Monocoque | See technical manual | Group 5.
porsche 2015 (918 spyder) special repair concept parts diagram

801-005 - SPECIAL REPAIR CONCEPT

Porsche 2015 (918 Spyder) SPECIAL REPAIR CONCEPT Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # 1
    MPN: 91855261701
    BRACKET FOR RETAINING FRAME
    LEFT
    from £400.58
    from £400.58
    BRACKET FOR RETAINING FRAME Genuine Porsche Part - New (to order)
    # 2
    MPN: 91855261901
    BRACKET FOR RETAINING FRAME
    RIGHT
    from £400.58
    from £400.58
    BRACKET FOR RETAINING FRAME Genuine Porsche Part - New (to order)
    # 3
    MPN: 91855262501
    BRACKET
    SUPPORT
    from £84.70
    from £84.70
    BRACKET Genuine Porsche Part - New (to order)
    # 4
    MPN: 91850191300
    SIDE MEMBER TRIM
    LEFT
    from £4,524.45
    from £4,524.45
    SIDE MEMBER TRIM Genuine Porsche Part - New (to order)
    # 5
    MPN: 91850191400
    SIDE MEMBER TRIM
    RIGHT
    from £4,221.88
    from £4,221.88
    SIDE MEMBER TRIM Genuine Porsche Part - New (to order)
    # 6
    MPN: 91850190700
    COWL
    LINING
    Supersession
    Supersession
    Genuine Porsche Part (no longer available to order)
    # -
    -
    CARBON GLOSS BLACK
    This part replaces part number 91850190700
    # -
    -
    PRIMED
    This part replaces part number 91850190700
    # 7
    MPN: 91850190200
    COWL
    upper |
    also use: | Position | 8 | comprising: | cowl 1x | bracket 2x | pop-rivet 2x | pop-rivet 2x
    from £6,238.45
    from £6,238.45
    COWL Genuine Porsche Part - New (to order)
    # 8
    MPN: 91850190300
    COWL
    lower | comprising: | Scuttle support 1x | bracket 2x | bracket 2x | bracket 1x | fillister hd. screw 8x | fillister hd. screw 4x
    from £3,250.45
    from £3,250.45
    COWL Genuine Porsche Part - New (to order)
    # 9
    MPN: 91850190400
    ROLL BAR
    upper | comprising: | frame 1x | trim 1x | trim 2x | headrest | screw, csk. hd. 16x
    from £8,073.22
    from £8,073.22
    ROLL BAR Genuine Porsche Part - New (to order)
    # 10
    MPN: 91855261501
    BRACKET FOR RETAINING FRAME
    COWL
    from £78.52
    from £78.52
    BRACKET FOR RETAINING FRAME Genuine Porsche Part - New (to order)
    # 11
    MPN: 91855262101
    BRACKET FOR RETAINING FRAME
    COWL
    from £58.90
    from £58.90
    BRACKET FOR RETAINING FRAME Genuine Porsche Part - New (to order)
    # 12
    MPN: 91855262301
    BRACKET FOR RETAINING FRAME
    COWL
    from £58.90
    from £58.90
    BRACKET FOR RETAINING FRAME Genuine Porsche Part - New (to order)
    # 13
    MPN: 99907362101
    FILLISTER HD. SCREW
    M5X16 | for | POS10 | POS11 | POS12
    from £6.71
    from £6.71
    FILLISTER HD. SCREW Genuine Porsche Part - New (to order)
