porsche 2015 (918 spyder) oil pump parts diagram

104-000 - oil pump

Porsche 2015 (918 Spyder) OIL PUMP Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 1
            MPN: 91810704103
            oil pump
            from £6,041.18
            from £6,041.18
            oil pump Genuine Porsche Part - New (to order)
            # 2
            MPN: 99970767140
            O-RING
            22,5 X 320
            from £4.46
            from £4.46
            O-RING Genuine Porsche Part - New (to order)
            # 3
            MPN: 91810515103
            COVER
            from £364.15
            from £364.15
            COVER Genuine Porsche Part - New (to order)
            # 4
            MPN: 99970760740
            O-RING
            59 X 2,5
            from £5.11
            from £5.11
            O-RING Genuine Porsche Part - New (to order)
            # 5
            MPN: 99907310301
            SCREW, ROUND HD.
            M 6 X 16
            from £0.91
            from £0.91
            SCREW, ROUND HD Genuine Porsche Part - New In stock
            # 6
            MPN: 91810504105
            GEAR CARRIER
            FRONT
            from £675.71
            from £675.71
            GEAR CARRIER Genuine Porsche Part - New (to order)
            # 7
            MPN: 91810504302
            GEAR CARRIER
            FRONT
            GEAR CARRIER Genuine Porsche Part - New (to order)
            # 8
            MPN: 91810730500
            SHAFT - OIL PUMP
            from £277.86
            from £277.86
            SHAFT - OIL PUMP Genuine Porsche Part - New (to order)
            # 9
            MPN: 91810730701
            SHAFT - OIL PUMP
            from £241.63
            from £241.63
            SHAFT - OIL PUMP Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740100
            SPACER WASHER
            0,3 MM | No longer use the part here
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740110
            SPACER WASHER
            0,35 MM
            from £57.97
            from £57.97
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740101
            SPACER WASHER
            0,4 MM | No longer use the part here
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740111
            SPACER WASHER
            0,45 MM
            from £59.39
            from £59.39
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740102
            SPACER WASHER
            0,5 MM | No longer use the part here
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740112
            SPACER WASHER
            0,55 MM
            from £60.82
            from £60.82
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740103
            SPACER WASHER
            0,6 MM | No longer use the part here
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740113
            SPACER WASHER
            0,65 MM
            from £62.24
            from £62.24
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740104
            SPACER WASHER
            0,7 MM | No longer use the part here
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740114
            SPACER WASHER
            0,75 MM
            from £63.58
            from £63.58
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740105
            SPACER WASHER
            0,8 MM | No longer use the part here
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740115
            SPACER WASHER
            0,85 MM
            from £65.04
            from £65.04
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740106
            SPACER WASHER
            0,9 MM | No longer use the part here
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740116
            SPACER WASHER
            0,95 MM
            from £66.46
            from £66.46
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740107
            SPACER WASHER
            1,0 MM | No longer use the part here
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 10
            MPN: 91810740117
            SPACER WASHER
            1,05 MM
            from £67.86
            from £67.86
            SPACER WASHER Genuine Porsche Part - New (to order)
            # 11
            MPN: 91810701109
            oil pump
            No longer use the part here
            oil pump Genuine Porsche Part - New (to order)
            # 11
            MPN: 91810701110
            oil pump
            No longer use the part here
            oil pump Genuine Porsche Part - New (to order)
            # 11
            MPN: 91810701111
            oil pump
            from £7,007.76
            from £7,007.76
            oil pump Genuine Porsche Part - New (to order)
            # 12
            MPN: 99907310201
            SCREW, ROUND HD.
            M 6 X 25
            from £0.91
            from £0.91
            SCREW, ROUND HD Genuine Porsche Part - New (to order)
            # 13
            MPN: 99970736441
            SEAL RING
            30 X 2,5 | No longer use the part here
            from £2.96
            from £2.96
            SEAL RING Genuine Porsche Part - New In stock
            # 13
            MPN: 99610710351
            O-RING
            29,10 X 2,55
            from £12.13
            from £12.13
            O-Ring - 29,1 X 2,55 - also use: Genuine Porsche Part - New (to order)
            # 14
            MPN: 99907335201
            SCREW, ROUND HD.
            M 6 X 35
            from £2.45
            from £2.45
            SCREW, ROUND HD Genuine Porsche Part - New In stock
            # 15
            MPN: 91810725702
            OIL PIPE
            oil pump
            from £709.25
            from £709.25
            OIL PIPE Genuine Porsche Part - New (to order)
            # 16
            MPN: 91810741300
            LOCK WASHER
            from £19.10
            from £19.10
            LOCK WASHER Genuine Porsche Part - New (to order)
