
SPRING WASHER - B 5
(692/3)
# 41
MPN: 61610829100
gasket - for - Intake trumpet
(692/1/2)
from £10.83
from £10.83
# 43
MPN: 90007501000
SCREW, HEX. HD. - M 6 X 12
(692/1/2)
# 43
-
SCREW, HEX. HD. - M 5 X 22
(692/3)
# 44
MPN: 61610842300
SEAL RING
(692/1/2)
from £0.64
from £0.64
# 45
MPN: 69210098100
SEAL RING
(692/1/2)
# -
-
SINGLE PARTS - FOR - CARBURETOR - SOLEX
(6922)
# -
-
VENTURI - 34
(6922)
# -
-
MAIN JET - GG 0110
(6922)
# -
-
AIR CORRECTION JET - A 220
(6922)
# -
-
PILOT JET - G 55
(6922)
# -
-
jet - 1,6
(6922)
# -
-
JET - GP 50
(6922)
# -
-
TUBE - 25 - DISCONTINUED PART
(6922)
# -
-
TUBE - 25
(6922)
# -
-
VALVE - 2 - DISCONTINUED PART
(6922)
# -
-
VALVE - 2
(6922)
# -
-
FLOAT - PLASTIC - 10 GR
(692/3)
# -
-
INJECTION PUMP - 72
(6922)
# -
-
BALL VALVE - WITH: - BALL
(6922)
# -
-
SINGLE PARTS - FOR VEHICLES WITH - CARBURETOR PRE-HEATING
(692/2/3)
# -
-
ADAPTER
left (692/2/3)
# -
-
ADAPTER
right (692/2/3)
# -
-
FLAP - FOR - ADAPTER
(692/2/3)
# -
-
COTTER PIN - 3 X 45
(692/2/3)
# -
-
SPRING CLIP
(692/2/3)
# -
-
WASHER
(692/2/3)
# -
-
SCREW, CHEESE HD.
(692/2/3)
# -
-
ADAPTER
(692/3)
# -
-
CLAMP
(692/3)
# -
-
AIR DUCT - FOR VEHICLES WITH - CARBURETOR PRE-HEATING
(6922)
# -
-
HOSE - FOR VEHICLES WITH - CARBURETOR PRE-HEATING
(6922)
# -
-
HOSE - FOR VEHICLES WITH - CARBURETOR PRE-HEATING
(692/3)
# -
-
HOSE CLIP
(6922)
# -
-
HOSE CLIP
(692/3)
