porsche 1976 (911 turbo) cylinder head parts diagram

103-000 - CYLINDER HEAD

Porsche 1976 (911 Turbo) CYLINDER HEAD Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                  #
                                                  Part number
                                                  Description
                                                  Key
                                                  Price
                                                  # -
                                                  -
                                                  CYLINDER WITH PISTONS
                                                  # 1
                                                  MPN: 93010404202
                                                  CYLINDER HEAD - WITH STUDS - WITHOUT VALVES
                                                  (930/50)
                                                  from £961.45
                                                  from £961.45
                                                  CYLINDER HEAD - WITH STUDS - WITHOUT VALVES Genuine Porsche Part - New (to order)
                                                  # 1
                                                  MPN: 93010404306
                                                  CYLINDER HEAD - WITH STUDS - WITHOUT VALVES - FOR - 930/51/52/53/54
                                                  CYLINDER HEAD - WITH STUDS - WITHOUT VALVES - FOR - 930/51/52/53/54 Genuine Porsche Part - New (to order)
                                                  # 1
                                                  MPN: 93010402202
                                                  CYLINDER HEAD - WITH STUDS - WITH VALVES - READY FOR INSTALLATION
                                                  (930/50)
                                                  CYLINDER HEAD - WITH STUDS - WITH VALVES - READY FOR INSTALLATION Genuine Porsche Part - New (to order)
                                                  # 1
                                                  MPN: 93010402306
                                                  CYLINDER HEAD - WITH STUDS - WITH VALVES - READY FOR INSTALLATION - FOR - 930/51/52/53/54
                                                  CYLINDER HEAD - WITH STUDS - WITH VALVES - READY FOR INSTALLATION - FOR - 930/51/52/53/54 Genuine Porsche Part - New (to order)
                                                  # 2
                                                  MPN: 93010432150
                                                  valve guide - 1ST oversize
                                                  from £33.36
                                                  from £33.36
                                                  valve guide - Intake - Oversize Genuine Porsche Part - New (to order)
                                                  # 2
                                                  MPN: 90110432161
                                                  valve guide - 2ND oversize
                                                  from £38.02
                                                  from £38.02
                                                  valve guide - 2ND oversize Genuine Porsche Part - New (to order)
                                                  # 3
                                                  MPN: 93010433150
                                                  VALVE SEAT (INTAKE) - OVERSIZE
                                                  from £29.66
                                                  from £29.66
                                                  VALVE SEAT (INTAKE) - OVERSIZE Genuine Porsche Part - New (to order)
                                                  # 4
                                                  MPN: 93010433550
                                                  VALVE SEAT RING - EXHAUST - OVERSIZE
                                                  from £32.59
                                                  from £32.59
                                                  VALVE SEAT RING - FOR - EXHAUST - OVERSIZE Genuine Porsche Part - New (to order)
                                                  # 5
                                                  MPN: 99906200602
                                                  STUD - BM 8 X 20
                                                  from £3.62
                                                  from £3.62
                                                  stud - M 8 X 20 Genuine Porsche Part - New (to order)
                                                  # 5
                                                  MPN: 99906204402
                                                  STUD - BM 8 X 30
                                                  from £3.48
                                                  from £3.48
                                                  stud - M 8 X 30 - for - Tensioner for toothed belt Genuine Porsche Part - New (to order)
                                                  # 6
                                                  MPN: 99906217802
                                                  STUD - BM 8 X 120
                                                  from £8.22
                                                  from £8.22
                                                  STUD - BM 8 X 120 Genuine Porsche Part - New (to order)
                                                  # 8
                                                  MPN: 99901200600
                                                  DOWEL PIN
                                                  from £3.48
                                                  from £3.48
                                                  dowel pin - - D >> - MJ 1968 Genuine Porsche Part - New (to order)
                                                  # 9
                                                  MPN: 96410540906
                                                  intake valve - Discontinued part
                                                  intake valve - Discontinued part Genuine Porsche Part - New (to order)
                                                  # 9
                                                  MPN: 96410540908
                                                  INTAKE VALVE
                                                  from £203.95
                                                  from £203.95
                                                  INTAKE VALVE Genuine Porsche Part - New (to order)
                                                  # 10
                                                  MPN: 93010541950
                                                  EXHAUST VALVE
                                                  from £271.58
                                                  from £271.58
                                                  EXHAUST VALVE Genuine Porsche Part - New (to order)
                                                  # 11
                                                  MPN: 93010546100
                                                  WASHER
                                                  from £2.03
                                                  from £2.03
                                                  WASHER - 0,5MM Genuine Porsche Part - New (to order)
                                                  # 12
                                                  MPN: 90110546300
                                                  RING
                                                  from £4.81
                                                  from £4.81
                                                  RING Genuine Porsche Part - New (to order)
                                                  # 14
                                                  MPN: 90110590150
                                                  SET OF VALVE SPRINGS
                                                  Set of valve springs - Discontinued part Genuine Porsche Part - New (to order)
                                                  # 14
                                                  MPN: 90110590151
                                                  SET OF VALVE SPRINGS
                                                  from £30.87
                                                  from £30.87
                                                  Set of valve springs - - and Genuine Porsche Part - New (to order)
                                                  # 15
                                                  MPN: 90110542103
                                                  SPRING SEAT - DISCONTINUED PART
                                                  SPRING SEAT - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                  # 15
                                                  MPN: 90110542104
                                                  SPRING SEAT
                                                  from £8.77
                                                  from £8.77
                                                  SPRING SEAT Genuine Porsche Part - New (to order)
                                                  # 16
                                                  MPN: 90110541700
                                                  COTTER, SPLIT
                                                  from £2.03
                                                  from £2.03
                                                  cotter, split - Divided - D - MJ 1969>> Genuine Porsche Part - New In stock
                                                  # 17
                                                  MPN: 99903108301
                                                  Washer - Discontinued part
                                                  Washer - Discontinued part Genuine Porsche Part - New (to order)
                                                  # 17
                                                  MPN: 99903108302
                                                  WASHER
                                                  from £4.21
                                                  from £4.21
                                                  WASHER Genuine Porsche Part - New (to order)
                                                  # 18
                                                  MPN: 90110438202
                                                  NUT - DISCONTINUED PART
                                                  NUT - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                  # 18
                                                  MPN: 90110438203
                                                  NUT
                                                  Supersession
                                                  Supersession
                                                  Genuine Porsche Part (no longer available to order)
                                                  # 20
                                                  MPN: 93010395801
                                                  CYLINDER WITH PISTONS - AND - PISTON - GROUP 5 - - MAHLE -
                                                  CYLINDER WITH PISTONS - AND - PISTON - GROUP 5 - - MAHLE - Genuine Porsche Part - New (to order)
                                                  # 20
                                                  MPN: 93010395802
                                                  CYLINDER WITH PISTONS - AND - PISTON - GROUP 6 - - MAHLE - - DISCONTINUED PART
                                                  CYLINDER WITH PISTONS - AND - PISTON - GROUP 6 - - MAHLE - - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                  # 21
                                                  MPN: 93010395900
                                                  1 SET OF PISTON RINGS
                                                  1 set of piston rings - $ 95 MM Genuine Porsche Part - New (to order)
                                                  # 22
                                                  MPN: 93010337300
                                                  PISTON PIN
                                                  PISTON PIN Genuine Porsche Part - New (to order)
                                                  # 23
                                                  MPN: N 0122781
                                                  circlip - F. ST C 22
                                                  from £0.47
                                                  from £0.47
                                                  circlip - F. ST C 22 Genuine Porsche Part - New (to order)
                                                  SNAP RING Genuine Bentley Part - New (to order)
                                                  CIRCLIP Genuine Lamborghini - New (to order)
                                                  # 24
                                                  MPN: 93010419402
                                                  CYLINDER BASE GASKET
                                                  from £7.21
                                                  from £7.21
                                                  CYLINDER BASE GASKET - 0,25 MM Genuine Porsche Part - New (to order)
                                                  # 24
                                                  MPN: 93010419401
                                                  CYLINDER BASE GASKET - 0,50 MM
                                                  from £5.67
                                                  from £5.67
                                                  Cylinder base gasket - Oversize 0.50 mm - See technical information - GR.1 NR.18 1977 Genuine Porsche Part - New (to order)
                                                  # 25
                                                  MPN: 93010431700
                                                  CE-SEAL RING
                                                  from £19.21
                                                  from £19.21
                                                  CE-SEAL RING - REPAIR SET FOR MAINTENANCE - SEE ILLUSTRATION: Genuine Porsche Part - New (to order)
