porsche 1969 (911/912) rear window wiper parts diagram

904-005 - REAR WINDOW WIPER

Porsche 1969 (911/912) REAR WINDOW WIPER Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                      #
                                      Part number
                                      Description
                                      Key
                                      Price
                                      # -
                                      MPN: 90162806100
                                      Rear window wiper - complete - with: - wiper blade - silver metallic - F 030 5101 >> - F 035 4001 >> - F 045 8101 >> - D >> - MJ 1968
                                      REAR WINDOW WIPER - COMPLETE - WITH: - WIPER BLADE - SILVER METALLIC - F 030 5101 >>- F 035 4001 >>- F 045 8101 >>- D >>- MJ 1968 Genuine Porsche Part - New (to order)
                                      # -
                                      -
                                      DIFFERING PARTS - PICTURE - NR. 14 + 15 - ALSO USE: - F >> 030 5100 - F >> 035 4000 - F >> 045 8100 - D >> - MJ 1968
                                      (Coupe)
                                      # 1
                                      MPN: 90162806101
                                      Rear window wiper - without: - wiper arm - wiper blade - Black
                                      Rear window wiper - complete Genuine Porsche Part - New (to order)
                                      # 2
                                      MPN: 91162806300
                                      wiper motor
                                      Supersession
                                      Supersession
                                      Genuine Porsche Part (no longer available to order)
                                      # 3
                                      MPN: 90162806500
                                      Assembly frame
                                      from £44.24
                                      from £44.24
                                      Assembly frame Genuine Porsche Part - New (to order)
                                      # 4
                                      MPN: 90162833800
                                      LOCK RING
                                      from £1.96
                                      from £1.96
                                      LOCK RING - 14,2 Genuine Porsche Part - New (to order)
                                      # 6
                                      MPN: 90162833900
                                      WASHER
                                      from £1.45
                                      from £1.45
                                      WASHER - 5,2 Genuine Porsche Part - New (to order)
                                      # 7
                                      MPN: 90007602702
                                      NUT - M 5
                                      from £0.47
                                      from £0.47
                                      nut - M5 - D - MJ 1972>> Genuine Porsche Part - New (to order)
                                      # 8
                                      MPN: 90162832000
                                      BRACKET
                                      from £5.98
                                      from £5.98
                                      BRACKET Genuine Porsche Part - New (to order)
                                      # 9
                                      MPN: N 01021513
                                      SCREW, HEX. HD. - M 6 X 15
                                      from £2.09
                                      from £2.09
                                      screw, hex. hd. - M6 X 15 Genuine Porsche Part - New (to order)
                                      # 10
                                      MPN: 90162833700
                                      BRACKET
                                      from £6.15
                                      from £6.15
                                      BRACKET Genuine Porsche Part - New (to order)
                                      # 11
                                      MPN: 90162831800
                                      LEVER
                                      from £18.60
                                      from £18.60
                                      LEVER Genuine Porsche Part - New (to order)
                                      # 12
                                      MPN: 90002701401
                                      LOCK RING - B 6 - DISCONTINUED PART
                                      LOCK RING - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                      # 12
                                      MPN: 90002701402
                                      LOCK RING - B 6 - DISCONTINUED PART
                                      LOCK RING - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                      # 12
                                      MPN: N 0120064
                                      LOCK RING - B 6
                                      from £0.70
                                      from £0.70
                                      lock ring - D - MJ 1980>> Genuine Porsche Part - New (to order)
                                      # 13
                                      MPN: 90007601002
                                      NUT - M 6 - DISCONTINUED PART
                                      nut - M6 - Discontinued part Genuine Porsche Part - New (to order)
                                      # 13
                                      MPN: 9000760100B
                                      NUT - M 6
                                      Supersession
                                      Supersession
                                      Genuine Porsche Part (no longer available to order)
                                      # 14
                                      MPN: 90162831700
                                      toggle lever - 404 MM - F >> 030 5100 - F >> 035 4000 - F >> 045 8100 - D >> - MJ 1968
                                      (Coupe)
                                      toggle lever - 404 MM - F >> 030 5100 - F >> 035 4000 - F >> 045 8100 - D >> - MJ 1968 Genuine Porsche Part - New (to order)
                                      # 14
                                      MPN: 90162861500
                                      toggle lever - 396 MM - F 030 5101 >> - F 035 4001 >> - F 045 8101 >>
                                      from £53.83
                                      from £53.83
                                      toggle lever - 396 MM - F 030 5101 >> - F 035 4001 >> - F 045 8101 >> Genuine Porsche Part - New (to order)
                                      # 15
                                      MPN: 90162831901
                                      wiper bearing - F >> 030 5100 - F >> 035 4000 - F >> 045 8100 - D >> - MJ 1968
                                      (Coupe)
                                      wiper bearing - F >> 030 5100 - F >> 035 4000 - F >> 045 8100 - D >> - MJ 1968 Genuine Porsche Part - New (to order)
                                      # 15
                                      MPN: 90162831902
                                      wiper bearing - F 030 5101 >> - F 035 4001 >> - F 045 8101 >>
                                      wiper bearing - F 030 5101 >> - F 035 4001 >> - F 045 8101 >> Genuine Porsche Part - New (to order)
                                      # 16
                                      MPN: 90162891300
                                      SPACER BUSHING
                                      SPACER BUSHING Genuine Porsche Part - New (to order)
                                      # 17
                                      MPN: 90162891200
                                      HEX. NUT
                                      HEX. NUT Genuine Porsche Part - New (to order)
                                      # 18
                                      MPN: 90162891100
                                      CAP
                                      CAP Genuine Porsche Part - New (to order)
                                      # 19
                                      MPN: 90162830300
                                      wiper arm - silver metallic - D >> - MJ 1968
                                      wiper arm - silver metallic - D >> - MJ 1968 Genuine Porsche Part - New (to order)
                                      # 19
                                      MPN: 90162861100
                                      wiper arm - Black
                                      from £39.88
                                      from £39.88
                                      wiper arm - Black Genuine Porsche Part - New (to order)
                                      # 19
                                      MPN: 90162861101
                                      wiper arm - Black
                                      from £75.38
                                      from £75.38
                                      wiper arm - Black Genuine Porsche Part - New (to order)
                                      # 20
                                      MPN: 90162831300
                                      wiper blade - silver metallic - D >> - MJ 1968
                                      wiper blade - silver metallic - D >> - MJ 1968 Genuine Porsche Part - New (to order)
                                      # 20
                                      MPN: 90162861300
                                      WIPER BLADE - BLACK - DISCONTINUED PART
                                      WIPER BLADE - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                      # 20
                                      MPN: PCG62861300
                                      wiper blade - Black
                                      wiper blade - Black Genuine Porsche Part - New (to order)
                                      # 20
                                      MPN: PCG62861301
                                      wiper blade - Black
                                      from £21.69
                                      from £21.69
                                      wiper blade - Black Genuine Porsche Part - New (to order)
                                      # -
                                      -
                                      harness - Rear window wiper - D >> - MJ 1968
                                      # -
                                      -
                                      HARNESS - WIPER SWITCH - D >> - MJ 1968
                                      # -
                                      -
                                      HARNESS - NR. 19 - FUSE HOLDER - WIPER SWITCH
                                      # -
                                      -
                                      harness - tunnel - Rear window wiper - D - MJ 1969>> - MJ 1969
                                      # -
                                      -
                                      harness - Rear window wiper - D - MJ 1969>> - MJ 1969
                                      # -
                                      -
                                      ground strap - D >> - MJ 1968
                                      # -
                                      -
                                      Positive cable - D >> - MJ 1968
                                      # -
                                      -
                                      FUSE HOLDER - D >> - MJ 1968
                                      # -
                                      -
                                      fuse box - 4-POLE - D - MJ 1969>> - MJ 1969
                                      # -
                                      -
                                      PUSH-ON CONNECTOR
                                      # -
                                      -
                                      CABLE SUPPORT SLEEVE
                                      # -
                                      -
                                      SET - FOR SERVICE INSTALLATION - SEE GROUP - 9/98/05
