302-000 - TRANSMISSION CASE - WITH: - TRANSMISSION SUSPENSION
Porsche 1964 (356B/356C) TRANSMISSION CASE - WITH: - TRANSMISSION SUSPENSION Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 74130101000
TRANSMISSION CASE - COMPLETE
(356 B-T5)
# 1
MPN: 74130101010
TRANSMISSION CASE - COMPLETE
(356 B-T6 356 C)
# 2
MPN: 90009300502
GROOVED NAIL, - 6 X 20
# 3
MPN: 000 95138
STUD
# 4
MPN: 90006101402
STUD - BM 10 X 22
# 5
MPN: 99906200102
STUD - BM 6 X 10
# 6
MPN: 644 20117
BUSHING - CLUTCH LEVER SHAFT
from £18.30
from £18.30
# 7
MPN: 644 09401
BUSHING - STARTER - SHAFT
from £11.34
from £11.34
# 8
MPN: 519 20133
BAFFLE PLATE
from £6.85
from £6.85
# 9
MPN: 519 20135
LOCK WASHER - COPPER
from £5.08
from £5.08
# 10
MPN: 90007502802
SCREW, HEX. HD. - M 8 X 22
# 11
MPN: 519 20012
BREATHER ASSY.
from £39.82
from £39.82
# 12
MPN: 519 20115
THREADED PLUG - WITHOUT: - MAGNET - WHITE - ANODISED - D >> - MJ 1965
from £12.30
from £12.30
# 13
MPN: 519 20116
threaded plug - with magnet - white - Anodised - D >> - MJ 1965
from £12.30
from £12.30
# 14
MPN: 99911304850
SEALING FRAME - DRIVE SHAFT - DISCONTINUED PART
# 14
MPN: 113311113A
SEAL - DRIVE SHAFT - DISCONTINUED PART
# 14
MPN: 113311113B
SEAL RING - DRIVE SHAFT
from £13.98
from £13.98
# 15
MPN: 644 20105
CIRCLIP
# 16
MPN: N 0122902
LOCK RING - 52 X 2
(356 B)
from £2.92
from £2.92
# 16
MPN: 99904200401
LOCK RING - 3 MM - FROM TRANSMISSION NO. - 76 406 - UP TO TRANSMISSION NUMBER - 77 651
(356 C)
# 16
MPN: 74130118100
LOCK RING - 3 MM - FROM TRANSMISSION NO. - 76 406 - UP TO TRANSMISSION NUMBER - 77 651
(356 C)
from £4.20
from £4.20
# 16
MPN: N 0122902
lock ring - From transmission no. - 77 652
(356 C)
from £2.92
from £2.92
# 17
MPN: 644 200111
HOUSING COVER
LEFT
from £272.09
from £272.09
# 17
MPN: 644 20011
TRANSMISSION COVER
RIGHT
from £272.09
from £272.09
# 18
MPN: 000 95135
STUD
from £5.19
from £5.19
# 19
MPN: 99906201002
STUD - BM 8 X 35
from £3.17
from £3.17
# 20
MPN: 90005300400
BALL BEARING - 7210
from £64.30
from £64.30
# 20
MPN: 90005200500
BALL BEARING - 6210
from £47.25
from £47.25
# 21
MPN: 644 20116
GASKET
from £2.59
from £2.59
# 22
MPN: 644 23327
BRACKET - CLUTCH CABLE
# 23
MPN: 90007602502
HEX. NUT - M 8 - DISCONTINUED PART
(356 C)
Supersession
Supersession
# 23
MPN: 90007606402
hex. nut - M 8
(356 C)
from £0.59
from £0.59
# 24
MPN: N 0122418
SPRING WASHER - B 8
(356 C)
from £0.70
from £0.70
# 25
MPN: 74130122100
intermediate plate - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 26
MPN: 90005300300
BALL BEARING - 3305 - DISCONTINUED PART
# 26
MPN: 90005300301
BALL BEARING - 3305
from £54.17
from £54.17
# 27
MPN: 90005300200
BALL BEARING - 3304 - DISCONTINUED PART
# 27
MPN: 90005300201
BALL BEARING - 3304
from £74.70
from £74.70
# 28
MPN: 74130551100
pin - upper link - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
from £19.31
from £19.31
# 29
MPN: 90002801402
SPRING WASHER - B 12 - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - UP TO TRANSMISSION NUMBER - 35 000 - DISCONTINUED PART
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 29
MPN: 90002801403
SPRING WASHER - B 12 - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - UP TO TRANSMISSION NUMBER - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
from £1.32
from £1.32
# 30
MPN: 644 20122
PACKING
from £2.34
from £2.34
# 31
MPN: 644 20118
TENSIONING PLATE
from £60.40
from £60.40
# 32
MPN: 74130129100
RETAINER PLATE
LEFT
from £9.74
from £9.74
# 33
MPN: 74130129200
RETAINER PLATE
RIGHT
from £9.74
from £9.74
# 34
MPN: 90007403401
SCREW, HEX. HD. - M 8 X 30
(741/0-741/3 741/8,741/0A 741/2A 741/80A)
from £0.47
from £0.47
# 34
MPN: 99907400301
SCREW, HEX. HD.
(741/4-741/7)
# 34
MPN: 90007403502
SCREW, HEX. HD. - M 8 X 32
(741/0-741/8 741/0A 741/2A 741/80A)
# 34
MPN: 90007403200
SCREW, HEX. HD. - M 8 X 25
(741/20A 741/8A)
# -
-
HEX. NUT - M 8 - DISCONTINUED PART
(741/0-741/8)
# -
-
HEX. NUT - M 8 - DISCONTINUED PART
(741/0-741/8)
# -
-
hex. nut - M 8
(741/0-741/8)
# -
-
HEX. NUT - M 8 - - DISCONTINUED PART
(741/0A 741/2A 741/80A)
# -
-
HEX. NUT - M 8 - - DISCONTINUED PART
(741/0A 741/2A 741/80A)
# -
-
hex. nut - M 8
(741/0A 741/2A 741/80A)
# -
-
RETAINER PLATE
# 35
MPN: 644 20108
BUSH - GEAR LOCK DETENT
# 36
MPN: 90001202000
PIN - 8 M 6 X 45
# 37
MPN: 90001201700
PIN - 8 M 6 X 28
# 38
MPN: 644 20109
PACKING - 0,10 MM
from £2.29
from £2.29
# 38
MPN: 644 20110
PACKING - 0,15 MM
from £2.30
from £2.30
# 38
MPN: 644 20111
PACKING - 0,20 MM
from £2.30
from £2.30
# 39
MPN: 74130130102
transmission cover - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
front ( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 40
MPN: 644 20022
ECCENTRIC BOLT - REVERSE GEAR
# 40
MPN: 74130222000
PIN - REVERSE GEAR - FROM TRANSMISSION NO. - 60 862
(741/20A 741/8A 741/9A)
# 41
MPN: 90009501800
PIN - 5 X 28
# 42
MPN: 90011200150
RADIAL SHAFT SEAL - A 15 X 24 - DISCONTINUED PART
# 42
MPN: 99911318540
SEAL - 15 X 24
from £10.12
from £10.12
# 43
MPN: 69530130700
ECCENTRIC BOLT - RELAY LEVER
from £30.92
from £30.92
# 44
MPN: N 0122418
SPRING WASHER - B 8
from £0.70
from £0.70
# 45
MPN: 74130301700
CAM FOLLOWER - REVERSE LIGHT SWITCH
from £6.99
from £6.99
# -
-
LOCK WASHER - 2,3
# 46
MPN: 91461354102
REVERSE LIGHT SWITCH
(356 B)
Supersession
Supersession
# 46
MPN: 91461354102
REVERSE LIGHT SWITCH
(356 C)
Supersession
Supersession
# 47
MPN: 90012300920
SEAL RING - A 18 X 24
from £0.91
from £0.91
# 48
MPN: 91461349100
PROTECTIVE CAP
from £10.23
from £10.23
# 49
MPN: 74130191100
PACKING
from £2.34
from £2.34
# 50
MPN: 90007404402
SCREW, HEX. HD. - M 8 X 70 - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - UP TO TRANSMISSION NUMBER - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
from £1.96
from £1.96
# 50
MPN: N 0103754
SCREW, HEX. HD. - M 8 X 75
# 51
MPN: 99961191820
GROUND STRAP
from £13.57
from £13.57
# 52
MPN: 99909301002
SCREW, HEX. HD. - M 8 X 20
Supersession
Supersession
# 53
MPN: 99915102202
WASHER - 20 X 8,4 X 2 - GROUND STRAP
from £2.79
from £2.79
# 54
MPN: 74130502100
mounting - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
front ( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 55
MPN: 90002701602
LOCK RING - B 10 - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - UP TO TRANSMISSION NUMBER - 35 000 - DISCONTINUED PART
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 55
MPN: 90002701603
LOCK RING - B 10 - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - UP TO TRANSMISSION NUMBER - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
from £0.65
from £0.65
# 56
MPN: N 0110106
HEX. NUT - M 10 - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - UP TO TRANSMISSION NUMBER - 35 000 - DISCONTINUED PART
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 56
MPN: N 10155210
HEX. NUT - M 10 - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - UP TO TRANSMISSION NUMBER - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
from £0.88
from £0.88
# 57
MPN: 90002801200
spring washer - A 10 - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 58
MPN: 90006702200
Hexagon socket head bolt - M 10 X 25 - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 59
MPN: 74130550700
Joint head - Left thread - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 60
MPN: 74130550800
Joint head - Right thread - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 61
MPN: 90015700302
HEX. NUT - M 10 - LEFT THREAD - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - UP TO TRANSMISSION NUMBER - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
from £0.83
from £0.83
# 62
MPN: 74130550900
Adjusting nut - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 63
MPN: 90002500800
Washer - 10,5 - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 64
MPN: 90008200800
screw, hex. hd. - M 12 X 1,5 X 50 - Mount - cross tube - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 65
MPN: 90002701702
LOCK RING - B 12 - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - UP TO TRANSMISSION NUMBER - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
from £0.81
from £0.81
# 66
MPN: 90007601600
hex. nut - M 12 X 1,5 - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 67
MPN: 519 20095
RUBBER ISOLATOR
LEFT
from £170.35
from £170.35
# 67
MPN: 519 20096
RUBBER ISOLATOR
RIGHT
from £170.35
from £170.35
# 67
MPN: 74130502500
MOUNTING
left (CARRERA 2000)
# 67
MPN: 74130502600
MOUNTING
right (CARRERA 2000)
# 68
MPN: 99909301002
SCREW, HEX. HD. - M 8 X 20
Supersession
Supersession
# 69
MPN: 90007504601
SCREW, HEX. HD. - M 10 X 55
(741/20A 741/8A)
# 69
MPN: 90007406402
SCREW, HEX. HD. - M 10 X 60
(741/20A 741/8A)
# 69
MPN: 90007437701
SCREW, HEX. HD. - M 10 X 60
(741/20A 741/8A)
from £1.93
from £1.93
# 70
MPN: 90002701502
LOCK RING - B 8
# 70
MPN: 90002701503
LOCK RING - B 8
from £0.86
from £0.86
# 71
MPN: 519 20545
TRANSMISSION CARRIER
# 72
MPN: 90002801402
SPRING WASHER - B 12 - DISCONTINUED PART
# 72
MPN: 90002801403
SPRING WASHER - B 12
from £1.32
from £1.32
# 73
MPN: 90008200602
SCREW, HEX. HD. - M 12 X 1,5 X 30 - DISCONTINUED PART
# 73
MPN: 90008302301
SCREW, HEX. HD. - M 12 X 1,5 X 30
from £2.22
from £2.22
# 74
MPN: 519 20331
CATCH - GEAR LOCK DETENT
# 75
MPN: N 0256672
BALL - 9 MM - GEAR LOCK DETENT
from £1.36
from £1.36
# 76
MPN: 519 20265
SPRING - GEAR LOCK DETENT
# 77
MPN: 519 20330
SPRING - GEAR LOCK DETENT
from £6.04
from £6.04
# 78
MPN: 90001203800
DOWEL PIN - 10 H 11 X 14
# 79
MPN: 99906500102
THREADED PLUG
# 80
MPN: 74130301600
shift lever - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
# 81
MPN: 69542302100
relay lever - F >> 110 406 - - F >> 153 022 - - F >> 87 491 - Up to transmission number - 35 000
( COUPE -REUTER CABRIO HARDTOP ROADSTER)
from £79.33
from £79.33
# 82
MPN: 90002500802
WASHER - 10,5 - DISCONTINUED PART
Supersession
Supersession
# 82
MPN: N 0115274
WASHER - 10,5 - DISCONTINUED PART
# 82
MPN: 90002500809
WASHER - 10,5 - DISCONTINUED PART
# 82
MPN: 90002500804
WASHER - 10,5
from £0.80
from £0.80
This part replaces part number 90002500802
# 82
MPN: 9000250080E
WASHER - 10,5
Yellow
from £0.62
from £0.62
# 83
MPN: N 0125301
COTTER PIN - 3 X 15
from £0.60
from £0.60
# 84
MPN: N 0105003
SCREW, HEX. HD. - M 10 X 110 - FOR ENGINE - MOUNT
from £2.88
from £2.88
# 85
MPN: 90007406502
SCREW, HEX. HD. - M 10 X 70 - FOR ENGINE - MOUNT
# 86
MPN: 91442321100
BUSHING - RELAY LEVER
Supersession
Supersession
# -
-
FROM TRANSMISSION NO. - 35 001
-part-diagram-302-005.webp "PORSCHE 1964 (356B/356C) TRANSMISSION COVER - INTERMEDIATE PLATE PARTS DIAGRAM")
-part-diagram-303-000.webp "PORSCHE 1964 (356B/356C) SPEED - TRANSMISSION - GEARS AND SHAFTS PARTS DIAGRAM")
-part-diagram-305-000.webp "PORSCHE 1964 (356B/356C) DIFFERENTIAL PARTS DIAGRAM")
-part-diagram-305-005.webp "PORSCHE 1964 (356B/356C) LIMITED SLIP DIFFERENTIAL PARTS DIAGRAM")
-part-diagram-401-000.webp "PORSCHE 1964 (356B/356C) FRONT AXLE - SCHMIERSTOFFE PARTS DIAGRAM")
-part-diagram-403-000.webp "PORSCHE 1964 (356B/356C) STEERING PARTS PARTS DIAGRAM")
-part-diagram-403-005.webp "PORSCHE 1964 (356B/356C) STEERING COLUMN SWITCH PARTS DIAGRAM")
-part-diagram-403-010.webp "PORSCHE 1964 (356B/356C) STEERING GEAR - STEERING COUPLING PARTS DIAGRAM")
-part-diagram-501-000.webp "PORSCHE 1964 (356B/356C) REAR AXLE PARTS DIAGRAM")
-part-diagram-502-000.webp "PORSCHE 1964 (356B/356C) REAR AXLE - HELPER SPRING PARTS DIAGRAM")
-part-diagram-601-000.webp "PORSCHE 1964 (356B/356C) WHEELS PARTS DIAGRAM")
-part-diagram-601-005.webp "PORSCHE 1964 (356B/356C) WHEELS PARTS DIAGRAM")
-part-diagram-601-010.webp "PORSCHE 1964 (356B/356C) PERFORATED DISC WHEEL - CENTRAL LOCKING - WITH: - FASTENERS PARTS DIAGRAM")
-part-diagram-602-000.webp "PORSCHE 1964 (356B/356C) BRAKE PARTS DIAGRAM")
-part-diagram-602-005.webp "PORSCHE 1964 (356B/356C) BRAKE - D >> - MJ 1963 PARTS DIAGRAM")
-part-diagram-602-010.webp "PORSCHE 1964 (356B/356C) BRAKE PARTS DIAGRAM")
-part-diagram-604-000.webp "PORSCHE 1964 (356B/356C) WHEEL BRAKE CYLINDER - BRAKE MASTER CYLINDER PARTS DIAGRAM")
-part-diagram-604-005.webp "PORSCHE 1964 (356B/356C) BRAKE MASTER CYLINDER - RESERVOIR FOR - BRAKE FLUID PARTS DIAGRAM")
-part-diagram-604-010.webp "PORSCHE 1964 (356B/356C) BRAKE LINES PARTS DIAGRAM")
-part-diagram-698-005.webp "PORSCHE 1964 (356B/356C) BRAKE FLUID - PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-701-000.webp "PORSCHE 1964 (356B/356C) TRANSMISSION CONTROL PARTS DIAGRAM")
-part-diagram-701-005.webp "PORSCHE 1964 (356B/356C) TRANSMISSION CONTROL PARTS DIAGRAM")
-part-diagram-701-020.webp "PORSCHE 1964 (356B/356C) HANDBRAKE PARTS DIAGRAM")
-part-diagram-702-000.webp "PORSCHE 1964 (356B/356C) PEDALS PARTS DIAGRAM")
-part-diagram-801-005.webp "PORSCHE 1964 (356B/356C) FRAME PARTS DIAGRAM")
-part-diagram-801-010.webp "PORSCHE 1964 (356B/356C) FRAME - SINGLE PARTS PARTS DIAGRAM")
-part-diagram-801-015.webp "PORSCHE 1964 (356B/356C) INTERIOR PANELLING PARTS DIAGRAM")
-part-diagram-801-020.webp "PORSCHE 1964 (356B/356C) INTERIOR PANELLING PARTS DIAGRAM")
-part-diagram-802-000.webp "PORSCHE 1964 (356B/356C) EXTERIOR PANELLING PARTS DIAGRAM")
-part-diagram-802-005.webp "PORSCHE 1964 (356B/356C) EXTERIOR PANELLING - FENDER PARTS DIAGRAM")
-part-diagram-802-010.webp "PORSCHE 1964 (356B/356C) BUMPER PARTS DIAGRAM")
-part-diagram-803-000.webp "PORSCHE 1964 (356B/356C) COVER - - AND - WITH INSTALLATION PARTS - TO FIT USE WORKSHOP MATERIAL PARTS DIAGRAM")
-part-diagram-804-000.webp "PORSCHE 1964 (356B/356C) DOOR - WITH: - ACCESSORIES PARTS DIAGRAM")
-part-diagram-804-001.webp "PORSCHE 1964 (356B/356C) DOOR HANDLE, OUTER - AND - SINGLE PARTS PARTS DIAGRAM")
-part-diagram-804-005.webp "PORSCHE 1964 (356B/356C) WINDOW FRAME - SIDE WINDOW - DOOR WINDOW PARTS DIAGRAM")
-part-diagram-804-010.webp "PORSCHE 1964 (356B/356C) WINDOW FRAME - SIDE WINDOW - DOOR WINDOW - GLASS CHANNEL - DOOR WINDOW PARTS DIAGRAM")
-part-diagram-805-000.webp "PORSCHE 1964 (356B/356C) WINDOW GLAZING PARTS DIAGRAM")
-part-diagram-805-005.webp "PORSCHE 1964 (356B/356C) WINDOW GLAZING PARTS DIAGRAM")
-part-diagram-807-000.webp "PORSCHE 1964 (356B/356C) TRIMS - FOOTWELL PARTS DIAGRAM")
-part-diagram-807-005.webp "PORSCHE 1964 (356B/356C) TRIMS - INTERIOR EQUIPMENT PARTS DIAGRAM")
-part-diagram-807-010.webp "PORSCHE 1964 (356B/356C) TRIMS - INTERIOR EQUIPMENT PARTS DIAGRAM")
-part-diagram-807-015.webp "PORSCHE 1964 (356B/356C) TRIMS - INTERIOR EQUIPMENT PARTS DIAGRAM")
-part-diagram-807-020.webp "PORSCHE 1964 (356B/356C) BODY SHELL - DAMPING MAT PARTS DIAGRAM")
-part-diagram-807-025.webp "PORSCHE 1964 (356B/356C) BODY SHELL - DAMPING MAT PARTS DIAGRAM")
-part-diagram-808-000.webp "PORSCHE 1964 (356B/356C) FRONT SEAT - AND - EMERGENCY SEAT PARTS DIAGRAM")
-part-diagram-808-005.webp "PORSCHE 1964 (356B/356C) SEAT RAIL - SEAT RAIL SUPPORT - AND - RECLINING SEAT MECHANISM PARTS DIAGRAM")
-part-diagram-808-010.webp "PORSCHE 1964 (356B/356C) SEAT RAIL - AND - RECLINING SEAT MECHANISM PARTS DIAGRAM")
-part-diagram-808-015.webp "PORSCHE 1964 (356B/356C) RECLINING SEAT MECHANISM PARTS DIAGRAM")
-part-diagram-808-020.webp "PORSCHE 1964 (356B/356C) SEAT PARTS DIAGRAM")
-part-diagram-809-000.webp "PORSCHE 1964 (356B/356C) DASHBOARD - ACCESSORIES PARTS DIAGRAM")
-part-diagram-809-005.webp "PORSCHE 1964 (356B/356C) DASHBOARD - ACCESSORIES PARTS DIAGRAM")
-part-diagram-810-000.webp "PORSCHE 1964 (356B/356C) DECORATIVE FITTINGS PARTS DIAGRAM")
-part-diagram-810-005.webp "PORSCHE 1964 (356B/356C) DECORATIVE FITTINGS - - PARTS NOT LISTED - SEE GROUP - 8/10/00 PARTS DIAGRAM")
-part-diagram-811-000.webp "PORSCHE 1964 (356B/356C) SUNROOF - MECHANICAL PARTS DIAGRAM")
-part-diagram-811-005.webp "PORSCHE 1964 (356B/356C) SUNROOF - ELECTRIC PARTS DIAGRAM")
-part-diagram-811-010.webp "PORSCHE 1964 (356B/356C) WIND DEFLECTOR - SUNROOF - ELECTRIC PARTS DIAGRAM")
-part-diagram-811-015.webp "PORSCHE 1964 (356B/356C) TOP FRAME PARTS DIAGRAM")
-part-diagram-811-020.webp "PORSCHE 1964 (356B/356C) CONVERTIBLE TOP - AND - CONVERTIBLE TOP COVERING PARTS DIAGRAM")
-part-diagram-811-025.webp "PORSCHE 1964 (356B/356C) TOP FRAME PARTS DIAGRAM")
-part-diagram-811-030.webp "PORSCHE 1964 (356B/356C) CONVERTIBLE TOP - ACCESSORIES PARTS DIAGRAM")
-part-diagram-811-035.webp "PORSCHE 1964 (356B/356C) HARDTOP PARTS DIAGRAM")
-part-diagram-813-000.webp "PORSCHE 1964 (356B/356C) VENTILATION PARTS DIAGRAM")
-part-diagram-813-005.webp "PORSCHE 1964 (356B/356C) RADIAL BLOWER - ADDITIONAL BLOWER - FOR SERVICE INSTALLATION PARTS DIAGRAM")
-part-diagram-813-010.webp "PORSCHE 1964 (356B/356C) VALVE PARTS DIAGRAM")
-part-diagram-813-015.webp "PORSCHE 1964 (356B/356C) HEATER - - EBERSPAECHER - - BN 4 PARTS DIAGRAM")
-part-diagram-901-000.webp "PORSCHE 1964 (356B/356C) ELECTRICAL EQUIPMENT - ENGINE PARTS DIAGRAM")
-part-diagram-901-003.webp "PORSCHE 1964 (356B/356C) ELECTRICAL EQUIPMENT - ENGINE PARTS DIAGRAM")
-part-diagram-901-004.webp "PORSCHE 1964 (356B/356C) DISTRIBUTOR - DRIVING MECHANISM PARTS DIAGRAM")
-part-diagram-904-000.webp "PORSCHE 1964 (356B/356C) WINDSHIELD WASHER UNIT - WINDSCREEN WIPER SYSTEM PARTS DIAGRAM")
-part-diagram-904-005.webp "PORSCHE 1964 (356B/356C) WINDSHIELD WASHER UNIT - WINDSCREEN WIPER SYSTEM PARTS DIAGRAM")
-part-diagram-904-010.webp "PORSCHE 1964 (356B/356C) WINDSHIELD WASHER UNIT PARTS DIAGRAM")
-part-diagram-905-000.webp "PORSCHE 1964 (356B/356C) HEADLAMP PARTS DIAGRAM")
-part-diagram-905-005.webp "PORSCHE 1964 (356B/356C) HEADLAMP - AND - SWITCH - BATTERY PARTS DIAGRAM")
-part-diagram-905-006.webp "PORSCHE 1964 (356B/356C) BUTTON - SET - SWITCH PARTS DIAGRAM")
-part-diagram-906-000.webp "PORSCHE 1964 (356B/356C) INSTRUMENTS - MECHANICAL PARTS DIAGRAM")
-part-diagram-906-005.webp "PORSCHE 1964 (356B/356C) TACHOMETER - ELECTRIC PARTS DIAGRAM")
-part-diagram-906-010.webp "PORSCHE 1964 (356B/356C) TACHOMETER - ELECTRIC PARTS DIAGRAM")
-part-diagram-906-015.webp "PORSCHE 1964 (356B/356C) DRIVING MECHANISM - TACHOMETER PARTS DIAGRAM")
-part-diagram-001-000.webp "PORSCHE 1964 (356B/356C) TOOL PARTS DIAGRAM")
-part-diagram-001-003.webp "PORSCHE 1964 (356B/356C) CLEANING AGENT - PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-001-005.webp "PORSCHE 1964 (356B/356C) ACCESSORIES PARTS DIAGRAM")
-part-diagram-001-010.webp "PORSCHE 1964 (356B/356C) SCHLUESSEL-ETUI - LEATHER PARTS DIAGRAM")
-part-diagram-001-015.webp "PORSCHE 1964 (356B/356C) ACCESSORIES - PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-002-000.webp "PORSCHE 1964 (356B/356C) EMBLEM - STICKER PARTS DIAGRAM")
-part-diagram-002-003.webp "PORSCHE 1964 (356B/356C) IDENTIFICATION PLATE PARTS DIAGRAM")
-part-diagram-002-005.webp "PORSCHE 1964 (356B/356C) INSTRUCTION MANUAL PARTS DIAGRAM")
-part-diagram-101-005.webp "PORSCHE 1964 (356B/356C) CRANKCASE PARTS DIAGRAM")
-part-diagram-101-010.webp "PORSCHE 1964 (356B/356C) CRANKCASE PARTS DIAGRAM")
-part-diagram-102-000.webp "PORSCHE 1964 (356B/356C) CRANKSHAFT PARTS DIAGRAM")
-part-diagram-102-005.webp "PORSCHE 1964 (356B/356C) CRANKSHAFT PARTS DIAGRAM")
-part-diagram-103-000.webp "PORSCHE 1964 (356B/356C) CYLINDER HEAD - CYLINDER WITH PISTONS PARTS DIAGRAM")
-part-diagram-103-003.webp "PORSCHE 1964 (356B/356C) CYLINDER HEAD - CYLINDER WITH PISTONS PARTS DIAGRAM")
-part-diagram-103-004.webp "PORSCHE 1964 (356B/356C) CYLINDER HEAD - CYLINDER WITH PISTONS PARTS DIAGRAM")
-part-diagram-103-005.webp "PORSCHE 1964 (356B/356C) CAMSHAFT PARTS DIAGRAM")
-part-diagram-103-010.webp "PORSCHE 1964 (356B/356C) CAMSHAFT PARTS DIAGRAM")
-part-diagram-103-015.webp "PORSCHE 1964 (356B/356C) DRIVING MECHANISM - FOR - VALVE CONTROL PARTS DIAGRAM")
-part-diagram-103-020.webp "PORSCHE 1964 (356B/356C) VALVE CONTROL PARTS DIAGRAM")
-part-diagram-103-025.webp "PORSCHE 1964 (356B/356C) FLYWHEEL WEIGHTS - FOR - CAMSHAFT - INTAKE PARTS DIAGRAM")
-part-diagram-103-030.webp "PORSCHE 1964 (356B/356C) CAMSHAFT - AND - FLYWHEEL WEIGHTS - INTAKE - CYLINDER - 1 + 2 - AND - CYLINDER - 3 + 4 PARTS DIAGRAM")
-part-diagram-103-035.webp "PORSCHE 1964 (356B/356C) CAMSHAFT - AND - FLYWHEEL WEIGHTS - INTAKE - CYLINDER - 1 + 2 PARTS DIAGRAM")
-part-diagram-103-040.webp "PORSCHE 1964 (356B/356C) FLYWHEEL WEIGHTS - FOR - CAMSHAFT - EXHAUST PARTS DIAGRAM")
-part-diagram-104-000.webp "PORSCHE 1964 (356B/356C) ENGINE LUBRICATION PARTS DIAGRAM")
-part-diagram-104-005.webp "PORSCHE 1964 (356B/356C) OIL PUMP PARTS DIAGRAM")
-part-diagram-104-010.webp "PORSCHE 1964 (356B/356C) OIL PUMP PARTS DIAGRAM")
-part-diagram-104-015.webp "PORSCHE 1964 (356B/356C) ENGINE LUBRICATION PARTS DIAGRAM")
-part-diagram-104-020.webp "PORSCHE 1964 (356B/356C) OIL PIPE - OIL COOLER PARTS DIAGRAM")
-part-diagram-104-025.webp "PORSCHE 1964 (356B/356C) OIL PIPE - OIL COOLER PARTS DIAGRAM")
-part-diagram-104-030.webp "PORSCHE 1964 (356B/356C) OIL PIPE - OIL COOLER PARTS DIAGRAM")
-part-diagram-105-000.webp "PORSCHE 1964 (356B/356C) AIR COOLING - HEATER - OLD VERSION PARTS DIAGRAM")
-part-diagram-105-005.webp "PORSCHE 1964 (356B/356C) AIR COOLING - HEATER - NEW DESIGN PARTS DIAGRAM")
-part-diagram-105-010.webp "PORSCHE 1964 (356B/356C) AIR COOLING PARTS DIAGRAM")
-part-diagram-107-000.webp "PORSCHE 1964 (356B/356C) CARBURETOR - AND - FUEL SUPPLY LINE PARTS DIAGRAM")
-part-diagram-107-003.webp "PORSCHE 1964 (356B/356C) CARBURETOR - AND - FUEL SUPPLY LINE PARTS DIAGRAM")
-part-diagram-107-004.webp "PORSCHE 1964 (356B/356C) CARBURETOR - AND - FUEL SUPPLY LINE PARTS DIAGRAM")
-part-diagram-107-005.webp "PORSCHE 1964 (356B/356C) FUEL PUMP - AND - FUEL LINE PARTS DIAGRAM")
-part-diagram-107-007.webp "PORSCHE 1964 (356B/356C) FUEL PUMP - AND - FUEL LINE PARTS DIAGRAM")
-part-diagram-107-010.webp "PORSCHE 1964 (356B/356C) SINGLE PARTS - FOR - CARBURETOR - PALLAS - ZENITH 32 NDIX PARTS DIAGRAM")
-part-diagram-107-015.webp "PORSCHE 1964 (356B/356C) SINGLE PARTS - FOR - CARBURETOR - SOLEX-40 PII-4/44 PII-4 PARTS DIAGRAM")
-part-diagram-107-017.webp "PORSCHE 1964 (356B/356C) SINGLE PARTS - FOR - CARBURETOR - WEBER 46 IDM 2 PARTS DIAGRAM")
-part-diagram-107-018.webp "PORSCHE 1964 (356B/356C) SINGLE PARTS - FOR - CARBURETOR - WEBER 40 DCM 2 PARTS DIAGRAM")
-part-diagram-107-020.webp "PORSCHE 1964 (356B/356C) SINGLE PARTS - FOR - FUEL PUMP PARTS DIAGRAM")
-part-diagram-107-025.webp "PORSCHE 1964 (356B/356C) SINGLE PARTS - FOR - FUEL PUMP PARTS DIAGRAM")
-part-diagram-107-030.webp "PORSCHE 1964 (356B/356C) SINGLE PARTS - FOR - FUEL PUMP PARTS DIAGRAM")
-part-diagram-198-000.webp "PORSCHE 1964 (356B/356C) GASKET SET - ENGINE - CRANKCASE - PISTON RINGS PARTS DIAGRAM")
-part-diagram-198-010.webp "PORSCHE 1964 (356B/356C) ENGINE OIL - PORSCHE CLASSIC 20W50 PARTS DIAGRAM")
-part-diagram-201-000.webp "PORSCHE 1964 (356B/356C) FUEL TANK PARTS DIAGRAM")
-part-diagram-201-005.webp "PORSCHE 1964 (356B/356C) FUEL TANK PARTS DIAGRAM")
-part-diagram-202-000.webp "PORSCHE 1964 (356B/356C) EXHAUST SYSTEM - HEATER - OLD VERSION PARTS DIAGRAM")
-part-diagram-202-002.webp "PORSCHE 1964 (356B/356C) EXHAUST SYSTEM - HEATER - NEW DESIGN PARTS DIAGRAM")
-part-diagram-202-004.webp "PORSCHE 1964 (356B/356C) EXHAUST SYSTEM PARTS DIAGRAM")
-part-diagram-202-005.webp "PORSCHE 1964 (356B/356C) EXHAUST SYSTEM PARTS DIAGRAM")
-part-diagram-202-006.webp "PORSCHE 1964 (356B/356C) EXHAUST SYSTEM - SPORT VERSION - RETAINER - NR. 1 PARTS DIAGRAM")
-part-diagram-202-007.webp "PORSCHE 1964 (356B/356C) EXHAUST SYSTEM - SPORT VERSION PARTS DIAGRAM")
-part-diagram-202-008.webp "PORSCHE 1964 (356B/356C) EXHAUST SYSTEM - SPORT VERSION - ONLY - FOR - RACE TRACK PARTS DIAGRAM")
-part-diagram-202-010.webp "PORSCHE 1964 (356B/356C) RUBBER - HEATING AIR SUPPLY PARTS DIAGRAM")
-part-diagram-202-015.webp "PORSCHE 1964 (356B/356C) HEATING AIR SUPPLY - VALID FOR - F 122 851 >> - - F 212 601 >> - - F 157 751 >> PARTS DIAGRAM")
-part-diagram-202-020.webp "PORSCHE 1964 (356B/356C) HEATING AIR SUPPLY - D - MJ 1964>> PARTS DIAGRAM")
-part-diagram-298-005.webp "PORSCHE 1964 (356B/356C) PORSCHE CLASSIC - ADDITIVE - FOR FUEL PARTS DIAGRAM")
-part-diagram-301-000.webp "PORSCHE 1964 (356B/356C) CLUTCH PARTS DIAGRAM")
-part-diagram-301-005.webp "PORSCHE 1964 (356B/356C) CLUTCH RELEASE PARTS DIAGRAM")
