porsche 1977 (911 turbo) air conditioner - cooling air duct parts diagram

813-065 - AIR CONDITIONER - COOLING AIR DUCT

Porsche 1977 (911 Turbo) AIR CONDITIONER - COOLING AIR DUCT Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                  #
                  Part number
                  Description
                  Key
                  Price
                  # -
                  -
                  INSTALLATION PARTS - WITHOUT: - POS. - SEE GROUP - 8/13/05
                  # 1
                  MPN: 91161311107
                  CONTROL SWITCH
                  LHD
                  Control switch - D >> - MJ 1985 Genuine Porsche Part - New (to order)
                  # 1
                  MPN: 91161311207
                  CONTROL SWITCH
                  RHD
                  CONTROL SWITCH Genuine Porsche Part - New (to order)
                  # 2
                  MPN: 91157124300
                  AIR HOSE
                  air hose - D >> - MJ 1985 Genuine Porsche Part - New (to order)
                  # 2
                  MPN: 91457212310
                  AIR HOSE
                  from £16.72
                  from £16.72
                  air hose - LW 60 X 165 Genuine Porsche Part - New (to order)
                  # 3
                  MPN: 473261233A
                  AIR HOSE
                  AIR HOSE Genuine Porsche Part - New (to order)
                  # 3
                  MPN: 91457212310
                  AIR HOSE
                  from £16.72
                  from £16.72
                  air hose - LW 60 X 165 Genuine Porsche Part - New (to order)
                  # 4
                  MPN: 91157104902
                  CONTROL BOX
                  LEFT
                  CONTROL BOX Genuine Porsche Part - New (to order)
                  # 5
                  MPN: 91157105002
                  CONTROL BOX
                  RIGHT
                  CONTROL BOX Genuine Porsche Part - New (to order)
                  # 6
                  MPN: 91157303100
                  AIR DISTRIBUTOR
                  LHD
                  AIR DISTRIBUTOR Genuine Porsche Part - New (to order)
                  # 7
                  MPN: 91157320400
                  AIR HOSE
                  LHD
                  from £8.54
                  from £8.54
                  air hose - LW 36 X 630 - D >> - MJ 1985 - Discontinued part Genuine Porsche Part - New (to order)
                  # 8
                  MPN: 91161815100
                  THERMO BI-METAL SWITCH
                  from £198.38
                  from £198.38
                  Thermo bi-metal switch - D >> - MJ 1985 Genuine Porsche Part - New (to order)
                  # 9
                  MPN: 90014601102
                  FILLISTER HD. SCREW - AM 4 X 10
                  from £1.94
                  from £1.94
                  FILLISTER HD. SCREW - M4X10 Genuine Porsche Part - New (to order)
                  # 10
                  MPN: N 0122243
                  SPRING WASHER - A 4 - DISCONTINUED PART
                  SPRING WASHER - DISCONTINUED PART Genuine Porsche Part - New (to order)
                  # 10
                  MPN: N 012224C
                  spring washer - A 4
                  from £0.85
                  from £0.85
                  SPRING WASHER - B4 Genuine Porsche Part - New (to order)
                  # 11
                  MPN: 91164190900
                  RUBBER RING
                  LHD
                  Rubber ring - $ 60 Genuine Porsche Part - New (to order)
                  # 12
                  MPN: 91157308700
                  ADAPTER
                  LHD
                  from £58.54
                  from £58.54
                  ADAPTER Genuine Porsche Part - New (to order)
                  # 13
                  MPN: N 0102076
                  SCREW, HEX. HD. - M 5 X 12 - DISCONTINUED PART
                  screw, hex. hd. - M5 X 12 - Discontinued part Genuine Porsche Part - New (to order)
                  # 13
                  MPN: N 01020717
                  SCREW, HEX. HD. - M 5 X 12
                  from £0.47
                  from £0.47
                  screw, hex. hd. - M5 X 12 - D - MJ 1973>> Genuine Porsche Part - New (to order)
                  HEXAGON HEAD BOLT Genuine Lamborghini - New (to order)
                  # 14
                  MPN: 90002500302
                  WASHER - 5,3
                  Washer - M 5 Genuine Porsche Part - New (to order)
                  # 15
                  MPN: 91157124001
                  air hose - Discontinued part
                  LHD
                  air hose - Discontinued part Genuine Porsche Part - New (to order)
                  # 15
                  MPN: 91157124002
                  AIR HOSE
                  LHD
                  from £14.21
                  from £14.21
                  AIR HOSE Genuine Porsche Part - New (to order)
                  # 16
                  MPN: 99951235102
                  HOSE CLAMP
                  LHD
                  from £3.75
                  from £3.75
                  HOSE CLAMP - DISCONTINUED PART Genuine Porsche Part - New In stock
                  # 17
                  MPN: 91157319100
                  FLANGE SOCKET
                  RHD
                  from £58.87
                  from £58.87
                  FLANGE SOCKET - D >>- MJ 1985 Genuine Porsche Part - New (to order)
                  # 18
                  MPN: 90157252700
                  SEALING WASHER
                  RHD
                  from £2.27
                  from £2.27
                  SEALING WASHER Genuine Porsche Part - New (to order)
                  # 19
                  MPN: 91157308800
                  ADAPTER
                  RHD
                  from £188.40
                  from £188.40
                  adapter - D >> - MJ 1985 Genuine Porsche Part - New (to order)
                  # 21
                  MPN: 91157320400
                  AIR HOSE
                  RIGHT RHD
                  from £8.54
                  from £8.54
                  air hose - LW 36 X 630 - D >> - MJ 1985 - Discontinued part Genuine Porsche Part - New (to order)
                  # 22
                  MPN: 90157314300
                  RUBBER GROMMET
                  RHD
                  from £4.76
                  from £4.76
                  Rubber grommet - D >> - MJ 1985 Genuine Porsche Part - New (to order)
                  # 23
                  MPN: 99970206250
                  GROMMET
                  RHD
                  GROMMET Genuine Porsche Part - New (to order)
                  # 24
                  MPN: 91157352302
                  AIR HOSE
                  RHD
                  from £51.23
                  from £51.23
                  air hose - Discontinued part Genuine Porsche Part - New (to order)
                  # 25
                  MPN: 90157316000
                  HOSE CLIP
                  RHD
                  HOSE CLIP Genuine Porsche Part - New (to order)
                  # 27
                  MPN: 90012101502
                  TUBULAR RIVET - A 6 X 0,5 X 15
                  RHD
                  from £0.65
                  from £0.65
                  TUBULAR RIVET - A 6 X 0,5 X 15 Genuine Porsche Part - New (to order)
