Porsche 911 Turbo (1976) repair kits Parts Diagram

698-000 - repair kits

Porsche 911 Turbo (1976) REPAIR KITS Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Price
# -
-
FRONT AXLE
# -
MPN: 91135195007
1 SET OF BRAKE PADS FOR DISC - BRAKES - FUER - FOR S BRAKE CALLIPER - 911.351.935.00/936.00 - DISCONTINUED PART
FRONT
# -
MPN: 91135195009
1 SET OF BRAKE PADS FOR DISC - BRAKES - FOR S BRAKE CALLIPER - 911.351.935.00/936.00
FRONT
from £71.27
from £71.27
# -
MPN: 90135199800
GASKET SET - FOR - S-CALLIPER - 911.351.935.00/936.00 - COMPRISING: - GASKET - FOR - PISTON - PROTECTIVE CAP - SAFETY SEAL
FRONT
from £37.70
from £37.70
# -
-
rear axle
# -
MPN: 91135295005
1 set of brake pads for disc - brakes - for - For M brake calliper - comprising: - brake lining
rear-- TEXTAR
from £71.43
from £71.43
# -
MPN: 91135295100
1 SET OF ATTACHMENT PARTS FOR - DISC BRAKE PADS
rear
from £50.99
from £50.99
# -
MPN: 91135299800
GASKET SET - FOR - M CALLIPER - WITHOUT: - DISK BALANCING - COMPRISING: - GASKET - FOR - PISTON - PROTECTIVE CAP - CLAMPING RING - SAFETY SEAL - SAFETY SEAL
rear
from £32.27
from £32.27
# -
MPN: 90135593000
REPAIR KIT - FOR - BRAKE MASTER CYLINDER - 19,05 MM - PART NUMBER - 911.355.012.01 - AND - 911.355.012.02 - COMPRISING: - THRUST RING - PISTON - WASHER - CUP - CUP - PISTON - WASHER - CUP - SEAL RING - LOCK RING
from £71.92
from £71.92
# -
MPN: 90135592400
PROTECTIVE CAP
from £14.97
from £14.97
# -
MPN: 91135592500
repair kit - brake master cylinder - part number - 911.355.011.10 - comprising: - thrust ring - cup - Washer - piston - cup - seal ring - thrust ring - cup - Washer - piston - Washer - cup - intermediate ring - lock ring - O-ring
-20,64 MM-----------------25 X 1,2
