porsche 1971 (911) replacement transmission - repair kits - gasket set parts diagram

398-000 - REPLACEMENT TRANSMISSION - REPAIR KITS - GASKET SET

Porsche 1971 (911) REPLACEMENT TRANSMISSION - REPAIR KITS - GASKET SET Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # -
    MPN: 90130001006
    transmission - complete - 901/06 - 1ST gear - Z = 11:34 - 2ND gear - Z = 19:31 - 3RD gear - Z = 25:26 - 4TH speed - Z = 29:23 - with: - Differential - Normal - D >> - MJ 1970
    (911 T/E 911 S:M)
    TRANSMISSION - COMPLETE - 901/06 - 1ST GEAR - Z = 11:34 - 2ND GEAR - Z = 19:31 - 3RD GEAR - Z = 25:26 - 4TH SPEED - Z = 29:23 - WITH: - DIFFERENTIAL - NORMAL - D >>- MJ 1970 Genuine Porsche Part - New (to order)
    # -
    MPN: 90130001207
    transmission - complete - 901/07 - no longer available - Replacement transmission - 901.300/13 - 901 300 012 13 - D >> - MJ 1970
    (911 E/S 911 T:M)
    TRANSMISSION - COMPLETE - 901/07 - NO LONGER AVAILABLE - REPLACEMENT TRANSMISSION - 901.300/13 - 901 300 012 13 - D >>- MJ 1970 Genuine Porsche Part - New (to order)
    # -
    MPN: 90130001275
    transmission - complete - 901/75 - 1ST gear - Z = 14:37 - 2ND gear - Z = 18:32 - 3RD gear - Z = 22:29 - 4TH speed - Z = 26:26 - 5TH gear - Z = 28:23 - with: - Differential - Normal - D >> - MJ 1970
    (911 T/S/E:M)
    TRANSMISSION - COMPLETE - 901/75 - 1ST GEAR - Z = 14:37 - 2ND GEAR - Z = 18:32 - 3RD GEAR - Z = 22:29 - 4TH SPEED - Z = 26:26 - 5TH GEAR - Z = 28:23 - WITH: - DIFFERENTIAL - NORMAL - D >>- MJ 1970 Genuine Porsche Part - New (to order)
    # -
    MPN: 90130001276
    transmission - complete - 901/76 - 1ST gear - Z = 12:34 - 2ND gear - Z = 17:34 - 3RD gear - Z = 20:31 - 4TH speed - Z = 22:29 - 5TH gear - Z = 23:28 - with: - Differential - Normal - D >> - MJ 1970
    (911 T/E/S:M)
    TRANSMISSION - COMPLETE - 901/76 - 1ST GEAR - Z = 12:34 - 2ND GEAR - Z = 17:34 - 3RD GEAR - Z = 20:31 - 4TH SPEED - Z = 22:29 - 5TH GEAR - Z = 23:28 - WITH: - DIFFERENTIAL - NORMAL - D >>- MJ 1970 Genuine Porsche Part - New (to order)
    # -
    MPN: 90130001277
    transmission - complete - 901/77 - 1ST gear - Z = 12:34 - 2ND gear - Z = 18:34 - 3RD gear - Z = 21:31 - 4TH speed - Z = 23:28 - 5TH gear - Z = 25:26 - with: - Differential - Normal - D >> - MJ 1970
    (911 T/E/S:M)
    TRANSMISSION - COMPLETE - 901/77 - 1ST GEAR - Z = 12:34 - 2ND GEAR - Z = 18:34 - 3RD GEAR - Z = 21:31 - 4TH SPEED - Z = 23:28 - 5TH GEAR - Z = 25:26 - WITH: - DIFFERENTIAL - NORMAL - D >>- MJ 1970 Genuine Porsche Part - New (to order)
    # -
    MPN: 90130001278
    transmission - complete - 901/78 - 1ST gear - Z = 15:36 - 2ND gear - Z = 20:32 - 3RD gear - Z = 23:28 - 4TH speed - Z = 26:26 - 5TH gear - Z = 28:23 - with: - Differential - Normal - D >> - MJ 1970
    (911 T/E/S:M)
    TRANSMISSION - COMPLETE - 901/78 - 1ST GEAR - Z = 15:36 - 2ND GEAR - Z = 20:32 - 3RD GEAR - Z = 23:28 - 4TH SPEED - Z = 26:26 - 5TH GEAR - Z = 28:23 - WITH: - DIFFERENTIAL - NORMAL - D >>- MJ 1970 Genuine Porsche Part - New (to order)
    # -
    MPN: 90130001279
    transmission - complete - 901/79 - 1ST gear - Z = 14:37 - 2ND gear - Z = 20:32 - 3RD gear - Z = 22:29 - 4TH speed - Z = 25:27 - 5TH gear - Z = 27:25 - with: - Differential - Normal - D >> - MJ 1970
    (911 T/E/S:M)
    TRANSMISSION - COMPLETE - 901/79 - 1ST GEAR - Z = 14:37 - 2ND GEAR - Z = 20:32 - 3RD GEAR - Z = 22:29 - 4TH SPEED - Z = 25:27 - 5TH GEAR - Z = 27:25 - WITH: - DIFFERENTIAL - NORMAL - D >>- MJ 1970 Genuine Porsche Part - New (to order)
    # 1
    MPN: 90130090100
    Gasket set - for - transmission - with: - Chilled casting - comprising: - D >> - MJ 1970
    (911 T/E/S)
    from £81.14
    from £81.14
    GASKET SET - FOR - TRANSMISSION - WITH: - CHILLED CASTING - COMPRISING: - D >>- MJ 1970 Genuine Porsche Part - New (to order)
    # -
    -
    RADIAL SHAFT SEAL - 45 X 65 X 10
    # -
    -
    RADIAL SHAFT SEAL - B 15 X 24 X 7 - DISCONTINUED PART
    # -
    -
    SEAL - 15 X 24 X 7
    # -
    -
    seal - 15 X 24 X 7 - Discontinued part
    # -
    -
    GASKET - FOR - TRANSMISSION CASE - 0,1 MM
    # -
    -
    GASKET - FOR - TRANSMISSION CASE - 0,15 MM
    # -
    -
    GASKET - FOR - TRANSMISSION CASE - 0,2 MM
    # -
    -
    SEALING FRAME - DISCONTINUED PART
    # -
    -
    SEAL - DISCONTINUED PART
    # -
    -
    SEAL RING
    # -
    -
    seal ring - A 18 X 24 AL
    # -
    -
    RADIAL SHAFT SEAL
    # -
    -
    O-RING - 25,3 - 2,4
    # -
    -
    gasket - for - transmission cover
    # -
    -
    GASKET - FOR - TRANSMISSION COVER - DISCONTINUED PART
    SIDE
    # -
    -
    gasket - for - transmission cover
    SIDE
    # -
    -
    seal ring - A 22 X 27 AL
    # -
    -
    GASKET
    # -
    -
    SEALING WASHER
    # -
    -
    transmission - complete - 901.300/80 - 1ST gear - Z = 14:37 - 2ND gear - Z = 18:32 - 3RD gear - Z = 22:29 - 4TH speed - Z = 26:26 - 5TH gear - Z = 28:23 - with: - Differential - Normal - D >> - MJ 1970
    (911 T/E/S)
    # -
    -
    transmission - complete - 901.300/81 - 1ST gear - Z = 12:34 - 2ND gear - Z = 17:34 - 3RD gear - Z = 20:31 - 4TH speed - Z = 22:29 - 5TH gear - Z = 23:28 - with: - Differential - Normal - D >> - MJ 1970
    (911 T/E/S)
    # -
    -
    transmission - complete - 901.300/82 - 1ST gear - Z = 12:34 - 2ND gear - Z = 18:34 - 3RD gear - Z = 21:31 - 4TH speed - Z = 23:28 - 5TH gear - Z = 25:26 - with: - Differential - Normal - D >> - MJ 1970
    (911 T/E/S)
    # -
    -
    transmission - complete - 901.300/83 - 1ST gear - Z = 15:36 - 2ND gear - Z = 20:32 - 3RD gear - Z = 23:28 - 4TH speed - Z = 26:26 - 5TH gear - Z = 28:23 - with: - Differential - Normal - D >> - MJ 1970
    (911 T/E/S)
    # -
    -
    transmission - complete - 901.300/84 - 1ST gear - Z = 14:37 - 2ND gear - Z = 20:32 - 3RD gear - Z = 22:29 - 4TH speed - Z = 25:27 - 5TH gear - Z = 27:25 - with: - Differential - Normal - D >> - MJ 1970
    (911 T/E/S)
    # -
    -
    Automatic transmission - complete - 911.300/00 - 1ST gear - Z = 11:34 - 2ND gear - Z = 19:31 - 3RD gear - Z = 25:26 - 4TH speed - Z = 29:22 - with: - Differential - Normal - D >> - MJ 1971
    (911 T)
    # -
    -
    transmission - complete - 911.300/01 - 1ST gear - Z = 11:34 - 2ND gear - Z = 18:32 - 3RD gear - Z = 23:28 - 4TH speed - Z = 27:25 - 5TH gear - Z = 29:22 - with: - Differential - Normal - D >> - MJ 1971
    (911 E/S 911 T:M)
    # -
    -
    transmission - complete - 911.300/80 - 1ST gear - Z = 14:37 - 2ND gear - Z = 18:32 - 3RD gear - Z = 22:29 - 4TH speed - Z = 26:26 - 5TH gear - Z = 28:23 - with: - Differential - Normal - D >> - MJ 1971
    (911 S COUPE)
    # -
    -
    transmission - complete - 911.300/81 - 1ST gear - Z = 12:34 - 2ND gear - Z = 17:34 - 3RD gear - Z = 20:31 - 4TH speed - Z = 22:29 - 5TH gear - Z = 23:28 - with: - Differential - Normal - D >> - MJ 1971
    (911 S COUPE)
    # -
    -
    transmission - complete - 911.300/82 - 1ST gear - Z = 12:34 - 2ND gear - Z = 18:34 - 3RD gear - Z = 21:31 - 4TH speed - Z = 23:28 - 5TH gear - Z = 25:26 - with: - Differential - Normal - D >> - MJ 1971
    (911 S COUPE)
    # -
    -
    transmission - complete - 911.300/83 - 1ST gear - Z = 15:36 - 2ND gear - Z = 20:32 - 3RD gear - Z = 23:28 - 4TH speed - Z = 26:26 - 5TH gear - Z = 28:23 - with: - Differential - Normal - D >> - MJ 1971
    (911 S COUPE)
    # -
    -
    transmission - complete - 911.300/84 - 1ST gear - Z = 14:37 - 2ND gear - Z = 20:32 - 3RD gear - Z = 22:29 - 4TH speed - Z = 25:27 - 5TH gear - Z = 27:25 - with: - Differential - Normal - D >> - MJ 1971
    (911 S COUPE)
    # -
    -
    transmission - complete - 911.300/01 - 1ST gear - Z = 11:34 - 2ND gear - Z = 18:32 - 3RD gear - Z = 23:28 - 4TH speed - Z = 27:25 - 5TH gear - Z = 29:22 - with: - Differential - Normal - D - MJ 1971>> - MJ 1971
    (911 E/S 911 T:M)
    # 2
    MPN: 90130091600
    Gasket set - for - transmission - From - Die casting - housing - comprising: - D >> - MJ 1971
    (911 T/E/S)
    from £91.61
    from £91.61
    GASKET SET - FOR - TRANSMISSION - FROM - DIE CASTING - HOUSING - COMPRISING: - D >>- MJ 1971 Genuine Porsche Part - New (to order)
    # -
    -
    seal - seal - A 15 X 24 X 7 - D >> - MJ 1970
    # -
    -
    GASKET - FOR - TRANSMISSION CASE - 0,1 MM
    # -
    -
    GASKET - FOR - TRANSMISSION CASE - 0,15 MM
    # -
    -
    GASKET - FOR - TRANSMISSION CASE - 0,2 MM
    # -
    -
    SEALING FRAME - 20 X 40 X 16 - DISCONTINUED PART
    # -
    -
    seal - 20 X 40 X 16 - Discontinued part
    # -
    -
    SEAL RING - 20 X 40 X 16
    # -
    -
    RADIAL SHAFT SEAL - BA 10 X 18 X 6
    # -
    -
    O-Ring - OR 25,3-2,4
    # -
    -
    gasket - D >> - MJ 1970
    # -
    -
    RADIAL SHAFT SEAL - DG-FG 45 X 68 X 10
    # -
    -
    gasket - for - transmission cover
    # -
    -
    O-RING - FOR - TRANSMISSION COVER - 177 X 3,5
    SIDE
    # -
    -
    GASKET - FOR - FORK - OLD VERSION - D - MJ 1971>> - MJ 1971
    # -
    -
    O-RING - OR 40 X 1,5
    # -
    -
    Automatic transmission - complete - Ready for installation - 915.300/12 - 1ST gear - Z = 11:35 - 2ND gear - Z = 18:32 - 3RD gear - Z = 24:27 - 4TH speed - Z = 28:23 - with: - Differential - Normal - D - MJ 1972>>
    (911 T-E/E/S 911 T-V 911 T-K)
    # -
    -
    AUTOMATIC TRANSMISSION - COMPLETE - READY FOR INSTALLATION - 915.300/02 - 1ST GEAR - Z = 11:35 - 2ND GEAR - Z = 18:33 - 3RD GEAR - Z = 23:29 - 4TH SPEED - Z = 26:25 - 5TH GEAR - Z = 29:22 - WITH: - DIFFERENTIAL - NORMAL
    (911 T-E/E/S 911 T-V 911 T-K)
    # -
    -
    AUTOMATIC TRANSMISSION - 4-SPEED - WITH: - OIL PUMP - COMPLETE - READY FOR INSTALLATION - TYP 915.300/18 - 1ST GEAR - Z = 11:35 - 2ND GEAR - Z = 20:32 - 3RD GEAR - Z = 25:26 - 4TH SPEED - Z = 29:22 - WITH: - DIFFERENTIAL - NORMAL -
    (CARRERA 2.7)
    # -
    -
    MANUAL GEARBOX - 5-SPEED - WITH: - OIL PUMP - COMPLETE - READY FOR INSTALLATION - TYP 915.300/08 - 1ST GEAR - Z = 11:35 - 2ND GEAR - Z = 18:33 - 3RD GEAR - Z = 23:29 - 4TH SPEED - Z = 27:25 - 5TH GEAR - Z = 29:21 - WITH: - DIFFEREN
    (CARRERA 2.7)
    # 3
    MPN: 91530091100
    GASKET SET - FOR - TRANSMISSION - TYP 915 - WITHOUT: - OIL PUMP - D - MJ 1972>>
    gasket set - transmission - - TYP 915 - 923 - - comprising: Genuine Porsche Part - New (to order)
    # -
    -
    SEAL RING
    # -
    -
    RADIAL SHAFT SEAL - 45 X 68 X 10
    # -
    -
    SEAL - 23 X 40 X 10
    # -
    -
    SEAL - 23 X 35 X 8/11 - DISCONTINUED PART
    # -
    -
    SEAL - 23 X 35 X 8/11 - DISCONTINUED PART
    # -
    -
    SEAL - 23 X 35 X 8/11
    # -
    -
    O-RING - OR 195 X 3,5
    # -
    -
    GASKET
    # -
    -
    seal ring - A 10 X 16 AL
    # -
    -
    seal - 15 X 24 X7
    # -
    -
    O-Ring - 17,5 X 2,4
    # -
    -
    SEAL - 6 X 15 X 6
    # -
    -
    GASKET
    # -
    -
    O-Ring - 14,3 X 2,4
    # -
    -
    GASKET
    # -
    -
    FOR - TRANSMISSION - WITH: - OIL PUMP - GASKETS - GROUP: - 3/02/30 - ORDER
    # -
    -
    transmission - with: - torque converter - Ready for installation - 905/13 - Sportomatic - 1ST gear - Z = 15:36 - 2ND gear - Z = 19:31 - 3RD gear - Z = 23:28 - 4TH speed - Z = 27:25 - D >> - MJ 1970
    (911 T/E)
    # -
    -
    Automatic transmission - complete - 905.300/20 - Sportomatic - 1ST gear - Z = 15:36 - 2ND gear - Z = 20:31 - 3RD gear - Z = 24:27 - 4TH speed - Z = 28:24 - with: - Differential - Normal - D >> - MJ 1971
    (911 T/E)
    # 4
    MPN: 90530090200
    Gasket set - for - Sportomatic - transmission - comprising: - D >> - MJ 1971
    (911 T/E 911 T-V)
    from £88.57
    from £88.57
    GASKET SET - FOR - SPORTOMATIC - TRANSMISSION - COMPRISING: - D >>- MJ 1971 Genuine Porsche Part - New (to order)
    # -
    -
    RADIAL SHAFT SEAL - 25 X 35 X 6
    # -
    -
    SEAL - 12 X 18 X 3
    # -
    -
    RADIAL SHAFT SEAL - 45 X 60 X 7
    # -
    -
    seal ring - A 16 X 22 CU
    # -
    -
    seal ring - A 14 X 18 AL
    This part replaces part number 90012310430
    # -
    -
    SEAL - 22 X 35 X 8
    # -
    -
    GASKET - FOR - TRANSMISSION CASE - 0,10 MM
    # -
    -
    GASKET - FOR - TRANSMISSION CASE - 0,15 MM
    # -
    -
    GASKET - FOR - TRANSMISSION CASE - 0,20 MM
    # -
    -
    SEAL - A 15 X 24 X 7
    # -
    -
    O-Ring - 25,3 X 2,4
    # -
    -
    gasket - for - transmission cover
    FRONT
    # -
    -
    seal ring - A 14 X 18 CU
    # -
    -
    O-RING - 160 X 3
    # -
    -
    O-RING - 40 X 15
    # -
    -
    FOR - TRANSMISSION - WITH: - TRANSMISSION COVER - AND - FORK - OLD VERSION - WITHOUT: - O-RING - GASKETS - ALSO USE:
    SIDE
    # -
    -
    gasket - for - transmission cover
    SIDE
    # -
    -
    GASKET - FOR - FORK
    # -
    -
    TRANSMISSION - WITH: - TORQUE CONVERTER - COMPLETE - READY FOR INSTALLATION - 905.300/21 - SPORTOMATIC - 1ST GEAR - Z = 15:36 - 2ND GEAR - Z =20:31 - 3RD GEAR - Z = 24:27 - 4TH SPEED - Z = 28:24 - WITH: - DIFFERENTIAL - NORMAL - D
    (911 T-V)
    # -
    -
    TRANSMISSION - WITH: - TORQUE CONVERTER - COMPLETE - READY FOR INSTALLATION - 925.300/00 - SPORTOMATIC - 1ST GEAR - Z = 15:36 - 2ND GEAR - Z = 20:31 - 3RD GEAR - Z = 24:27 - 4TH SPEED - Z = 28:24 - WITH: - DIFFERENTIAL - NORMAL - D
    (911 T-E/E 911 T-K)
    # -
    -
    TRANSMISSION - WITH: - S- - TORQUE CONVERTER - COMPLETE - READY FOR INSTALLATION - 925.300/01 - SPORTOMATIC - 1ST GEAR - Z = 15:36 - 2ND GEAR - Z = 20:31 - 3RD GEAR - Z = 24:27 - 4TH SPEED - Z = 28:24 - WITH: - DIFFERENTIAL - NORMA
    (911 S)
    # 5
    MPN: 92530091100
    GASKET SET - FOR - TRANSMISSION - TYP 925 - SPORTOMATIC - COMPRISING: - D - MJ 1972>>
    (911 T-E/E/S 911 T-K)
    from £162.25
    from £162.25
    gasket set - transmission - - TYP 925 - - SPM - comprising: Genuine Porsche Part - New (to order)
    # -
    -
    SEAL - 26 X 37 X 7
    # -
    -
    O-RING - 72 X 2,5
    # -
    -
    seal ring - A 6 X 10 CU
    # -
    -
    RADIAL SHAFT SEAL
    # -
    -
    seal ring - A 24 X 29 AL
    # -
    -
    SEAL
    # -
    -
    RADIAL SHAFT SEAL - 45 X 68 X10
    # -
    -
    GASKET - 0,1 MM
    # -
    -
    GASKET - 0,15MM
    # -
    -
    GASKET - 0,2 MM
    # -
    -
    GASKET
    # -
    -
    SEAL RING - 14 X 18 AL
    This part replaces part number 90012310430
    # -
    -
    O-RING - 170 X 3,5
    # -
    -
    O-RING - 40 X 1,5
