porsche 1971 (914) valve control parts diagram

103-010 - VALVE CONTROL

Porsche 1971 (914) VALVE CONTROL Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                                                                #
                                                                                                Part number
                                                                                                Description
                                                                                                Key
                                                                                                Price
                                                                                                # 2
                                                                                                MPN: 91110522205
                                                                                                GUIDE RAIL
                                                                                                from £42.87
                                                                                                from £42.87
                                                                                                GUIDE RAIL Genuine Porsche Part - New (to order)
                                                                                                # 3
                                                                                                MPN: 90110522603
                                                                                                PIN - FOR - GUIDE RAIL
                                                                                                from £35.43
                                                                                                from £35.43
                                                                                                PIN - FOR - GUIDE RAIL Genuine Porsche Part - New (to order)
                                                                                                # 4
                                                                                                MPN: 90012306630
                                                                                                SEAL RING - A 10 X 16
                                                                                                from £1.12
                                                                                                from £1.12
                                                                                                seal ring - aluminium Genuine Porsche Part - New (to order)
                                                                                                # 6
                                                                                                MPN: 90110505500
                                                                                                SPROCKET - COMPLETE
                                                                                                from £88.91
                                                                                                from £88.91
                                                                                                sprocket - D >> - MJ 1968 Genuine Porsche Part - New (to order)
                                                                                                # 7
                                                                                                MPN: 90110505601
                                                                                                PIN - COMPLETE - DISCONTINUED PART
                                                                                                pin - Discontinued part Genuine Porsche Part - New (to order)
                                                                                                # 7
                                                                                                MPN: 90110505602
                                                                                                PIN - COMPLETE
                                                                                                from £31.05
                                                                                                from £31.05
                                                                                                PIN - COMPLETE Genuine Porsche Part - New (to order)
                                                                                                # 8
                                                                                                MPN: 90019701000
                                                                                                SPRING PIN - 3 X 22
                                                                                                from £0.82
                                                                                                from £0.82
                                                                                                Spring pin - 3 X 22 - D >> - MJ 1983 Genuine Porsche Part - New (to order)
                                                                                                # 10
                                                                                                MPN: 90110505001
                                                                                                housing - housing - complete
                                                                                                housing - housing - complete Genuine Porsche Part - New (to order)
                                                                                                # 10
                                                                                                MPN: 93010504900
                                                                                                TENSIONER - CHAIN - COMPLETE
                                                                                                tensioner - chain - M >> 640 0450 - M >> 630 8135 - M >> 630 1091 - M >> 630 9033 - M >> 670 0106 - M >> 689 1301 - M >> 689 0684 - M >> 670 8023 - Discontinued part Genuine Porsche Part - New (to order)
                                                                                                # -
                                                                                                -
                                                                                                REPAIR KIT - COMPRISING: - PICTURE - 12-15,18,20,21,24,26 - DISCONTINUED PART
                                                                                                # -
                                                                                                -
                                                                                                REPAIR KIT FOR UER CHAIN - TIGHTENER - COMPRISING: - PICTURE - 12-15,18,20,21,24,26
                                                                                                # 11
                                                                                                MPN: 93010555900
                                                                                                PISTON - FOR - TENSIONER - CHAIN
                                                                                                from £69.16
                                                                                                from £69.16
                                                                                                PISTON - FOR - TENSIONER - CHAIN Genuine Porsche Part - New (to order)
                                                                                                # 12
                                                                                                -
                                                                                                INTERMEDIATE PIECE
                                                                                                # 13
                                                                                                -
                                                                                                O-RING - R 10 - 1,3
                                                                                                # 14
                                                                                                -
                                                                                                HOUSING - FOR - BALL - VALVE
                                                                                                # 15
                                                                                                -
                                                                                                BALL - 5 MM V
                                                                                                # 16
                                                                                                MPN: 93010552300
                                                                                                SPRING GUIDE
                                                                                                from £2.34
                                                                                                from £2.34
                                                                                                SPRING GUIDE Genuine Porsche Part - New (to order)
                                                                                                # 17
                                                                                                MPN: 91610553400
                                                                                                pressure spring - for - tensioner - chain - Discontinued part
                                                                                                pressure spring - for - tensioner - chain - Discontinued part Genuine Porsche Part - New (to order)
                                                                                                # 17
                                                                                                MPN: 91610553401
                                                                                                pressure spring - for - tensioner - chain
                                                                                                from £4.32
                                                                                                from £4.32
                                                                                                pressure spring - for - tensioner - chain Genuine Porsche Part - New (to order)
                                                                                                # 18
                                                                                                -
                                                                                                CIRCLIP - 16
                                                                                                # 19
                                                                                                MPN: 90110555701
                                                                                                PISTON
                                                                                                PISTON Genuine Porsche Part - New (to order)
                                                                                                # 20
                                                                                                -
                                                                                                O-RING - 8,3 - 2,4
                                                                                                # 21
                                                                                                -
                                                                                                O-RING - 20,3 - 2,4
                                                                                                # 22
                                                                                                MPN: 93010553501
                                                                                                PRESSURE SPRING
                                                                                                from £1.44
                                                                                                from £1.44
                                                                                                PRESSURE SPRING Genuine Porsche Part - New (to order)
                                                                                                # 23
                                                                                                MPN: 93010556800
                                                                                                SPRING SEAT
                                                                                                from £3.93
                                                                                                from £3.93
                                                                                                SPRING SEAT Genuine Porsche Part - New (to order)
                                                                                                # 24
                                                                                                -
                                                                                                CIRCLIP - 28
                                                                                                # 25
                                                                                                MPN: 93010557300
                                                                                                BLEEDER SCREW
                                                                                                from £11.93
                                                                                                from £11.93
                                                                                                BLEEDER SCREW Genuine Porsche Part - New (to order)
                                                                                                # 26
                                                                                                -
                                                                                                SEAL RING - A 6,5 X 9,5
                                                                                                # 27
                                                                                                MPN: N 0122411
                                                                                                SPRING WASHER - B 8 X 15
                                                                                                from £0.64
                                                                                                from £0.64
                                                                                                spring washer - Not for: - (S)(D) - M >> 075 3003 - M >> 083 6549 Genuine Porsche Part - New (to order)
                                                                                                # 28
                                                                                                MPN: 90007602502
                                                                                                HEX. NUT - M 8 - DISCONTINUED PART
                                                                                                Supersession
                                                                                                Supersession
                                                                                                Genuine Porsche Part (no longer available to order)
                                                                                                # 28
                                                                                                MPN: 90007606402
                                                                                                hex. nut - M 8
                                                                                                from £0.59
                                                                                                from £0.59
                                                                                                hex. nut - SW 13 M 8 Genuine Porsche Part - New In stock
                                                                                                # 29
                                                                                                MPN: 93010519705
                                                                                                GASKET
                                                                                                from £3.80
                                                                                                from £3.80
                                                                                                gasket - D - MJ 1988>> Genuine Porsche Part - New In stock
                                                                                                # 30
                                                                                                MPN: 99970112440
                                                                                                O-RING - 67,5 X 75,5 X 4
                                                                                                from £3.62
                                                                                                from £3.62
                                                                                                O-Ring - 67,5X75,4X4 Genuine Porsche Part - New (to order)
                                                                                                # 31
                                                                                                MPN: 93010519600
                                                                                                COVER
                                                                                                from £37.18
                                                                                                from £37.18
                                                                                                COVER Genuine Porsche Part - New (to order)
                                                                                                # 32
                                                                                                MPN: 90002800801
                                                                                                LOCK RING - B 6
                                                                                                from £0.79
                                                                                                from £0.79
                                                                                                lock ring - D - MJ 1972>> Genuine Porsche Part - New (to order)
                                                                                                # 33
                                                                                                MPN: 90007501702
                                                                                                SCREW, HEX. HD. - M 6 X 25 - DISCONTINUED PART
                                                                                                SCREW, HEX. HD. - M 6 X V25 - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                                                                # 33
                                                                                                MPN: 90007501703
                                                                                                SCREW, HEX. HD. - M 6 X 25
                                                                                                from £0.73
                                                                                                from £0.73
                                                                                                SCREW, HEX. HD. - M 6 X V25 Genuine Porsche Part - New (to order)
                                                                                                # 34
                                                                                                MPN: 90110556200
                                                                                                THRUST WASHER - DISCONTINUED PART
                                                                                                THRUST WASHER - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                                                                # 34
                                                                                                MPN: 90110556202
                                                                                                THRUST WASHER
                                                                                                from £10.39
                                                                                                from £10.39
                                                                                                THRUST WASHER Genuine Porsche Part - New (to order)
                                                                                                # 35
                                                                                                MPN: 90110556100
                                                                                                SHIM
                                                                                                from £3.09
                                                                                                from £3.09
                                                                                                shim - - D >> - MJ 1975 Genuine Porsche Part - New (to order)
                                                                                                # 36
                                                                                                MPN: 90110558301
                                                                                                flange - sprocket
                                                                                                Supersession
                                                                                                Supersession
                                                                                                Genuine Porsche Part (no longer available to order)
                                                                                                # 37
                                                                                                MPN: 90011800500
                                                                                                WOODRUFF KEY - 4 X 5
                                                                                                woodruff key - Discontinued part Genuine Porsche Part - New (to order)
                                                                                                # 38
                                                                                                MPN: 90110554602
                                                                                                SPROCKET - II - DISCONTINUED PART
                                                                                                SPROCKET - II - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                                                                # 38
                                                                                                MPN: 90110554604
                                                                                                SPROCKET - II
                                                                                                from £60.84
                                                                                                from £60.84
                                                                                                sprocket - II - D - MJ 1969>> Genuine Porsche Part - New (to order)
                                                                                                # 39
                                                                                                MPN: 90024300100
                                                                                                DOWEL PIN - A 6 H 8 X 14
                                                                                                from £2.16
                                                                                                from £2.16
                                                                                                dowel pin - A 6H8 X 14 Genuine Porsche Part - New (to order)
                                                                                                # 41
                                                                                                MPN: 90110517200
                                                                                                NUT - FOR - CAMSHAFT
                                                                                                from £35.94
                                                                                                from £35.94
                                                                                                nut - M 090 7001 >> Genuine Porsche Part - New (to order)
                                                                                                # 42
                                                                                                MPN: 90110513300
                                                                                                camshaft - Discontinued part
                                                                                                LEFT
                                                                                                camshaft - Discontinued part Genuine Porsche Part - New (to order)
                                                                                                # 42
                                                                                                MPN: 90110513301
                                                                                                camshaft - Discontinued part
                                                                                                LEFT
                                                                                                camshaft - Discontinued part Genuine Porsche Part - New (to order)
                                                                                                # 42
                                                                                                MPN: 90110513302
                                                                                                camshaft
                                                                                                LEFT
                                                                                                from £955.19
                                                                                                from £955.19
                                                                                                camshaft - - D - MJ 1970>> Genuine Porsche Part - New (to order)
                                                                                                # 44
                                                                                                MPN: 90009501701
                                                                                                PIN - 5 X 24
                                                                                                (SPM)
                                                                                                from £1.10
                                                                                                from £1.10
                                                                                                pin - Discontinued part Genuine Porsche Part - New (to order)
                                                                                                # 45
                                                                                                MPN: 90110534204
                                                                                                ROCKER SHAFT - AS REQUIRED USE:
                                                                                                Supersession
                                                                                                Supersession
                                                                                                Genuine Porsche Part (no longer available to order)
                                                                                                # -
                                                                                                -
                                                                                                seal ring - Rocker shaft
                                                                                                # 46
                                                                                                MPN: 99906700800
                                                                                                SCREW, CHEESE HD.
                                                                                                from £5.76
                                                                                                from £5.76
                                                                                                SCREW, CHEESE HD. - M 7 X 48 Genuine Porsche Part - New (to order)
                                                                                                # 47
                                                                                                MPN: 90110534402
                                                                                                BUSHING - DISCONTINUED PART
                                                                                                BUSHING - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                                                                # 47
                                                                                                MPN: 90110534403
                                                                                                BUSHING
                                                                                                from £4.19
                                                                                                from £4.19
                                                                                                BUSHING Genuine Porsche Part - New (to order)
                                                                                                # 48
                                                                                                MPN: 90110537602
                                                                                                NUT - DISCONTINUED PART
                                                                                                NUT - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                                                                # 48
                                                                                                MPN: 90110537603
                                                                                                NUT
                                                                                                from £4.94
                                                                                                from £4.94
                                                                                                NUT Genuine Porsche Part - New (to order)
                                                                                                # 49
                                                                                                MPN: 93010504300
                                                                                                ROCKER ARM - COMPLETE - DISCONTINUED PART
                                                                                                ROCKER ARM - DISCONTINUED PART Genuine Porsche Part - New (to order)
                                                                                                # 49
                                                                                                MPN: 93010504302
                                                                                                ROCKER ARM - COMPLETE - DISCONTINUED PART
                                                                                                Supersession
                                                                                                Supersession
                                                                                                Genuine Porsche Part (no longer available to order)
                                                                                                # 49
                                                                                                MPN: 93010504305
                                                                                                Rocker arm - complete
                                                                                                from £107.71
                                                                                                from £107.71
                                                                                                Rocker arm - complete Genuine Porsche Part - New (to order)
                                                                                                # 50
                                                                                                MPN: 90110537002
                                                                                                ADJUSTING SCREW - COMPLETE
                                                                                                from £28.85
                                                                                                from £28.85
                                                                                                adjusting screw - valve Genuine Porsche Part - New (to order)
                                                                                                # 51
                                                                                                MPN: 99903400500
                                                                                                NUT
                                                                                                from £2.04
                                                                                                from £2.04
                                                                                                nut - M 8 X 1 Genuine Porsche Part - New (to order)
