porsche 1986 (911) capacitor - refrigerant line - accessories and others parts diagram

813-055 - CAPACITOR - REFRIGERANT LINE - ACCESSORIES AND OTHERS

Porsche 1986 (911) CAPACITOR - REFRIGERANT LINE - ACCESSORIES AND OTHERS Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                            #
                            Part number
                            Description
                            Price
                            # 1
                            MPN: 91157305704
                            CAPACITOR - ALSO USE: - POS.(3)
                            (CARRERA)
                            from £835.93
                            from £835.93
                            # 2
                            MPN: 93057305301
                            capacitor
                            (TURBO)
                            from £714.81
                            from £714.81
                            # 3
                            MPN: 90157313800
                            MOLTOPRENE SHIM - 6 X 65 X 85
                            (CARRERA)
                            # 3
                            MPN: 91157314100
                            MOLTOPRENE SHIM - 9 X 65 X 85
                            (CARRERA PR:425)
                            # 4
                            MPN: 91157314700
                            BRACKET
                            (CARRERA)
                            # 4
                            MPN: 91157305900
                            RETAINER
                            # 5
                            MPN: 90014303102
                            TAPPING SCREW, FILL. HD. - B 4,2 X 9,5
                            from £0.82
                            from £0.82
                            # 5
                            MPN: 99959157502
                            speed nut - B 4,2 - Discontinued part
                            (CARRERA)
                            # 5
                            MPN: 99959157501
                            SPEED NUT - B 4,2
                            (CARRERA)
                            from £0.86
                            from £0.86
                            # 6
                            MPN: 90007514502
                            SCREW, HEX. HD. - M 5 X 15
                            from £0.89
                            from £0.89
                            # 7
                            MPN: 90002500302
                            Washer - A 5,3
                            # 8
                            MPN: 99950724802
                            SPEED NUT - M 5
                            from £1.34
                            from £1.34
                            # 9
                            MPN: 91157302700
                            COVER PLATE
                            # 10
                            MPN: 93051226300
                            COVER PLATE
                            (TURBO)
                            from £18.86
                            from £18.86
                            # 11
                            MPN: 93051226400
                            COVER PLATE
                            (TURBO)
                            # 12
                            MPN: 93051204701
                            BRACKET
                            (TURBO CARRERA PR:425)
                            from £14.23
                            from £14.23
                            # 13
                            MPN: 93051225800
                            RETAINING CLAMP
                            (TURBO)
                            from £5.26
                            from £5.26
                            # 14
                            MPN: 90006700802
                            SCREW, CHEESE HD. - M 6 X 12 - DISCONTINUED PART
                            (TURBO)
                            # 14
                            MPN: 90006700803
                            SCREW, CHEESE HD. - M 6 X 12
                            (TURBO)
                            from £0.82
                            from £0.82
                            # 15
                            MPN: N 0122265
                            spring washer - A 6
                            (TURBO)
                            from £0.70
                            from £0.70
                            # 16
                            MPN: 91157315305
                            Hose - NW 10 - D >> - MJ 1985
                            (CARRERA)
                            # 16
                            MPN: 91157315306
                            HOSE - NW 10
                            (CARRERA)
                            from £174.92
                            from £174.92
                            # 16
                            MPN: 91157315306
                            HOSE
                            (CARRERA)
                            from £174.92
                            from £174.92
                            # 16
                            MPN: 93057315103
                            HOSE - NW 10
                            (TURBO)
                            from £420.96
                            from £420.96
                            # 17
                            MPN: 99970725040
                            O-RING - 3/4 - DISCONTINUED PART
                            # 17
                            MPN: 99970743441
                            O-RING - 3/4
                            from £5.61
                            from £5.61
                            # 18
                            MPN: 90157314300
                            RUBBER GROMMET
                            from £4.76
                            from £4.76
                            # 18
                            MPN: 90157314300
                            RUBBER GROMMET
                            RHD
                            from £4.76
                            from £4.76
                            # 19
                            MPN: 91157314400
                            CLAMP
                            from £6.03
                            from £6.03
                            # 19
                            MPN: 99951106102
                            CLAMP - DISCONTINUED PART
                            # 19
                            MPN: 99951106101
                            CLAMP
                            from £2.52
                            from £2.52
                            # 20
                            MPN: N 0102076
                            SCREW, HEX. HD. - M 5 X 12 - DISCONTINUED PART
                            # 20
                            MPN: N 01020717
                            SCREW, HEX. HD. - M 5 X 12
                            from £0.47
                            from £0.47
                            # 20
                            MPN: N 0102095
                            SCREW, HEX. HD. - M 5 X 25
                            (TURBO)
                            from £1.47
                            from £1.47
                            # -
                            -
                            SPACER SLEEVE
                            (TURBO)
                            # 21
                            MPN: N 0120053
                            LOCK RING - B 5
                            from £0.66
                            from £0.66
                            # 22
                            MPN: 90007609101
                            hex. nut - M 5
                            from £1.00
                            from £1.00
                            # 23
                            MPN: 90018711502
                            Bolt with washer - B 5,5 X 16 - Discontinued part
                            # 23
                            MPN: 90018711501
                            BOLT WITH WASHER - B 5,5 X 16
                            from £4.00
                            from £4.00
                            # 23
                            MPN: N 0901831
                            TAPPING SCREW,FILL.HD.(COMBI.) - B 6,3 X 16
                            Supersession
                            Supersession
                            # 23
                            MPN: 90007514502
                            screw, hex. hd. - Discontinued part
                            from £0.89
                            from £0.89
                            # 23
                            MPN: 90007514502
                            SCREW, HEX. HD. - M 5 X 16
                            from £0.89
                            from £0.89
                            # -
                            -
                            HEX. NUT - M 5 - DISCONTINUED PART
                            # -
                            -
                            hex. nut - M 5
                            # -
                            -
                            LOCK RING - B 5
                            # 23
                            MPN: 99970413440
                            SEALING WASHER - 4 X 15 X 4,5
                            from £1.04
                            from £1.04
                            # 23
                            MPN: N 0115247
                            WASHER - A 6,4 - DISCONTINUED PART
                            # 23
                            MPN: N 01152427
                            Washer - A 6,4
                            from £0.47
                            from £0.47
                            # -
                            -
                            PROTECTIVE EDGING
                            (TURBO)
                            # 24
                            MPN: 91157315003
                            HOSE - NW 10 - DISCONTINUED PART
                            (CARRERA)
                            from £158.69
                            from £158.69
                            # 24
                            MPN: 91157315005
                            HOSE - NW 10
                            (CARRERA)
                            from £333.57
                            from £333.57
                            # 24
                            MPN: 93057315004
                            HOSE - NW 10
                            (TURBO)
                            from £226.94
                            from £226.94
                            # 24
                            MPN: 99970331200
                            BONDED RUBBER BUFFER - $=15 MM - M 5 X 10 - DISCONTINUED PART
                            (TURBO)
                            # 24
                            MPN: 99970331201
                            BONDED RUBBER BUFFER - $=15 MM - M 5 X 10
                            (TURBO)
                            from £21.04
                            from £21.04
                            # 25
                            MPN: 99951106102
                            CLAMP - DISCONTINUED PART
                            (CARRERA)
                            # 25
                            MPN: 99951106101
                            CLAMP
                            (CARRERA)
                            from £2.52
                            from £2.52
                            # 25
                            MPN: 99951208002
                            HOSE CLAMP
                            (TURBO)
                            from £3.29
                            from £3.29
                            # 26
                            MPN: 91157314903
                            HOSE - NW 13
                            # -
                            -
                            HOSE
                            RHD
                            # 27
                            MPN: 99970725140
                            O-RING - 7/8
                            from £2.43
                            from £2.43
                            # 28
                            MPN: 91157314500
                            CLAMP - DISCONTINUED PART
                            # 28
                            MPN: 91157314501
                            CLAMP
                            from £6.02
                            from £6.02
                            # 28
                            MPN: 99951111502
                            clamp - 22/20
                            from £4.08
                            from £4.08
                            # 28
                            MPN: 99951108002
                            CLAMP
                            from £2.62
                            from £2.62
                            # 29
                            MPN: 99970724740
                            O-RING - 5/8
                            from £2.68
                            from £2.68
