180-010 - SPECIAL MODEL - FLATNOSE DESIGN - OIL COOLER - D - MJ 1988>>
Porsche 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - OIL COOLER - D - MJ 1988>> Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 91110705101
OIL COOLER
# 2
MPN: 90007534102
BOLT WITH WASHER - M 6 X 25 - DISCONTINUED PART
# 2
MPN: 90007534101
BOLT WITH WASHER - M 6 X 25
from £0.80
from £0.80
# 3
MPN: N 0115247
WASHER - A 6,4 - DISCONTINUED PART
# 3
MPN: N 01152427
Washer - A 6,4
from £0.47
from £0.47
# 4
MPN: 90091001202
LOCK NUT - M 6 - DISCONTINUED PART
# 4
MPN: 90091004709
LOCK NUT - M 6
from £3.80
from £3.80
# 5
MPN: 93010791100
OIL HOSE - INTAKE
from £390.49
from £390.49
# 6
MPN: 93010791200
oil hose - Return line
# 7
MPN: 99951113002
clamp - 44/20
from £4.08
from £4.08
# 8
MPN: 90013401502
BANJO BOLT - A 20
from £21.20
from £21.20
# 9
MPN: 90012304930
SEAL RING - A 26 X 32
from £2.34
from £2.34
