porsche 1979 (924) for - k-jetronic parts diagram

107-010 - FOR - K-JETRONIC

Porsche 1979 (924) FOR - K-JETRONIC Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 1
MPN: 047133063
THROTTLE BODY
LHD
THROTTLE BODY Genuine Porsche Part - New (to order)
# 1
MPN: 047133063F
throttle body - D - MJ 1979>> - MJ 1979
AUT.
throttle body - D - MJ 1979>> - MJ 1979 Genuine Porsche Part - New (to order)
# 1
MPN: 047133063B
THROTTLE BODY
RHD
THROTTLE BODY Genuine Porsche Part - New (to order)
# -
-
CAP
(\\S..\\)
# 1
MPN: 823721567
BUSHING
from £1.66
from £1.66
BUSHING Genuine Porsche Part - New (to order)
# 2
MPN: N 01224111
SPRING WASHER - DISCONTINUED PART
spring washer - M 8 X 22 - Discontinued part Genuine Porsche Part - New (to order)
# 3
MPN: N 0147172
bolt, with hex. socket - hd. - M 8 X 40
bolt, with hex. socket - hd. - M 8 X 40 Genuine Porsche Part - New (to order)
# 4
MPN: 049133073B
GASKET
from £4.07
from £4.07
GASKET Genuine Porsche Part - New (to order)
# 5
MPN: 047133093A
BRACKET
BRACKET Genuine Porsche Part - New (to order)
# 6
MPN: N 01021513
SCREW, HEX. HD. - M 6 X 15
from £2.09
from £2.09
screw, hex. hd. - M6 X 15 Genuine Porsche Part - New (to order)
# 7
MPN: N 0122265
SPRING WASHER
from £0.70
from £0.70
spring washer - M6X16 Genuine Porsche Part - New In stock
# 8
MPN: 047133192
BRACKET
BRACKET Genuine Porsche Part - New (to order)
# 9
MPN: 047133191D
BRACKET
BRACKET Genuine Porsche Part - New (to order)
# 10
MPN: 047133191C
BRACKET
BRACKET Genuine Porsche Part - New (to order)
# -
-
RUBBER GROMMET
# 11
MPN: 047133201
Intake manifold - D >> - MJ 1978
Intake manifold - D >> - MJ 1978 Genuine Porsche Part - New (to order)
# 11
MPN: 477133201
intake manifold - D - MJ 1979>> - MJ 1979
intake manifold - D - MJ 1979>> - MJ 1979 Genuine Porsche Part - New (to order)
# 11
MPN: 93111040300
inscription - D - MJ 1979>> - MJ 1979
INSCRIPTION - D - MJ 1979>>- MJ 1979 Genuine Porsche Part - New (to order)
# 11
MPN: 047133239
SUPPORT
LHD
SUPPORT Genuine Porsche Part - New (to order)
# 11
MPN: 047133239D
SUPPORT
RHD
SUPPORT Genuine Porsche Part - New (to order)
# 11
MPN: N 01021513
SCREW, HEX. HD. - M 6 X 15
from £2.09
from £2.09
screw, hex. hd. - M6 X 15 Genuine Porsche Part - New (to order)
# -
-
SPRING WASHER
# 12
MPN: 477133227
GASKET
from £6.05
from £6.05
GASKET Genuine Porsche Part - New (to order)
# 14
MPN: N 0110088
HEX. NUT
from £0.52
from £0.52
HEX. NUT - M8 Genuine Porsche Part - New In stock
# 15
MPN: N 0103732
SCREW, HEX. HD. - M 8 X 72
SCREW, HEX. HD. - M 8 X 72 Genuine Porsche Part - New (to order)
# 16
MPN: N 0444115
stud - M 8 X 30
from £3.01
from £3.01
stud - M 8 X 30 Genuine Porsche Part - New (to order)
# 17
MPN: 048129723
SUPPORT
SUPPORT Genuine Porsche Part - New (to order)
# 18
MPN: 90007508702
SCREW, HEX. HD. - M 8 X 15 - DISCONTINUED PART
screw, hex. hd. - M8X16 Genuine Porsche Part - New (to order)
# 18
MPN: 90007508703
SCREW, HEX. HD. - M 8 X 15
Supersession
Supersession
Genuine Porsche Part (no longer available to order)
# 18
MPN: 90007508704
SCREW, HEX. HD. - M 8 X 15
M8X16-yellow
from £0.86
from £0.86
This part replaces part number 90007508703
screw, hex. hd. - M8X16 Genuine Porsche Part - New (to order)
# 20
MPN: N 0102407
SCREW, HEX. HD. - M 8 X 20
from £1.02
from £1.02
SCREW, HEX. HD. - M 8 X 20 - 4-SPEED - D >>- MJ 1984 Genuine Porsche Part - New (to order)
# 21
MPN: 047133315
INJECTION LINE
cylinder 1,2
from £68.51
from £68.51
INJECTION LINE - CYLINDER 2 Genuine Porsche Part - New (to order)
# 21
MPN: 047133319
INJECTION LINE
cylinder 3
INJECTION LINE - CYLINDER 3 Genuine Porsche Part - New (to order)
# 21
MPN: 047133321
INJECTION LINE
cylinder 4
from £36.00
from £36.00
INJECTION LINE - CYLINLDER 4 Genuine Porsche Part - New (to order)
# 22
MPN: 91111089900
BANJO BOLT
from £16.94
from £16.94
banjo bolt - D >> - MJ 1980 Genuine Porsche Part - New (to order)
# 22
MPN: 90017500202
SCREW
from £6.44
from £6.44
SCREW Genuine Porsche Part - New (to order)
# 23
MPN: 90012305020
SEAL RING - A 8 X 11,5
from £0.82
from £0.82
seal ring - A8X11,5 Genuine Porsche Part - New In stock
# 23
MPN: 90012303320
SEAL RING - A 10 X 14
from £1.22
from £1.22
seal ring - for - drain plug - torque converter Genuine Porsche Part - New (to order)
# 24
MPN: 063133403
WARM-UP VALVE
WARM-UP VALVE Genuine Porsche Part - New (to order)
# -
-
WARM-UP VALVE
# 25
MPN: N 0147441
bolt, with hex. socket - hd. - M 6 X 32
from £1.70
from £1.70
bolt, with hex. socket - hd. - M 6 X 32 - D >> - MJ 1985 Genuine Porsche Part - New (to order)
# 26
MPN: N 0122265
SPRING WASHER
from £0.70
from £0.70
spring washer - M6X16 Genuine Porsche Part - New In stock
# 27
MPN: 477133535
BRACKET - TEMPERATURE SWITCH
BRACKET - TEMPERATURE SWITCH Genuine Porsche Part - New (to order)
# 29
MPN: 047133453A
IDLE AIR CONTROL
IDLE AIR CONTROL Genuine Porsche Part - New (to order)
# -
-
Retaining Clip
# 30
MPN: N 0147032
bolt, with hex. socket - hd. - M 6 X 18
from £2.30
from £2.30
bolt, with hex. socket - hd. - M6 X 18 - D - MJ 1972>> Genuine Porsche Part - New (to order)
# 31
MPN: 047133497B
HOSE
HOSE Genuine Porsche Part - New (to order)
# 32
MPN: 99951234600
Hose Clamp - 12-20
from £3.29
from £3.29
Hose Clamp - SGT 16-25 - Interior sensor Genuine Porsche Part - New In stock
# 33
MPN: 93060610700
ELECTRIC START VALVE
from £229.03
from £229.03
ELECTRIC START VALVE Genuine Porsche Part - New (to order)
# 34
MPN: 063906179
gasket - Discontinued part
gasket - Discontinued part Genuine Porsche Part - New (to order)
# 34
MPN: 026906179A
gasket - Discontinued part
gasket - Discontinued part Genuine Porsche Part - New (to order)
# 34
MPN: 050906179
GASKET
from £2.06
from £2.06
GASKET Genuine Porsche Part - New (to order)
# 35
MPN: 063133541
SCREWED SOCKET - DISCONTINUED PART
SCREWED SOCKET - DISCONTINUED PART Genuine Porsche Part - New (to order)
# 35
MPN: 063133558
SCREWED SOCKET
from £24.99
from £24.99
SCREWED SOCKET Genuine Porsche Part - New (to order)
# 35
MPN: 068130233
SEAL RING - A 8 X 11,5
SEAL RING - A 8 X 11,5 Genuine Porsche Part - New (to order)
# 36
MPN: 047133551
INJECTOR
INJECTOR Genuine Porsche Part - New (to order)
# 37
MPN: 063133555
INSERT FOR INJECTOR
from £5.74
from £5.74
INSERT FOR INJECTOR Genuine Porsche Part - New (to order)
# 38
MPN: 034133557E
O-RING
from £3.84
from £3.84
O-RING Genuine Porsche Part - New (to order)
# 39
MPN: 047133625
Fuel return line - F >> 92-47100 287
Fuel return line - F >> 92-47100 287 Genuine Porsche Part - New (to order)
# 39
MPN: 047133625A
Fuel return line - F 92-47100 288>> - D >> - MJ 1978
Fuel return line - F 92-47100 288>> - D >> - MJ 1978 Genuine Porsche Part - New (to order)
# -
-
F 92-48100 777>> - F >> 92-48105 656
# -
-
ALSO USE:
477 209 175-477 209 176 A-477 209 161
# 39
MPN: 047133625C
Fuel return line - D - MJ 1979>> - MJ 1979
Fuel return line - D - MJ 1979>> - MJ 1979 Genuine Porsche Part - New (to order)
# 40
MPN: 047133627
FUEL SUPPLY LINE
FUEL SUPPLY LINE Genuine Porsche Part - New (to order)
# 41
MPN: N 0210712
BANJO BOLT
banjo bolt - LL8 Genuine Porsche Part - New (to order)
# 41
MPN: 047133691
Screw socket - D >> - MJ 1978
SCREW SOCKET - D >>- MJ 1978 Genuine Porsche Part - New (to order)
# 42
MPN: N 0138123
SEAL RING - A 12 X 15,5
from £3.20
from £3.20
SEAL RING - A 12 X 15,6 Genuine Porsche Part - New (to order)
# 43
MPN: 047133655
Fuel control line - D >> - MJ 1978
Fuel control line - D >> - MJ 1978 Genuine Porsche Part - New (to order)
# 43
MPN: 047133655B
Fuel control line - D - MJ 1979>> - MJ 1979
Fuel control line - D - MJ 1979>> - MJ 1979 Genuine Porsche Part - New (to order)
# -
-
BRACKET - FUEL LINE
# 43
MPN: 477133525D
solenoid valve - with: - bracket - D - MJ 1979>> - MJ 1979
SOLENOID VALVE - WITH: - BRACKET - D - MJ 1979>>- MJ 1979 Genuine Porsche Part - New (to order)
# 44
MPN: 047131013
THROTTLE VALVE LIFT
(\\S..\\)
THROTTLE VALVE LIFT Genuine Porsche Part - New (to order)
# -
-
BRACKET
(\\S..\\)
# -
-
FROM - 02/77
# 44
MPN: 047131013A
VACUUM LIMITER
(\\J..\\,\\S..\\, \\USA\\,\\CDN\\)
VACUUM LIMITER Genuine Porsche Part - New (to order)
# 45
MPN: 047131039
CLAMP
CLAMP Genuine Porsche Part - New (to order)
# 46
MPN: 047131455
BRACKET
(\\S..\\)
BRACKET Genuine Porsche Part - New (to order)
# 47
MPN: 99970323900
BONDED RUBBER BUFFER
Supersession
Supersession
Genuine Porsche Part (no longer available to order)
# 48
MPN: N 01021513
SCREW, HEX. HD. - M 6 X 15
from £2.09
from £2.09
screw, hex. hd. - M6 X 15 Genuine Porsche Part - New (to order)
# 49
MPN: 90007501402
SCREW, HEX. HD. - M 6 X 18 - DISCONTINUED PART
screw, hex. hd. - M6 X 18 - Discontinued part Genuine Porsche Part - New (to order)
# 49
MPN: 90007501403
SCREW, HEX. HD. - M 6 X 18
from £2.04
from £2.04
screw, hex. hd. - M6 X 18 Genuine Porsche Part - New (to order)
# 50
MPN: 90007601002
NUT - DISCONTINUED PART
nut - M6 - Discontinued part Genuine Porsche Part - New (to order)
# 50
MPN: 9000760100B
NUT
from £0.73
from £0.73
NUT - M6 Genuine Porsche Part - New In stock
# 51
MPN: N 0122265
SPRING WASHER
from £0.70
from £0.70
spring washer - M6X16 Genuine Porsche Part - New In stock
# 52
MPN: N 0203591
HOSE
Running meter
Supersession
Supersession
Genuine Porsche Part (no longer available to order)
# 53
MPN: N 0235262
HOSE CLAMP - A 9 X 18
from £2.62
from £2.62
HOSE CLAMP - A 9 X 18 Genuine Porsche Part - New (to order)
# 54
MPN: 047131461
BRANCH PIECE
(\\S..\\)
BRANCH PIECE Genuine Porsche Part - New (to order)
# 55
MPN: N 0203612
HOSE IN COILS OF 5M - 'ORDER QTY. 5'
Running meter
from £71.86
from £71.86
Hose in coils of 5m - 'Order qty. 5' - Discontinued part Genuine Porsche Part - New (to order)
# 56
MPN: 99951234600
HOSE CLAMP - LC 16 - 25
from £3.29
from £3.29
Hose Clamp - SGT 16-25 - Interior sensor Genuine Porsche Part - New In stock
# -
-
INSTALLATION KIT - FOR - WARM-STARTING PROBLEM
# -
-
SOLENOID VALVE
# -
-
RETAINING BRACKET
# -
-
SCREW, CHEESE HD. - M 6 X 12 - DISCONTINUED PART
# -
-
SCREW, CHEESE HD. - M 6 X 12
# -
-
Fuel supply line - solenoid valve - Fuel distributor
# -
-
SCREWED SOCKET
# -
-
banjo bolt - M 8 X 1
# -
-
SEAL RING
# -
-
FUEL RETURN LINE
# -
-
BANJO BOLT
# -
-
BANJO BOLT
# -
-
SCREWED SOCKET
# -
-
TEMPERATURE SWITCH
# -
-
HEX. NUT
# -
-
BRACKET - FOR - TEMPERATURE SWITCH
# -
-
harness
# -
-
TIE WRAP
# -
-
SCREW SOCKET
# -
-
INSTALLATION INSTRUCTIONS
Translating Select View All Diagrams Search Most relevant Price descending Price ascending Translating 7 days days Stock Order Urgent Order
