811-012 - MAIN BOW - ROOF FRAME - SINGLE PARTS
Porsche 1989 (911) MAIN BOW - ROOF FRAME - SINGLE PARTS Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 91156192700
MAIN BOW
LEFT
Supersession
Supersession
# 1
MPN: 91156192800
MAIN BOW
RIGHT
Supersession
Supersession
# 2
MPN: 99950406902
THREADED INSERT - M 6
from £3.48
from £3.48
# 3
MPN: 91156121500
BOW PLATE
from £177.52
from £177.52
# 4
MPN: 90002500302
Washer - A 5,3
# 5
MPN: 90026901702
SCREW, CSK. HD. - M 5 X 12
from £0.82
from £0.82
# 6
MPN: 90091000702
LOCK NUT - M 5
from £0.59
from £0.59
# 7
MPN: 91156144965
RETAINING PIVOT
from £21.78
from £21.78
# 8
MPN: 90007606207
hex. nut - M 8
from £2.04
from £2.04
# 9
MPN: 91156142300
PLATE - 2 MM
from £3.88
from £3.88
# 9
MPN: 91156142301
PLATE - 1 MM
from £3.02
from £3.02
# 11
MPN: 90006727109
BOLT WITH WASHER - M 8 X 20
# 12
MPN: 91156147100
GASKET
from £20.83
from £20.83
# 13
MPN: 91156147500
PLATE
from £15.24
from £15.24
# 14
MPN: 90026905607
SCREW, CSK. HD. - M 4 X 10
from £3.48
from £3.48
# 15
MPN: 99950702002
SPEED NUT - B 4,2
# 15
MPN: 99950702001
SPEED NUT - 4,2
from £0.74
from £0.74
# 16
MPN: 91156103500
RAIL
# 17
MPN: 99950701802
speed nut - B 4,2 - Discontinued part
# 17
MPN: 99950701801
SPEED NUT - B 4,2
from £0.90
from £0.90
# 18
MPN: 91156152700
WHEEL CHOCK
from £5.13
from £5.13
# 19
MPN: 90018701402
tapping screw,hex.hd. - BZ 4,2 X 16
# 20
MPN: 91156102701
ROOF FRAME
# 20
MPN: 91156102702
ROOF FRAME
# 21
MPN: 91156521460
LOCATING PEG
from £10.83
from £10.83
# 22
MPN: 90002500702
WASHER - A 8,4 X 16 X 1,6 - DISCONTINUED PART
# 22
MPN: 90002500703
WASHER - A 8,4 X 16 X 1,6
from £0.84
from £0.84
# 23
MPN: 91156503163
CATCH - D >> - MJ 1988 - DISCONTINUED PART
LEFT
Supersession
Supersession
# 23
MPN: 91156503263
CATCH - D >> - MJ 1988 - DISCONTINUED PART
RIGHT
Supersession
Supersession
# 23
MPN: 91156503164
CATCH - DISCONTINUED PART
LEFT
# 23
MPN: 96456503100
CATCH
LEFT
from £197.40
from £197.40
This part replaces part number 91156503100 - and 1 more. Click to view details
# 23
MPN: 91156503264
CATCH - DISCONTINUED PART
RIGHT
# 23
MPN: 96456503200
CATCH
RIGHT
Supersession
Supersession
This part replaces part number 91156503200 - and 1 more. Click to view details
# 24
MPN: 91156154701
TAPPING PLATE
from £31.23
from £31.23
# 25
MPN: 91156507561
handle - D >> - MJ 1988 - Discontinued part
# 25
MPN: 91156507562
HANDLE
# 26
MPN: N 0154041
WASHER - A 6,4 - DISCONTINUED PART
# 26
MPN: 90022303002
WASHER - A 6,4 - DISCONTINUED PART
# 26
MPN: 90022300302
Washer - A 6,4
from £0.82
from £0.82
# 27
MPN: N 0147402
SCREW, CHEESE HD. - M 6 X 16
# 27
MPN: N 01474011
bolt, with hex. socket - hd. - M 6 X 16
from £1.26
from £1.26
# 28
MPN: 91156113965
END PIECE
LEFT
from £3.02
from £3.02
# 28
MPN: 91156114065
END PIECE
RIGHT
from £3.02
from £3.02
# 29
MPN: N 01408612
TAPPING SCREW - 3,5 X 13 - DISCONTINUED PART
# 29
MPN: N 0140861C
TAPPING SCREW - 3,5 X 13
from £1.11
from £1.11
# 30
MPN: 99959176240
SPEED NUT - B 3,5
from £0.47
from £0.47
# 31
MPN: 91156145300
JOUNCE BUMPER
from £6.86
from £6.86
# 32
MPN: 91156145100
HOUSING
# 33
MPN: 90026904302
SCREW, CSK. HD. - M 4 X 12
from £0.82
from £0.82
# 34
MPN: 91156101965
INTERMED. FOLDING TOP BOW
# 35
MPN: 91156146100
SHAFT SCREW - M 8 X 20
from £19.80
from £19.80
# 36
MPN: 91156142800
WASHER - 10,5
from £2.55
from £2.55
# 37
MPN: 91156140200
ECCENTRIC WASHER
from £9.49
from £9.49
# 38
MPN: N 0331851
SCREW, CSK. HD. - M 4 X 16
from £1.10
from £1.10
# 39
MPN: 91156142100
shaft screw - Micro-self-locking - M 8 X 24
from £9.49
from £9.49
# 40
MPN: 91156115700
SWING LEVER
LEFT
# 40
MPN: 91156115800
SWING LEVER
RIGHT
# 41
MPN: 91156159565
JOINT FORK - DISCONTINUED PART
# 41
MPN: 91156159566
JOINT FORK
from £33.12
from £33.12
# 43
MPN: 91156176165
PIN
from £5.63
from £5.63
# 44
MPN: 99916603402
retainer plate - 8
from £3.54
from £3.54
# 45
MPN: 91156143165
BRACKET
from £14.52
from £14.52
# 46
MPN: 91156158565
TAPPING PLATE
from £4.97
from £4.97
# 47
MPN: 90002500702
WASHER - A 8,4 - DISCONTINUED PART
# 47
MPN: 90002500703
Washer - A 8,4
from £0.84
from £0.84
# 48
MPN: 90002500809
WASHER - A 10,5 - DISCONTINUED PART
# 48
MPN: 90002500804
Washer - A 10,5
from £0.80
from £0.80
This part replaces part number 90002500802
# 48
MPN: 9000250080E
Washer - A 10,5
Yellow
from £0.62
from £0.62
# 49
MPN: 90007508702
SCREW, HEX. HD. - M 8 X 16 - DISCONTINUED PART
# 49
MPN: 90007508703
SCREW, HEX. HD. - M 8 X 16
Supersession
Supersession
# 49
MPN: 90007508704
SCREW, HEX. HD. - M 8 X 16
M8X16-yellow
from £0.86
from £0.86
This part replaces part number 90007508703
# 50
MPN: N 01101013
hex. nut - M 10
from £1.48
from £1.48
# 51
MPN: 91156141800
SHAFT SCREW - M 8 X 20
Supersession
Supersession
# 52
MPN: 91156111900
SWING LEVER
LEFT
# 52
MPN: 91156112000
SWING LEVER
RIGHT
# 52
MPN: 91156111965
SWING LEVER
left (PR:439)
# 52
MPN: 91156112065
SWING LEVER
right (PR:439)
# 53
MPN: 91156142000
shaft screw - Micro-self-locking - M 10 X 28
from £28.34
from £28.34
# 54
MPN: 91156143000
WASHER - 13,5
from £1.80
from £1.80
# 55
MPN: 90155287140
COVERS
# 56
MPN: 90025000602
TAPPING SCREW - AM 5 X 10
from £1.12
from £1.12
# 57
MPN: 90155287220
COAT HOOK
from £2.05
from £2.05
-part-diagram-811-013.webp "PORSCHE 1989 (911) CONVERTIBLE TOP - BRACKET - SINGLE PARTS PARTS DIAGRAM")
-part-diagram-811-015.webp "PORSCHE 1989 (911) CONVERTIBLE TOP COVERING - SEAL STRIP - SINGLE PARTS PARTS DIAGRAM")
-part-diagram-811-016.webp "PORSCHE 1989 (911) BOOT COVER PARTS DIAGRAM")
-part-diagram-811-020.webp "PORSCHE 1989 (911) CONVERTIBLE TOP - TOP FRAME - ELECTRICALLY ADJUSTABLE PARTS DIAGRAM")
-part-diagram-811-021.webp "PORSCHE 1989 (911) CONVERTIBLE TOP - DRIVING MECHANISM PARTS DIAGRAM")
-part-diagram-811-022.webp "PORSCHE 1989 (911) CONVERTIBLE TOP - CATCH - ELECTRICALLY ADJUSTABLE PARTS DIAGRAM")
-part-diagram-811-030.webp "PORSCHE 1989 (911) EMERGENCY FOLDING TOP - COMPLETE - MAIN BOW - SINGLE PARTS - D - MJ 1989>> - MJ 1989 PARTS DIAGRAM")
-part-diagram-811-031.webp "PORSCHE 1989 (911) CONVERTIBLE TOP COVERING - TOP FRAME - SINGLE PARTS - D - MJ 1989>> - MJ 1989 PARTS DIAGRAM")
-part-diagram-811-032.webp "PORSCHE 1989 (911) EMERGENCY FOLDING TOP - SEAL STRIP - ROOF FRAME - D - MJ 1989>> - MJ 1989 PARTS DIAGRAM")
-part-diagram-811-035.webp "PORSCHE 1989 (911) REAR COVERING - D - MJ 1989>> - MJ 1989 PARTS DIAGRAM")
-part-diagram-811-036.webp "PORSCHE 1989 (911) REAR COVERING - RELAY SHAFT - SINGLE PARTS - D - MJ 1989>> - MJ 1989 PARTS DIAGRAM")
-part-diagram-811-040.webp "PORSCHE 1989 (911) TONNEAU COVER - COVER CLIP PARTS DIAGRAM")
-part-diagram-812-000.webp "PORSCHE 1989 (911) SEAT BELT PARTS DIAGRAM")
-part-diagram-812-005.webp "PORSCHE 1989 (911) SEAT BELT PARTS DIAGRAM")
-part-diagram-813-000.webp "PORSCHE 1989 (911) VENTILATION - HEATING SYSTEM 1 PARTS DIAGRAM")
-part-diagram-813-001.webp "PORSCHE 1989 (911) VENTILATION - HEATING SYSTEM 2 PARTS DIAGRAM")
-part-diagram-813-002.webp "PORSCHE 1989 (911) ADDITIONAL BLOWER - AIR DUCT PARTS DIAGRAM")
-part-diagram-813-005.webp "PORSCHE 1989 (911) AIR CONDITIONER - EVAPORATOR HOUSING - SINGLE PARTS PARTS DIAGRAM")
-part-diagram-813-010.webp "PORSCHE 1989 (911) COOLING AIR DUCT PARTS DIAGRAM")
-part-diagram-813-011.webp "PORSCHE 1989 (911) COOLING AIR DUCT PARTS DIAGRAM")
-part-diagram-813-015.webp "PORSCHE 1989 (911) COMPRESSOR PARTS DIAGRAM")
-part-diagram-813-020.webp "PORSCHE 1989 (911) COMPRESSOR - MOUNTING - DRIVING MECHANISM PARTS DIAGRAM")
-part-diagram-813-040.webp "PORSCHE 1989 (911) ELECTRICAL COMPONENTS - FOR - AIR CONDITIONER PARTS DIAGRAM")
-part-diagram-813-045.webp "PORSCHE 1989 (911) CAPACITOR - LINES - ACCESSORIES AND OTHERS PARTS DIAGRAM")
-part-diagram-813-050.webp "PORSCHE 1989 (911) FAN PARTS DIAGRAM")
-part-diagram-813-055.webp "PORSCHE 1989 (911) CAPACITOR - LINES - ACCESSORIES AND OTHERS PARTS DIAGRAM")
-part-diagram-880-000.webp "PORSCHE 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - INTERIOR PANELLING PARTS DIAGRAM")
-part-diagram-880-020.webp "PORSCHE 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - EXTERIOR PANELLING - FENDER PARTS DIAGRAM")
-part-diagram-880-025.webp "PORSCHE 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - EXTERIOR PANELLING - BUMPER - D - MJ 1988>> PARTS DIAGRAM")
-part-diagram-880-030.webp "PORSCHE 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - EXTERIOR PANELLING PARTS DIAGRAM")
-part-diagram-880-040.webp "PORSCHE 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - EXTERIOR PANELLING PARTS DIAGRAM")
-part-diagram-880-050.webp "PORSCHE 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - INTERIOR EQUIPMENT - FRONT LUGGAGE COMPARTMENT PARTS DIAGRAM")
-part-diagram-901-000.webp "PORSCHE 1989 (911) ENGINE ELECTRICS 1 PARTS DIAGRAM")
-part-diagram-901-002.webp "PORSCHE 1989 (911) ENGINE ELECTRICS 2 PARTS DIAGRAM")
-part-diagram-901-003.webp "PORSCHE 1989 (911) ENGINE ELECTRICS 3 PARTS DIAGRAM")
-part-diagram-902-000.webp "PORSCHE 1989 (911) CONTROL UNITS - RELAY - FUSE BOX PARTS DIAGRAM")
-part-diagram-902-005.webp "PORSCHE 1989 (911) BATTERY - STARTER - ALTERNATOR PARTS DIAGRAM")
-part-diagram-902-010.webp "PORSCHE 1989 (911) WIRING HARNESSES - PASSENGER COMPARTMENT - STARTER BATTERY - LUGGAGE COMPARTMENT FLOOR PARTS DIAGRAM")
-part-diagram-902-012.webp "PORSCHE 1989 (911) WIRING HARNESSES - FRONT END PARTS DIAGRAM")
-part-diagram-902-014.webp "PORSCHE 1989 (911) WIRING HARNESSES - PASSENGER COMPARTMENT - BODY SHELL PARTS DIAGRAM")
-part-diagram-902-016.webp "PORSCHE 1989 (911) WIRING HARNESSES - BODY SHELL - DOOR PARTS DIAGRAM")
-part-diagram-902-018.webp "PORSCHE 1989 (911) WIRING HARNESSES - REAR END PARTS DIAGRAM")
-part-diagram-902-020.webp "PORSCHE 1989 (911) WIRING HARNESSES - ENGINE - - DME - - O2 SENSOR CLOSED-LOOP CTRL PARTS DIAGRAM")
-part-diagram-902-050.webp "PORSCHE 1989 (911) PIN (MALE) TERMINAL - CONTACT PIN - CABLE SHOE PARTS DIAGRAM")
-part-diagram-902-052.webp "PORSCHE 1989 (911) MALE BLADE TERMINAL - PUSH-ON CONNECTOR PARTS DIAGRAM")
-part-diagram-902-054.webp "PORSCHE 1989 (911) BUTT CONNECTOR - CONNECTOR HOUSING PARTS DIAGRAM")
-part-diagram-902-056.webp "PORSCHE 1989 (911) CONNECTOR HOUSING PARTS DIAGRAM")
-part-diagram-902-058.webp "PORSCHE 1989 (911) CONNECTOR HOUSING PARTS DIAGRAM")
-part-diagram-902-060.webp "PORSCHE 1989 (911) CONNECTOR HOUSING PARTS DIAGRAM")
-part-diagram-902-062.webp "PORSCHE 1989 (911) CONNECTOR HOUSING PARTS DIAGRAM")
-part-diagram-902-064.webp "PORSCHE 1989 (911) CONNECTOR HOUSING PARTS DIAGRAM")
-part-diagram-902-066.webp "PORSCHE 1989 (911) CONNECTOR HOUSING PARTS DIAGRAM")
-part-diagram-903-000.webp "PORSCHE 1989 (911) HORN PARTS DIAGRAM")
-part-diagram-903-004.webp "PORSCHE 1989 (911) INTERIOR LIGHTS PARTS DIAGRAM")
-part-diagram-903-006.webp "PORSCHE 1989 (911) SWITCH PARTS DIAGRAM")
-part-diagram-903-010.webp "PORSCHE 1989 (911) STEERING COLUMN SWITCH PARTS DIAGRAM")
-part-diagram-904-000.webp "PORSCHE 1989 (911) WINDSCREEN WIPER SYSTEM PARTS DIAGRAM")
-part-diagram-904-005.webp "PORSCHE 1989 (911) REAR WINDOW WIPER PARTS DIAGRAM")
-part-diagram-904-010.webp "PORSCHE 1989 (911) WINDSHIELD WASHER UNIT PARTS DIAGRAM")
-part-diagram-904-015.webp "PORSCHE 1989 (911) INTENSIVE WINDSCREEN WASHER PARTS DIAGRAM")
-part-diagram-904-020.webp "PORSCHE 1989 (911) HEADLIGHT WASHER SYSTEM PARTS DIAGRAM")
-part-diagram-905-000.webp "PORSCHE 1989 (911) HEADLAMP PARTS DIAGRAM")
-part-diagram-905-002.webp "PORSCHE 1989 (911) BEAM LENGTH ADJUSTMENT PARTS DIAGRAM")
-part-diagram-905-005.webp "PORSCHE 1989 (911) COVERING - COMBINED LIGHTS PARTS DIAGRAM")
-part-diagram-905-010.webp "PORSCHE 1989 (911) ADDITIONAL BRAKE LIGHT PARTS DIAGRAM")
-part-diagram-907-000.webp "PORSCHE 1989 (911) CRUISE CONTROL SYSTEM - D - MJ 1987>> - MJ 1987 PARTS DIAGRAM")
-part-diagram-907-001.webp "PORSCHE 1989 (911) CRUISE CONTROL SYSTEM - D - MJ 1988>> PARTS DIAGRAM")
-part-diagram-908-000.webp "PORSCHE 1989 (911) HEATER - ADDITIONAL BLOWER PARTS DIAGRAM")
-part-diagram-909-000.webp "PORSCHE 1989 (911) EMISSION CONTROL PARTS DIAGRAM")
-part-diagram-910-000.webp "PORSCHE 1989 (911) ALARM SYSTEM PARTS DIAGRAM")
-part-diagram-910-005.webp "PORSCHE 1989 (911) PORSCHE CLASSIC - LOUDSPEAKER KIT - SOUND SYSTEM PARTS DIAGRAM")
-part-diagram-911-000.webp "PORSCHE 1989 (911) RADIO UNIT - LOUDSPEAKER - INSTALLATION PARTS - SEE TPI - GR.9 , NR.7 , 07/94 - GR.9 , NR.10 , 09/94 PARTS DIAGRAM")
-part-diagram-912-000.webp "PORSCHE 1989 (911) PHONE PREPARATION - D - MJ 1988>> - MJ 1988 PARTS DIAGRAM")
-part-diagram-912-001.webp "PORSCHE 1989 (911) PHONE PREPARATION PARTS DIAGRAM")
-part-diagram-980-000.webp "PORSCHE 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - POP-UP HEADLIGHT PARTS DIAGRAM")
-part-diagram-980-005.webp "PORSCHE 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - ADDITIONAL HEADLIGHT - D - MJ 1988>> PARTS DIAGRAM")
-part-diagram-980-010.webp "PORSCHE 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - WIRING HARNESSES - RELAY PARTS DIAGRAM")
-part-diagram-980-020.webp "PORSCHE 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - WINDSHIELD WASHER UNIT - HORN PARTS DIAGRAM")
-part-diagram-001-000.webp "PORSCHE 1989 (911) TOOL - JACK - FIRST AID KIT PARTS DIAGRAM")
-part-diagram-001-002.webp "PORSCHE 1989 (911) TOOL KIT BAG PARTS DIAGRAM")
-part-diagram-001-003.webp "PORSCHE 1989 (911) CLEANING AGENT - PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-001-004.webp "PORSCHE 1989 (911) ACCESSORIES - PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-001-005.webp "PORSCHE 1989 (911) STICKER PARTS DIAGRAM")
-part-diagram-001-010.webp "PORSCHE 1989 (911) IDENTIFICATION PLATE PARTS DIAGRAM")
-part-diagram-001-015.webp "PORSCHE 1989 (911) FLOOR MAT PARTS DIAGRAM")
-part-diagram-002-000.webp "PORSCHE 1989 (911) ACCESSORIES - SNOW CHAINS PARTS DIAGRAM")
-part-diagram-002-001.webp "PORSCHE 1989 (911) ACCESSORIES - CHILD SEAT - FLOOR MAT - VEHICLE COVER PARTS DIAGRAM")
-part-diagram-002-005.webp "PORSCHE 1989 (911) ROOF TRANSPORT SYSTEM PARTS DIAGRAM")
-part-diagram-002-006.webp "PORSCHE 1989 (911) ROOF TRANSPORT SYSTEM PARTS DIAGRAM")
-part-diagram-004-000.webp "PORSCHE 1989 (911) LACQUERS - BASIC MATERIALS PARTS DIAGRAM")
-part-diagram-080-000.webp "PORSCHE 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - JACK - ACCESSORIES PARTS DIAGRAM")
-part-diagram-080-005.webp "PORSCHE 1989 (911) OWNER'S MANUAL - CARE PASS PARTS DIAGRAM")
-part-diagram-101-000.webp "PORSCHE 1989 (911) REPLACEMENT ENGINE - READY FOR INSTALLATION PARTS DIAGRAM")
-part-diagram-101-005.webp "PORSCHE 1989 (911) CRANKCASE - REPAIR SET FOR MAINTENANCE - SEE ILLUSTRATION: PARTS DIAGRAM")
-part-diagram-101-010.webp "PORSCHE 1989 (911) CRANKCASE - REPAIR SET FOR MAINTENANCE - SEE ILLUSTRATION: PARTS DIAGRAM")
-part-diagram-102-000.webp "PORSCHE 1989 (911) CRANKSHAFT PARTS DIAGRAM")
-part-diagram-102-005.webp "PORSCHE 1989 (911) CYLINDER WITH PISTONS PARTS DIAGRAM")
-part-diagram-103-000.webp "PORSCHE 1989 (911) CYLINDER HEAD - REPAIR SET FOR MAINTENANCE - SEE ILLUSTRATION: PARTS DIAGRAM")
-part-diagram-103-005.webp "PORSCHE 1989 (911) CAMSHAFT HOUSING - CHAIN CASE - REPAIR SET FOR MAINTENANCE - SEE ILLUSTRATION: PARTS DIAGRAM")
-part-diagram-103-010.webp "PORSCHE 1989 (911) VALVE CONTROL PARTS DIAGRAM")
-part-diagram-103-015.webp "PORSCHE 1989 (911) VALVE CONTROL PARTS DIAGRAM")
-part-diagram-104-000.webp "PORSCHE 1989 (911) ENGINE LUBRICATION - OIL PUMP - LINES - SEE TECHNICAL INFORMATION - GR.1 NR.1/1A-85 PARTS DIAGRAM")
-part-diagram-104-001.webp "PORSCHE 1989 (911) ENGINE LUBRICATION - OIL TANK - LINES PARTS DIAGRAM")
-part-diagram-104-002.webp "PORSCHE 1989 (911) OIL SEPARATOR PARTS DIAGRAM")
-part-diagram-104-005.webp "PORSCHE 1989 (911) ENGINE LUBRICATION - OIL COOLER PARTS DIAGRAM")
-part-diagram-105-000.webp "PORSCHE 1989 (911) AIR COOLING PARTS DIAGRAM")
-part-diagram-105-005.webp "PORSCHE 1989 (911) AIR DUCT PARTS DIAGRAM")
-part-diagram-106-000.webp "PORSCHE 1989 (911) AIR CLEANER - - REPAIR SET FOR MAINTENANCE - SEE ILLUSTRATION: PARTS DIAGRAM")
-part-diagram-106-005.webp "PORSCHE 1989 (911) AIR CLEANER PARTS DIAGRAM")
-part-diagram-107-000.webp "PORSCHE 1989 (911) FOR - L-JETRONIC I PARTS DIAGRAM")
-part-diagram-107-005.webp "PORSCHE 1989 (911) FOR - L-JETRONIC II PARTS DIAGRAM")
-part-diagram-107-010.webp "PORSCHE 1989 (911) FOR - L-JETRONIC III PARTS DIAGRAM")
-part-diagram-107-012.webp "PORSCHE 1989 (911) THROTTLE LINKAGE - BRACKET PARTS DIAGRAM")
-part-diagram-107-015.webp "PORSCHE 1989 (911) MIXTURE CONTROL UNIT PARTS DIAGRAM")
-part-diagram-107-020.webp "PORSCHE 1989 (911) FOR - K-JETRONIC I PARTS DIAGRAM")
-part-diagram-107-030.webp "PORSCHE 1989 (911) FOR - K-JETRONIC II PARTS DIAGRAM")
-part-diagram-107-035.webp "PORSCHE 1989 (911) FOR - K-JETRONIC III PARTS DIAGRAM")
-part-diagram-107-040.webp "PORSCHE 1989 (911) TURBOCHARGING PARTS DIAGRAM")
-part-diagram-107-045.webp "PORSCHE 1989 (911) CHARGE AIR COOLER PARTS DIAGRAM")
-part-diagram-108-000.webp "PORSCHE 1989 (911) AIR INJECTION PARTS DIAGRAM")
-part-diagram-108-005.webp "PORSCHE 1989 (911) AIR INJECTION PARTS DIAGRAM")
-part-diagram-108-007.webp "PORSCHE 1989 (911) AIR INJECTION PARTS DIAGRAM")
-part-diagram-108-010.webp "PORSCHE 1989 (911) ADDITIONAL BLOWER PARTS DIAGRAM")
-part-diagram-109-000.webp "PORSCHE 1989 (911) ENGINE SUSPENSION PARTS DIAGRAM")
-part-diagram-180-010.webp "PORSCHE 1989 (911) SPECIAL MODEL - FLATNOSE DESIGN - OIL COOLER - D - MJ 1988>> PARTS DIAGRAM")
-part-diagram-198-000.webp "PORSCHE 1989 (911) GASKET SET - REPAIR KITS - REPAIR SET FOR MAINTENANCE PARTS DIAGRAM")
-part-diagram-198-005.webp "PORSCHE 1989 (911) ENGINE OIL - PORSCHE CLASSIC 10W60 PARTS DIAGRAM")
-part-diagram-201-000.webp "PORSCHE 1989 (911) FUEL SYSTEM PARTS DIAGRAM")
-part-diagram-201-005.webp "PORSCHE 1989 (911) FUEL SYSTEM PARTS DIAGRAM")
-part-diagram-201-010.webp "PORSCHE 1989 (911) FUEL SYSTEM PARTS DIAGRAM")
-part-diagram-201-015.webp "PORSCHE 1989 (911) TANK VENTILATION PARTS DIAGRAM")
-part-diagram-201-020.webp "PORSCHE 1989 (911) EVAPORATIVE EMISSION CANISTER PARTS DIAGRAM")
-part-diagram-202-000.webp "PORSCHE 1989 (911) EXHAUST SYSTEM PARTS DIAGRAM")
-part-diagram-202-005.webp "PORSCHE 1989 (911) EXHAUST SYSTEM PARTS DIAGRAM")
-part-diagram-202-010.webp "PORSCHE 1989 (911) EXHAUST SYSTEM PARTS DIAGRAM")
-part-diagram-202-015.webp "PORSCHE 1989 (911) EXHAUST SYSTEM PARTS DIAGRAM")
-part-diagram-202-016.webp "PORSCHE 1989 (911) EXHAUST GAS TURBOCHARGER PARTS DIAGRAM")
-part-diagram-202-020.webp "PORSCHE 1989 (911) HEATING AIR SUPPLY PARTS DIAGRAM")
-part-diagram-298-000.webp "PORSCHE 1989 (911) ASSEMBLY KIT - REPAIR KIT - MAINTENANCE SET PARTS DIAGRAM")
-part-diagram-298-005.webp "PORSCHE 1989 (911) PORSCHE CLASSIC - ADDITIVE - FOR FUEL PARTS DIAGRAM")
-part-diagram-301-000.webp "PORSCHE 1989 (911) CLUTCH PARTS DIAGRAM")
-part-diagram-301-005.webp "PORSCHE 1989 (911) CLUTCH RELEASE - MECHANICAL PARTS DIAGRAM")
-part-diagram-301-007.webp "PORSCHE 1989 (911) CLUTCH RELEASE - HYDRAULIC PARTS DIAGRAM")
-part-diagram-302-000.webp "PORSCHE 1989 (911) REPLACEMENT TRANSMISSION - TRANSMISSION CASE PARTS DIAGRAM")
-part-diagram-302-002.webp "PORSCHE 1989 (911) REPLACEMENT TRANSMISSION - TRANSMISSION CASE PARTS DIAGRAM")
-part-diagram-302-005.webp "PORSCHE 1989 (911) GEAR HOUSING - TRANSMISSION COVER PARTS DIAGRAM")
-part-diagram-302-007.webp "PORSCHE 1989 (911) GEAR HOUSING - TRANSMISSION COVER PARTS DIAGRAM")
-part-diagram-303-000.webp "PORSCHE 1989 (911) GEAR WHEEL SETS - 4-SPEED PARTS DIAGRAM")
-part-diagram-303-005.webp "PORSCHE 1989 (911) GEARS AND SHAFTS - 4-SPEED PARTS DIAGRAM")
-part-diagram-303-010.webp "PORSCHE 1989 (911) GEAR WHEEL SETS - 5-SPEED PARTS DIAGRAM")
-part-diagram-303-015.webp "PORSCHE 1989 (911) GEARS AND SHAFTS - 5-SPEED PARTS DIAGRAM")
-part-diagram-304-000.webp "PORSCHE 1989 (911) SHIFT RODS - SHIFT FORKS - FOR - 4-SPEED - AND - 5-SPEED PARTS DIAGRAM")
-part-diagram-304-005.webp "PORSCHE 1989 (911) TENSIONING PLATE - SHIFT CONTROL LOCK DEVICE - 5-SPEED PARTS DIAGRAM")
-part-diagram-305-000.webp "PORSCHE 1989 (911) DIFFERENTIAL PARTS DIAGRAM")
-part-diagram-305-005.webp "PORSCHE 1989 (911) LIMITED SLIP DIFFERENTIAL PARTS DIAGRAM")
-part-diagram-306-000.webp "PORSCHE 1989 (911) TRANSMISSION SUSPENSION PARTS DIAGRAM")
-part-diagram-398-000.webp "PORSCHE 1989 (911) GASKET SET PARTS DIAGRAM")
-part-diagram-401-000.webp "PORSCHE 1989 (911) FRONT AXLE - STABILIZER PARTS DIAGRAM")
-part-diagram-402-000.webp "PORSCHE 1989 (911) SHOCK ABSORBER STRUT - LUBRICANTS PARTS DIAGRAM")
-part-diagram-403-000.webp "PORSCHE 1989 (911) STEERING PARTS PARTS DIAGRAM")
-part-diagram-403-005.webp "PORSCHE 1989 (911) STEERING PARTS PARTS DIAGRAM")
-part-diagram-501-000.webp "PORSCHE 1989 (911) REAR AXLE PARTS DIAGRAM")
-part-diagram-501-005.webp "PORSCHE 1989 (911) DRIVE SHAFT - REAR-WHEEL HUB PARTS DIAGRAM")
-part-diagram-502-000.webp "PORSCHE 1989 (911) VIBRATION DAMPER - STABILIZER PARTS DIAGRAM")
-part-diagram-601-000.webp "PORSCHE 1989 (911) WHEELS PARTS DIAGRAM")
-part-diagram-602-000.webp "PORSCHE 1989 (911) BRAKE - FRONT AXLE PARTS DIAGRAM")
-part-diagram-602-005.webp "PORSCHE 1989 (911) BRAKE - FRONT AXLE PARTS DIAGRAM")
-part-diagram-603-000.webp "PORSCHE 1989 (911) BRAKE - REAR AXLE PARTS DIAGRAM")
-part-diagram-603-005.webp "PORSCHE 1989 (911) BRAKE - REAR AXLE PARTS DIAGRAM")
-part-diagram-604-000.webp "PORSCHE 1989 (911) RESERVOIR FOR - BRAKE FLUID - BRAKE MASTER CYLINDER PARTS DIAGRAM")
-part-diagram-604-005.webp "PORSCHE 1989 (911) BRAKE LINE PARTS DIAGRAM")
-part-diagram-604-010.webp "PORSCHE 1989 (911) BRAKE LINE PARTS DIAGRAM")
-part-diagram-698-005.webp "PORSCHE 1989 (911) BRAKE FLUID - PORSCHE CLASSIC PARTS DIAGRAM")
-part-diagram-701-000.webp "PORSCHE 1989 (911) TRANSMISSION CONTROL - D >> - MJ 1988 PARTS DIAGRAM")
-part-diagram-701-001.webp "PORSCHE 1989 (911) TRANSMISSION CONTROL PARTS DIAGRAM")
-part-diagram-701-005.webp "PORSCHE 1989 (911) HAND BRAKE LEVER - OPERATING LEVER - FOR - HEATER PARTS DIAGRAM")
-part-diagram-702-000.webp "PORSCHE 1989 (911) PEDALS - D >> - MJ 1988 PARTS DIAGRAM")
-part-diagram-702-005.webp "PORSCHE 1989 (911) PEDALS - D >> - MJ 1988 PARTS DIAGRAM")
-part-diagram-702-006.webp "PORSCHE 1989 (911) PEDALS PARTS DIAGRAM")
-part-diagram-702-007.webp "PORSCHE 1989 (911) PEDALS PARTS DIAGRAM")
-part-diagram-702-008.webp "PORSCHE 1989 (911) HYDRAULIC CLUTCH - OPERATION - CLUTCH MASTER CYLINDER - HYDRAULIC CLUTCH PIPE PARTS DIAGRAM")
-part-diagram-702-010.webp "PORSCHE 1989 (911) PEDALS - FOR - THROTTLE CONTROL PARTS DIAGRAM")
-part-diagram-801-000.webp "PORSCHE 1989 (911) CAR BODY PARTS DIAGRAM")
-part-diagram-801-020.webp "PORSCHE 1989 (911) INNER PANEL PARTS DIAGRAM")
-part-diagram-801-025.webp "PORSCHE 1989 (911) INTERIOR PANELLING PARTS DIAGRAM")
-part-diagram-801-030.webp "PORSCHE 1989 (911) FENDER - WITH: - SHEET METAL CUP FOR TANK PARTS DIAGRAM")
-part-diagram-801-031.webp "PORSCHE 1989 (911) FENDER - WITH: - PLASTIC CUP FOR TANK - TO FIT USE WORKSHOP MATERIAL PARTS DIAGRAM")
-part-diagram-801-035.webp "PORSCHE 1989 (911) EXTERIOR PANELLING - TO FIT USE WORKSHOP MATERIAL PARTS DIAGRAM")
-part-diagram-801-040.webp "PORSCHE 1989 (911) EXTERIOR PANELLING - - TO FIT USE WORKSHOP MATERIAL PARTS DIAGRAM")
-part-diagram-802-000.webp "PORSCHE 1989 (911) BUMPER PARTS DIAGRAM")
-part-diagram-802-001.webp "PORSCHE 1989 (911) COVER FOR BUMPER - FRONT SPOILER - CARRERA PARTS DIAGRAM")
-part-diagram-802-005.webp "PORSCHE 1989 (911) BUMPER PARTS DIAGRAM")
-part-diagram-803-000.webp "PORSCHE 1989 (911) COVER PARTS DIAGRAM")
-part-diagram-803-005.webp "PORSCHE 1989 (911) COVER PARTS DIAGRAM")
-part-diagram-803-010.webp "PORSCHE 1989 (911) REAR SPOILER PARTS DIAGRAM")
-part-diagram-804-000.webp "PORSCHE 1989 (911) ACCESSORIES - DOORS PARTS DIAGRAM")
-part-diagram-804-005.webp "PORSCHE 1989 (911) INSTALLATION PARTS - DOORS PARTS DIAGRAM")
-part-diagram-804-006.webp "PORSCHE 1989 (911) CENTRAL LOCKING SYSTEM PARTS DIAGRAM")
-part-diagram-804-010.webp "PORSCHE 1989 (911) WINDOW REGULATOR PARTS DIAGRAM")
-part-diagram-804-015.webp "PORSCHE 1989 (911) WINDOW FRAME PARTS DIAGRAM")
-part-diagram-804-020.webp "PORSCHE 1989 (911) WINDOW FRAME PARTS DIAGRAM")
-part-diagram-805-000.webp "PORSCHE 1989 (911) WINDOW GLAZING PARTS DIAGRAM")
-part-diagram-805-005.webp "PORSCHE 1989 (911) WINDOW GLAZING PARTS DIAGRAM")
-part-diagram-805-010.webp "PORSCHE 1989 (911) WINDOW GLAZING PARTS DIAGRAM")
-part-diagram-807-000.webp "PORSCHE 1989 (911) INTERIOR EQUIPMENT - FRONT LUGGAGE COMPARTMENT PARTS DIAGRAM")
-part-diagram-807-001.webp "PORSCHE 1989 (911) TRIMS - FOOTWELL - DETACHABLE CARPETS PARTS DIAGRAM")
-part-diagram-807-002.webp "PORSCHE 1989 (911) INTERIOR EQUIPMENT - ADHESIVE CARPET PARTS DIAGRAM")
-part-diagram-807-005.webp "PORSCHE 1989 (911) INTERIOR EQUIPMENT PARTS DIAGRAM")
-part-diagram-807-006.webp "PORSCHE 1989 (911) INTERIOR EQUIPMENT - ROOF - ROLL BAR PARTS DIAGRAM")
-part-diagram-807-007.webp "PORSCHE 1989 (911) INTERIOR EQUIPMENT PARTS DIAGRAM")
-part-diagram-807-010.webp "PORSCHE 1989 (911) INTERIOR EQUIPMENT - DOORS PARTS DIAGRAM")
-part-diagram-807-015.webp "PORSCHE 1989 (911) BODY SHELL - SOUND ABSORBERS PARTS DIAGRAM")
-part-diagram-808-000.webp "PORSCHE 1989 (911) SEAT - COMPLETE PARTS DIAGRAM")
-part-diagram-809-000.webp "PORSCHE 1989 (911) DASHBOARD - WITH INSTALLATION PARTS PARTS DIAGRAM")
-part-diagram-809-005.webp "PORSCHE 1989 (911) GLOVE BOX - SUN VIZORS PARTS DIAGRAM")
-part-diagram-809-010.webp "PORSCHE 1989 (911) REAR VIEW MIRROR INNER - REAR VIEW MIRROR PARTS DIAGRAM")
-part-diagram-809-015.webp "PORSCHE 1989 (911) CENTER CONSOLE PARTS DIAGRAM")
-part-diagram-810-000.webp "PORSCHE 1989 (911) DECORATIVE FITTINGS PARTS DIAGRAM")
-part-diagram-810-005.webp "PORSCHE 1989 (911) DECORATIVE FITTINGS PARTS DIAGRAM")
-part-diagram-811-000.webp "PORSCHE 1989 (911) SUNROOF PARTS DIAGRAM")
-part-diagram-811-005.webp "PORSCHE 1989 (911) SOFT TOP PARTS DIAGRAM")
-part-diagram-811-006.webp "PORSCHE 1989 (911) WINDSHIELD FRAME - ACCESSORIES PARTS DIAGRAM")
-part-diagram-811-010.webp "PORSCHE 1989 (911) CONVERTIBLE TOP - TOP FRAME - MANUALLY ADJUSTABLE PARTS DIAGRAM")
