front-rear
porsche 1956 (356/356a) cover - - and - with installation parts - to fit use workshop material parts diagram

803-000 - COVER - - AND - WITH INSTALLATION PARTS - TO FIT USE WORKSHOP MATERIAL

Porsche 1956 (356/356A) COVER - - AND - WITH INSTALLATION PARTS - TO FIT USE WORKSHOP MATERIAL Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # 1
    MPN: 356 52050
    COVER - WITHOUT: - LOCK - AND - HINGE
    FRONT (356)
    COVER - WITHOUT: - LOCK - AND - HINGE Genuine Porsche Part - New (to order)
    # 1
    MPN: 64451101000
    COVER - WITHOUT: - LOCK - AND - HINGE
    front (356 A)
    COVER - WITHOUT: - LOCK - AND - HINGE Genuine Porsche Part - New (to order)
    # 2
    MPN: 356 52073
    PUSH-BUTTON LOCK - COMPLETE
    (356)
    PUSH-BUTTON LOCK - COMPLETE Genuine Porsche Part - New (to order)
    # 2
    MPN: 64451105100
    LOCK - COMPLETE
    (356 A)
    LOCK - COMPLETE Genuine Porsche Part - New (to order)
    # 3
    MPN: 356 520731
    PUSH-BUTTON LOCK - UPPER PART - PIN - HOOK - SPRING
    (356)
    PUSH-BUTTON LOCK - UPPER PART - PIN - HOOK - SPRING Genuine Porsche Part - New (to order)
    # 3
    MPN: 64451105300
    LOCK - UPPER PART - PIN - HOOK - SPRING
    (356 A)
    LOCK - UPPER PART - PIN - HOOK - SPRING Genuine Porsche Part - New (to order)
    # 4
    MPN: 356 520733
    SPRING
    (356)
    SPRING Genuine Porsche Part - New (to order)
    # 5
    MPN: 356 520732
    PUSH-BUTTON LOCK - LOWER PART
    (356)
    PUSH-BUTTON LOCK - LOWER PART Genuine Porsche Part - New (to order)
    # 5
    MPN: 64451105400
    LOCK - LOWER PART - WITHOUT: - SPRING
    (356 A)
    LOCK - LOWER PART - WITHOUT: - SPRING Genuine Porsche Part - New (to order)
    # 6
    MPN: 64451151200
    TENSION SPRING - $ 8 X 1 X 30 MM
    (356 A)
    TENSION SPRING - $ 8 X 1 X 30 MM Genuine Porsche Part - New (to order)
    # 7
    MPN: 64451103100
    HINGE
    (356)
    from £273.94
    from £273.94
    hinge - Not for: - -CARRERA GT- Genuine Porsche Part - New (to order)
    # 7
    MPN: 64451103100
    hinge - Not for: - -CARRERA GT-
    (356 A)
    from £273.94
    from £273.94
    hinge - Not for: - -CARRERA GT- Genuine Porsche Part - New (to order)
    # 7
    MPN: 64451103100
    HINGE
    (356 A CARRERA GT COUPE SPEEDSTER)
    from £273.94
    from £273.94
    hinge - Not for: - -CARRERA GT- Genuine Porsche Part - New (to order)
    # 8
    MPN: 356 24064
    CABLE - HOOD LATCH - WITH: - BUTTON - IVORY - GREY - BEIGE
    (356)
    CABLE - HOOD LATCH - WITH: - BUTTON - IVORY - GREY - BEIGE Genuine Porsche Part - New (to order)
    # 8
    MPN: 64442409100
    WIRE PULL - WITH: - BUTTON - GREY - BEIGE
    (356 A)
    WIRE PULL - WITH: - BUTTON - GREY - BEIGE Genuine Porsche Part - New (to order)
    # 9
    MPN: 64455281100
    BUTTON - CABLE - HOOD LATCH
    (356 A)
    BUTTON - CABLE - HOOD LATCH Genuine Porsche Part - New (to order)
    # 10
    MPN: 99970600980
    SUSPENSION STRAP
    (356 A:CABRIO)
    Suspension strap - Short Genuine Porsche Part - New (to order)
    # 10
    MPN: 91142434101
    SUSPENSION STRAP - DISCONTINUED PART
    (356 A:CABRIO)
    Suspension strap - Short - Discontinued part Genuine Porsche Part - New (to order)
    # 10
    MPN: 91142434103
    SUSPENSION STRAP
    (356 A:CABRIO)
    from £5.99
    from £5.99
    Suspension strap - Short Genuine Porsche Part - New (to order)
    # 11
    MPN: 64451107021
    lock
    (356 A:CABRIO)
    LOCK - WITH 2 SECONDARY KEYS Genuine Porsche Part - New (to order)
    # 12
    MPN: 64451107321
    BRACKET
    (356 A:CABRIO)
    BRACKET Genuine Porsche Part - New (to order)
    # 13
    MPN: 90015102702
    WASHER - A 5,3 - DISCONTINUED PART
    (356 A:CABRIO)
    Washer - F 92-A0411 806>> - F 93-A0140 314>> - Discontinued part Genuine Porsche Part - New (to order)
    # 13
    MPN: 90015102703
    Washer - A 5,3
    (356 A:CABRIO)
    from £0.65
    from £0.65
    Washer - F 92-A0411 806>> - F 93-A0140 314>> Genuine Porsche Part - New (to order)
    # 14
    MPN: 90002800200
    LOCK RING - A 5
    (356 A:CABRIO)
    lock ring - A 5 - for - vent tube Genuine Porsche Part - New (to order)
    # 15
    MPN: 90007600602
    hex. nut - M 5
    (356 A:CABRIO)
    HEX. NUT - M5 Genuine Porsche Part - New (to order)
    # 16
    MPN: 64442490101
    WIRE PULL - 1700 MM
    (356 A)
    from £81.92
    from £81.92
    WIRE PULL - 1700 MM Genuine Porsche Part - New (to order)
    # 17
    MPN: 64442495100
    cable clamp - Discontinued part
    cable clamp - Wire pull - Discontinued part Genuine Porsche Part - New (to order)
    # -
    -
    BEARING PIN
    # -
    -
    SCREW, HEX. HD. - FOR - NIPPLE - DISCONTINUED PART
    # -
    -
    SCREW - FOR - NIPPLE
    # 18
    MPN: 64451190106
    GASKET - RUBBER SEAL - 3750 MM
    (356)
    from £31.47
    from £31.47
    GASKET - RUBBER SEAL - 3750 MM Genuine Porsche Part - New (to order)
    # 18
    MPN: 64451190106
    GASKET - RUBBER SEAL - 3750 MM
    (356 A)
    from £31.47
    from £31.47
    GASKET - RUBBER SEAL - 3750 MM Genuine Porsche Part - New (to order)
    # 19
    MPN: 356 52506
    REINFORCEMENT - TREAD
    (356)
    REINFORCEMENT - TREAD Genuine Porsche Part - New (to order)
    # 19
    MPN: 64451191100
    CORNER PANEL - TREAD
    (356 A)
    from £18.13
    from £18.13
    CORNER PANEL - TREAD Genuine Porsche Part - New (to order)
    # 20
    MPN: 356 52060
    COVER - WITHOUT: - LOCK - AND - HINGE
    (356)
    COVER - WITHOUT: - LOCK - AND - HINGE Genuine Porsche Part - New (to order)
    # 20
    MPN: 64451200100
    COVER - WITHOUT: - LOCK - AND - HINGE
    (356 A:COUPE)
    COVER - WITHOUT: - LOCK - AND - HINGE Genuine Porsche Part - New (to order)
    # 20
    MPN: 64451200101
    COVER - WITHOUT: - LOCK - AND - HINGE
    (356 A CARRERA COUPE)
    COVER - WITHOUT: - LOCK - AND - HINGE Genuine Porsche Part - New (to order)
    # 20
    MPN: 64451200126
    COVER - WITHOUT: - LOCK - AND - HINGE - NOT FOR: - -CARRERA GT-
    (356 A:CABRIO SPEEDSTER)
    COVER - WITHOUT: - LOCK - AND - HINGE - NOT FOR: - -CARRERA GT- Genuine Porsche Part - New (to order)
    # 20
    MPN: 64451200126
    COVER - WITHOUT: - LOCK - AND - HINGE
    (356 A CARRERA GT CABRIO SPEEDSTER)
    COVER - WITHOUT: - LOCK - AND - HINGE - NOT FOR: - -CARRERA GT- Genuine Porsche Part - New (to order)
    # 21
    MPN: 356 52075
    PUSH-BUTTON LOCK - COMPLETE
    (356)
    PUSH-BUTTON LOCK - COMPLETE Genuine Porsche Part - New (to order)
    # 21
    MPN: 64451205101
    LOCK - COMPLETE
    (356 A)
    LOCK - COMPLETE Genuine Porsche Part - New (to order)
    # 22
    MPN: 356 520751
    PUSH-BUTTON LOCK - UPPER PART
    (356)
    PUSH-BUTTON LOCK - UPPER PART Genuine Porsche Part - New (to order)
    # 22
    MPN: 64451251101
    LOCK - UPPER PART
    (356 A)
    LOCK - UPPER PART Genuine Porsche Part - New (to order)
    # 23
    MPN: 356 520752
    PUSH-BUTTON LOCK - LOWER PART
    (356)
    PUSH-BUTTON LOCK - LOWER PART Genuine Porsche Part - New (to order)
    # 23
    MPN: 64451205201
    LOCK - LOWER PART
    (356 A)
    LOCK - LOWER PART Genuine Porsche Part - New (to order)
    # 24
    MPN: 64451203100
    HINGE
    left (356)
    from £174.38
    from £174.38
    hinge - Not for: - -CARRERA GT- Genuine Porsche Part - New (to order)
    # 24
    MPN: 64451203100
    hinge - Not for: - -CARRERA GT-
    left (356 A)
    from £174.38
    from £174.38
    hinge - Not for: - -CARRERA GT- Genuine Porsche Part - New (to order)
    # 24
    MPN: 64451203100
    HINGE
    left (356 A CARRERA GT COUPE SPEEDSTER)
    from £174.38
    from £174.38
    hinge - Not for: - -CARRERA GT- Genuine Porsche Part - New (to order)
    # 24
    MPN: 64451203200
    HINGE
    right (356)
    from £189.47
    from £189.47
    hinge - Not for: - -CARRERA GT- Genuine Porsche Part - New (to order)
    # 24
    MPN: 64451203200
    hinge - Not for: - -CARRERA GT-
    right (356 A)
    from £189.47
    from £189.47
    hinge - Not for: - -CARRERA GT- Genuine Porsche Part - New (to order)
    # 24
    MPN: 64451203200
    HINGE
    right (356 A CARRERA GT COUPE SPEEDSTER)
    from £189.47
    from £189.47
    hinge - Not for: - -CARRERA GT- Genuine Porsche Part - New (to order)
    # 25
    MPN: 356 52812
    RUBBER BUFFER - $ 8 MM
    (356)
    RUBBER BUFFER - $ 8 MM Genuine Porsche Part - New (to order)
    # 25
    MPN: 99970308640
    PLUG - $ 8 MM
    (356 A)
    from £2.48
    from £2.48
    plug - D - MJ 1993>> Genuine Porsche Part - New (to order)
    # -
    -
    RETAINING STRAP - COVER
    front (356 A CARRERA GT COUPE SPEEDSTER)
