porsche 1958 (356/356a) fuel tank parts diagram

201-000 - FUEL TANK

Porsche 1958 (356/356A) FUEL TANK Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
          #
          Part number
          Description
          Key
          Price
          # 1
          MPN: 356 56012
          FUEL TANK
          RHD
          FUEL TANK Genuine Porsche Part - New (to order)
          # 1
          MPN: 64420101000
          FUEL TANK - 50 L
          FUEL TANK - 50 L Genuine Porsche Part - New (to order)
          # 1
          MPN: 356 56013
          FUEL TANK - F >> 53 526 - F >> 60 815
          lhd ( COUPE CABRIO)
          FUEL TANK - F >> 53 526 - F >> 60 815 Genuine Porsche Part - New (to order)
          # 1
          MPN: 356 560131
          fuel tank - F 53 527 >> - F 60 816 >>
          lhd ( COUPE CABRIO)
          fuel tank - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 2
          MPN: 64420101050
          FUEL TANK - 80 L
          (356 A/540.1)
          FUEL TANK - 80 L Genuine Porsche Part - New (to order)
          # 2
          MPN: 644 56015
          FUEL TANK - 72 L
          (356)
          FUEL TANK - 72 L Genuine Porsche Part - New (to order)
          # -
          -
          PETROL DIPSTICK LITRES - WITH LEATHER CASE
          # -
          -
          PETROL DIPSTICK GALLONS - WITH LEATHER CASE
          # 3
          MPN: 64420127000
          SEALING CAP
          (356 A/540.1)
          Supersession
          Supersession
          Genuine Porsche Part (no longer available to order)
          # 3
          MPN: 356 56003
          SEALING CAP
          (356)
          SEALING CAP Genuine Porsche Part - New (to order)
          # 4
          MPN: 64420127900
          SEAL RING
          (356 A/540.1)
          from £14.64
          from £14.64
          seal ring - sealing cap Genuine Porsche Part - New (to order)
          # 4
          MPN: 64420127900
          SEAL RING
          (356)
          from £14.64
          from £14.64
          seal ring - sealing cap Genuine Porsche Part - New (to order)
          # 5
          MPN: 64420161100
          VENT HOSE
          (356 A/540.1)
          VENT HOSE Genuine Porsche Part - New (to order)
          # 5
          MPN: 356 56106
          VENT HOSE - 950 MM
          (356)
          VENT HOSE - 950 MM Genuine Porsche Part - New (to order)
          # 6
          MPN: 64420102100
          FUEL COCK - FUEL RESERVE - 50 L
          (356 A/540.1)
          FUEL COCK - FUEL RESERVE - 50 L Genuine Porsche Part - New (to order)
          # 6
          MPN: 356 56022
          switch - F >> 53 526 - F >> 60 815
          ( COUPE CABRIO)
          switch - F >> 53 526 - F >> 60 815 Genuine Porsche Part - New (to order)
          # 6
          MPN: 64420102107
          SWITCH - F 53 527 >> - F 60 816 >>
          ( COUPE CABRIO)
          from £184.55
          from £184.55
          switch - Fuel reserve - complete Genuine Porsche Part - New (to order)
          # 7
          MPN: 64420102107
          SWITCH - FUEL RESERVE - 80 L
          (356 A/540.1)
          from £184.55
          from £184.55
          switch - Fuel reserve - complete Genuine Porsche Part - New (to order)
          # 8
          MPN: 64420129100
          SEAL RING
          (356 A/540.1)
          from £5.43
          from £5.43
          seal ring - 18 X 13 X 1,5 - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 8
          -
          SEAL RING - A 12 X 16 - F >> 53 526 - F >> 60 815
          ( COUPE CABRIO)
          # 8
          MPN: 64420129100
          seal ring - 18 X 13 X 1,5 - F 53 527 >> - F 60 816 >>
          ( COUPE CABRIO)
          from £5.43
          from £5.43
          seal ring - 18 X 13 X 1,5 - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 9
          MPN: 64420122500
          FUEL STRAINER - INSERT
          (356 A/540.1)
          from £9.62
          from £9.62
          Fuel strainer - insert - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 9
          MPN: 356 56203
          strainer - insert - F >> 53 526 - F >> 60 815
          ( COUPE CABRIO)
          strainer - insert - F >> 53 526 - F >> 60 815 Genuine Porsche Part - New (to order)
          # 9
          MPN: 64420122500
          Fuel strainer - insert - F 53 527 >> - F 60 816 >>
          ( COUPE CABRIO)
          from £9.62
          from £9.62
          Fuel strainer - insert - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 10
          MPN: 64420122100
          UNION NUT - FUEL COCK
          (356 A/540.1)
          from £11.98
          from £11.98
          UNION NUT - FUEL COCK Genuine Porsche Part - New (to order)
          # 10
          MPN: 356 56207
          nut - F >> 53 526 - F >> 60 815
          ( COUPE CABRIO)
          nut - F >> 53 526 - F >> 60 815 Genuine Porsche Part - New (to order)
          # 10
          MPN: 550 56206
          nut - F 53 527 >> - F 60 816 >>
          ( COUPE CABRIO)
          nut - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 11
          MPN: 64420129200
          SEALING WASHER
          (356 A/540.1)
          from £3.78
          from £3.78
          sealing washer - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 11
          MPN: 356 56108
          sealing washer - F >> 53 526 - F >> 60 815
          ( COUPE CABRIO)
          sealing washer - F >> 53 526 - F >> 60 815 Genuine Porsche Part - New (to order)
          # 11
          MPN: 64420129200
          sealing washer - F 53 527 >> - F 60 816 >>
          ( COUPE CABRIO)
          from £3.78
          from £3.78
          sealing washer - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 12
          MPN: 64420120300
          SEAL RING
          (356 A/540.1)
          from £5.98
          from £5.98
          seal ring - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 12
          MPN: 356 56208
          seal ring - F >> 53 526 - F >> 60 815
          ( COUPE CABRIO)
          seal ring - F >> 53 526 - F >> 60 815 Genuine Porsche Part - New (to order)
          # 12
          MPN: 64420120300
          seal ring - F 53 527 >> - F 60 816 >>
          ( COUPE CABRIO)
          from £5.98
          from £5.98
          seal ring - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 13
          MPN: 64420120400
          FILTER
          (356 A/540.1)
          from £5.98
          from £5.98
          Filter - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 13
          MPN: 356 5620900
          Filter - F >> 53 526 - F >> 60 815
          ( COUPE CABRIO)
          Filter - F >> 53 526 - F >> 60 815 Genuine Porsche Part - New (to order)
          # 13
          MPN: 64420120400
          Filter - F 53 527 >> - F 60 816 >>
          ( COUPE CABRIO)
          from £5.98
          from £5.98
          Filter - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 14
          MPN: 64420120500
          FILTER
          (356 A/540.1)
          FILTER Genuine Porsche Part - New (to order)
          # 14
          MPN: 356 5621000
          container - F >> 53 526 - F >> 60 815
          ( COUPE CABRIO)
          container - F >> 53 526 - F >> 60 815 Genuine Porsche Part - New (to order)
          # 14
          MPN: 550 56214
          container - F 53 527 >> - F 60 816 >>
          ( COUPE CABRIO)
          container - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 15
          MPN: 64420120600
          LOCK RING
          (356 A/540.1)
          LOCK RING Genuine Porsche Part - New (to order)
          # 15
          MPN: 356 56205
          lock ring - F >> 53 526 - F >> 60 815
          ( COUPE CABRIO)
          lock ring - F >> 53 526 - F >> 60 815 Genuine Porsche Part - New (to order)
          # 15
          MPN: 550 56218
          lock ring - F 53 527 >> - F 60 816 >>
          ( COUPE CABRIO)
          lock ring - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 16
          MPN: 64420120700
          GASKET - $ 22 MM
          (356 A/540.1)
          GASKET - $ 22 MM Genuine Porsche Part - New (to order)
          # 16
          MPN: 64420129300
          GASKET - $ 26 MM
          (356 A/540.1)
          from £5.35
          from £5.35
          GASKET - $ 26 MM Genuine Porsche Part - New (to order)
          # 16
          MPN: 356 56206
          gasket - F >> 53 526 - F >> 60 815
          ( COUPE CABRIO)
          gasket - F >> 53 526 - F >> 60 815 Genuine Porsche Part - New (to order)
          # 16
          MPN: 550 56219
          gasket - F 53 527 >> - F 60 816 >>
          ( COUPE CABRIO)
          gasket - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 17
          MPN: 64420123150
          SEAL RING - TUBE
          (356 A/540.1)
          SEAL RING - TUBE Genuine Porsche Part - New (to order)
          # 18
          -
          DELETED
          # 19
          MPN: 64420124300
          HOSE PIECE - OPERATING ROD
          (356 A/540.1)
          HOSE PIECE - OPERATING ROD Genuine Porsche Part - New (to order)
          # 19
          MPN: 356 56107
          HOSE PIECE - OPERATING ROD
          (356)
          HOSE PIECE - OPERATING ROD Genuine Porsche Part - New (to order)
          # 20
          MPN: 64420126100
          STICKER
          (356 A/540.1)
          Sticker - AUF-ZU-RESERVE Genuine Porsche Part - New (to order)
          # 20
          MPN: 356 56102
          STICKER
          (356)
          STICKER Genuine Porsche Part - New (to order)
          # 21
          MPN: 90001600200
          SCREW, BUTTON HD. - M 4 X 10
          SCREW, BUTTON HD. - M 4 X 10 Genuine Porsche Part - New (to order)
          # 22
          MPN: 90007600202
          hex. nut - M 4
          hex. nut - M 4 Genuine Porsche Part - New (to order)
          # 23
          MPN: 64420124100
          OPERATING ROD - FOR - SWITCH
          (356 A/540.1)
          OPERATING ROD - FOR - SWITCH Genuine Porsche Part - New (to order)
          # 23
          MPN: 356 56101
          OPERATING ROD - FOR - SWITCH
          (356)
          OPERATING ROD - FOR - SWITCH Genuine Porsche Part - New (to order)
          # 24
          MPN: 64402561100
          RUBBER GROMMET
          (356 A/540.1)
          RUBBER GROMMET Genuine Porsche Part - New (to order)
          # 24
          MPN: 356 56105
          GROMMET
          (356)
          GROMMET Genuine Porsche Part - New (to order)
          # 25
          MPN: N 0125221
          COTTER PIN - 3 X 22
          COTTER PIN - 3 X 22 Genuine Porsche Part - New (to order)
          # 26
          MPN: 99918003050
          fuel hose - Discontinued part
          (356 A/540.1)
          fuel hose - Discontinued part Genuine Porsche Part - New (to order)
          # 26
          MPN: 9991800305A
          FUEL HOSE
          (356 A/540.1)
          from £30.85
          from £30.85
          fuel hose - C6 X 11 X 250 MM Genuine Porsche Part - New (to order)
          # 27
          MPN: 61610853100
          FUEL LINE - 1860 MM
          (356 A/540.1)
          FUEL LINE - 1860 MM Genuine Porsche Part - New (to order)
          # 28
          MPN: 356 49648
          CLAMP
          (356 A/540.1)
          clamp - S 8 MM Genuine Porsche Part - New (to order)
          # 28
          MPN: 90017200100
          CLAMP
          (356 A/540.1)
          Clamp - 12 Genuine Porsche Part - New (to order)
          # 29
          MPN: 90007400502
          SCREW, HEX. HD. - M 5 X 22
          (356 A/540.1)
          SCREW, HEX. HD. - M 5 X 22 Genuine Porsche Part - New (to order)
          # 30
          MPN: N 0122252
          SPRING WASHER - B 5
          (356 A/540.1)
          from £0.92
          from £0.92
          spring washer - B5 - D - MJ 1972>> Genuine Porsche Part - New (to order)
          # 31
          MPN: 90007600402
          hex. nut - M 5
          (356 A/540.1)
          hex. nut - M 5 Genuine Porsche Part - New (to order)
          # -
          -
          BOOT
          (356 A/540.1)
          # 32
          MPN: 91435620100
          RUBBER GROMMET
          (356 A/540.1)
          from £5.08
          from £5.08
          Rubber grommet - D >> - MJ 1974 Genuine Porsche Part - New (to order)
          # 33
          MPN: 99918003050
          fuel hose - Discontinued part
          (356 A/540.1)
          fuel hose - Discontinued part Genuine Porsche Part - New (to order)
          # 33
          MPN: 9991800305A
          FUEL HOSE
          (356 A/540.1)
          from £30.85
          from £30.85
          fuel hose - C6 X 11 X 250 MM Genuine Porsche Part - New (to order)
          # 34
          MPN: 99970600980
          SUSPENSION STRAP
          (356 A/540.1)
          Suspension strap - Short Genuine Porsche Part - New (to order)
          # 34
          MPN: 91142434101
          SUSPENSION STRAP - DISCONTINUED PART
          (356 A/540.1)
          Suspension strap - Short - Discontinued part Genuine Porsche Part - New (to order)
          # 34
          MPN: 91142434103
          SUSPENSION STRAP
          (356 A/540.1)
          from £8.54
          from £8.54
          Suspension strap - Short Genuine Porsche Part - New (to order)
          # 35
          MPN: 64420162100
          TAILPIPE - BLEEDING
          (356 A/540.1)
          TAILPIPE - BLEEDING Genuine Porsche Part - New (to order)
          # 36
          MPN: 99970202050
          RUBBER GROMMET - 8 X 12 X 9
          (356 A/540.1)
          from £0.95
          from £0.95
          Rubber grommet - for - 901 609 059 30 Genuine Porsche Part - New (to order)
          # 37
          MPN: 356 70141
          SENSOR - FOR - -BECK- - FUEL-LEVEL INDICATOR
          rhd (356)
          SENSOR - FOR - -BECK- - FUEL-LEVEL INDICATOR Genuine Porsche Part - New (to order)
          # 37
          MPN: 356 56135
          Sensor - for - -VDO- - KE 303 - F 53 527 >> - F 60 816 >>
          (356)
          Sensor - for - -VDO- - KE 303 - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 37
          MPN: 64420180100
          SENSOR - FUEL-LEVEL INDICATOR
          (356 A/540.1)
          SENSOR - FUEL-LEVEL INDICATOR Genuine Porsche Part - New (to order)
          # 38
          MPN: 91420189100
          gasket - -VDO- - F 53 527 >> - F 60 816 >>
          (356)
          from £5.26
          from £5.26
          gasket - -VDO- - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 38
          MPN: 91420189100
          GASKET
          (356 A)
          from £5.26
          from £5.26
          gasket - -VDO- - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 38
          MPN: 91420189100
          GASKET
          (356 A/540.1)
          from £5.26
          from £5.26
          gasket - -VDO- - F 53 527 >> - F 60 816 >> Genuine Porsche Part - New (to order)
          # 39
          MPN: 90001501202
          fillister hd. screw - M 5 X 15
          (356 A/540.1)
          fillister hd. screw - M 5 X 15 Genuine Porsche Part - New (to order)
          # 40
          MPN: 90002500330
          WASHER - 5,3 - ALUMINIUM
          (356 A/540.1)
          from £1.47
          from £1.47
          Washer - D - MJ 1971>> Genuine Porsche Part - New (to order)
          # -
          -
          HOSE - $ 7 MM - 250 MM - LONG - FOR - FUEL LINE
          (356)
          # -
          -
          HOSE - $ 7 MM - 150 MM - LONG - FOR - FUEL LINE
          (356)
          # -
          -
          FUEL LINE - $ 8 MM(CU) - 2400 MM
          (356)
