902-052 - MALE BLADE TERMINAL - PUSH-ON CONNECTOR
Porsche 1988 (911) MALE BLADE TERMINAL - PUSH-ON CONNECTOR Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 111971958
FLAT CONNECTOR WITH RETAINING - LUG - WITHOUT: - LOCKING SEGMENT - 2,8 X 1 CUZN
from £0.85
from £0.85
# 1
MPN: N 0172431
flat sleeve - without: - locking segment - 2,8 X 1,5 CUZN
from £0.64
from £0.64
# 2
MPN: 111971959
FLAT CONNECTOR WITH RETAINING - LUG - WITH: - LOCKING SEGMENT - 6,3 X 0,8
from £1.47
from £1.47
# 2
MPN: PCG971959
flat sleeve - without: - locking segment - 6,3 X 1,0 SN
from £0.78
from £0.78
# 2
MPN: N 0174918
FLAT CONNECTOR WITH RETAINING - LUG - 'ORDER QTY. 25' - WITH: - LOCKING SEGMENT - 6,3 X 2,5 CUZN
from £2.04
from £2.04
# 2
MPN: N 0174943
FLAT CONNECTOR WITH RETAINING - LUG - WITH: - LOCKING SEGMENT - 6,3 X 6,0 CUSN
from £3.28
from £3.28
# 2
MPN: 99965210602
FLAT SLEEVE - WITHOUT: - LOCKING SEGMENT - 6,3 X 1,5 CUSN
from £0.85
from £0.85
# 2
MPN: 99965210602
flat sleeve - without: - locking segment - 6,3 X 1,5 CUZN
from £0.85
from £0.85
# 2
MPN: N 0174918
FLAT CONNECTOR WITH RETAINING - LUG - 'ORDER QTY. 25' - WITHOUT: - LOCKING SEGMENT - 6,3 X 2,5 CUZN
from £2.04
from £2.04
# 2
MPN: N 0174943
FLAT CONNECTOR WITH RETAINING - LUG - WITHOUT: - LOCKING SEGMENT - 6,3 X 6,0 CUZN
from £3.28
from £3.28
# 3
MPN: N 0174531
flat sleeve - without: - locking segment - 7,7 X 2,5 CUZN
from £0.90
from £0.90
# 3
MPN: N 0172451
flat sleeve - without: - locking segment - 7,7 X 10 CUSN
# 5
MPN: N 0172421
FLAT SLEEVE - WITH: - PLUG CONNECTION - 6,3 X 1
from £1.16
from £1.16
# 6
MPN: N 0174982
ANGLED CONNECTOR - 6,3 X 1
from £0.84
from £0.84
# -
-
MALE BLADE TERMINAL - 7,7 X 1 CUZN
# 7
MPN: 99965211602
RETAINING BRACKET - 6,3 X 1,5
from £2.75
from £2.75
# 8
MPN: 99965212210
Plug connection - 6,3
from £1.12
from £1.12
# 9
MPN: N 0174572
MALE BLADE TERMINAL - WITH: - LOCKING SEGMENT - 2,8 X 1
from £0.64
from £0.64
# 10
MPN: 111971985
FLAT CONNECTOR WITH - RETAINING LUG - WITH: - LOCKING SEGMENT - 6,3 X 1
from £0.86
from £0.86
# 10
MPN: 111971986
FLAT CONNECTOR WITH - RETAINING LUG - WITH: - LOCKING SEGMENT - 6,3 X 2,5
from £0.72
from £0.72
# 11
MPN: 99965212510
MALE BLADE TERMINAL - 6,3 $ 2,8
# 11
MPN: 99965231502
MALE BLADE TERMINAL - 6,3 $ 5,3 CUSN
from £0.82
from £0.82
# 11
MPN: 99965231502
MALE BLADE TERMINAL - 6,3 $ 5,3 CUZN
from £0.82
from £0.82
# 11
MPN: 99965231502
MALE BLADE TERMINAL - 6,3 $ 5,3
from £0.82
from £0.82
# 12
MPN: 91160391100
MALE BLADE TERMINAL - 6,3
round
from £0.61
from £0.61
# 13
MPN: 171971519A
GROUND CONNECTOR - DISCONTINUED PART
# 13
MPN: PCG971519A
GROUND CONNECTOR
from £6.91
from £6.91
# 14
MPN: 99965214240
PUSH-ON CONNECTOR - 6,3 - 12-FACH
from £8.05
from £8.05
# 14
MPN: 99965214240
PUSH-ON CONNECTOR - 6,3 - 5-FACH
from £8.05
from £8.05
# 14
MPN: 99965214240
PUSH-ON CONNECTOR - 6,3
3 POINT
from £8.05
from £8.05
# 14
MPN: 99965214240
PUSH-ON CONNECTOR - 6,3 - 2-FACH
from £8.05
from £8.05
# 14
MPN: 99965214240
PUSH-ON CONNECTOR - 6,3 - 1-FACH
from £8.05
from £8.05
# 15
MPN: 99965215140
PUSH-ON CONNECTOR - 6,3
from £2.74
from £2.74
# 16
MPN: 99965227510
contact - 6,3
SQUARE
from £12.02
from £12.02
# 17
MPN: N 90335303
flat contact - 'order qty. 25' - $ 2,5 - 3,5
from £1.14
from £1.14
# 18
MPN: 99965245122
CONNECTOR HOUSING - 6,3 $ 0,5 - 1,0
# 19
MPN: 99965238012
spring contact - $ 0,4 - 0,75
from £1.12
from £1.12
# 19
MPN: 477971827B
wire connector - 2-FACH
from £9.79
from £9.79
# 19
MPN: 477971827B
wire connector - 1-FACH
from £9.79
from £9.79
# 20
MPN: 99965226912
SPRING CONTACT
from £2.04
from £2.04
# 21
MPN: 99965245622
spring contact - $ 0,75 - 1,5
from £1.12
from £1.12
